4TR9

Ternary co-crystal structure of fructose-bisphosphate aldolase from Plasmodium falciparum in complex with TRAP and a small molecule inhibitor


Experimental Data Snapshot

  • Method: X-RAY DIFFRACTION
  • Resolution: 2.11 Å
  • R-Value Free: 0.262
  • R-Value Work: 0.206
  • R-Value Observed: 0.209

Starting Model: experimental
View more details

wwPDB Validation   3D Report Full Report


Ligand Structure Quality Assessment


This is version 1.2 of the entry. See complete history


Literature

Inhibition by stabilization: targeting the Plasmodium falciparum aldolase-TRAP complex.

Nemetski, S.M.Cardozo, T.J.Bosch, G.Weltzer, R.O'Malley, K.Ejigiri, I.Kumar, K.A.Buscaglia, C.A.Nussenzweig, V.Sinnis, P.Levitskaya, J.Bosch, J.

(2015) Malar J 14: 324-324

  • DOI: https://doi.org/10.1186/s12936-015-0834-9
  • Primary Citation of Related Structures:
    4TR9

  • PubMed Abstract:

    Emerging resistance of the malaria parasite Plasmodium to current therapies underscores the critical importance of exploring novel strategies for disease eradication. Plasmodium species are obligate intracellular protozoan parasites. They rely on an unusual form of substrate-dependent motility for their migration on and across host-cell membranes and for host cell invasion. This peculiar motility mechanism is driven by the 'glideosome', an actin-myosin associated, macromolecular complex anchored to the inner membrane complex of the parasite. Myosin A, actin, aldolase, and thrombospondin-related anonymous protein (TRAP) constitute the molecular core of the glideosome in the sporozoite, the mosquito stage that brings the infection into mammals. Virtual library screening of a large compound library against the PfAldolase-TRAP complex was used to identify candidate compounds that stabilize and prevent the disassembly of the glideosome. The mechanism of these compounds was confirmed by biochemical, biophysical and parasitological methods. A novel inhibitory effect on the parasite was achieved by stabilizing a protein-protein interaction within the glideosome components. Compound 24 disrupts the gliding and invasive capabilities of Plasmodium parasites in in vitro parasite assays. A high-resolution, ternary X-ray crystal structure of PfAldolase-TRAP in complex with compound 24 confirms the mode of interaction and serves as a platform for future ligand optimization. This proof-of-concept study presents a novel approach to anti-malarial drug discovery and design. By strengthening a protein-protein interaction within the parasite, an avenue towards inhibiting a previously "undruggable" target is revealed and the motility motor responsible for successful invasion of host cells is rendered inactive. This study provides new insights into the malaria parasite cell invasion machinery and convincingly demonstrates that liver cell invasion is dramatically reduced by 95 % in the presence of the small molecule stabilizer compound 24.


  • Organizational Affiliation

    Department of Biochemistry and Molecular Pharmacology, New York University School of Medicine, New York, USA. maureen.nemetski@gmail.com.


Macromolecules
Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 1
MoleculeChains Sequence LengthOrganismDetailsImage
Fructose-bisphosphate aldolase
A, B, C, D
369Plasmodium falciparum 3D7Mutation(s): 0
Gene Names: PF14_0425
EC: 4.1.2.13
UniProt
Find proteins for Q7KQL9 (Plasmodium falciparum (isolate 3D7))
Explore Q7KQL9
Go to UniProtKB:  Q7KQL9
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupQ7KQL9
Sequence Annotations
Expand
  • Reference Sequence

Find similar proteins by:  Sequence   |   3D Structure

Entity ID: 2
MoleculeChains Sequence LengthOrganismDetailsImage
ALA-ALA-SER-LEU-TYR-GLU-LYS-LYS-ALA-ALA10Plasmodium falciparum 3D7Mutation(s): 0
UniProt
Find proteins for Q7KQL9 (Plasmodium falciparum (isolate 3D7))
Explore Q7KQL9
Go to UniProtKB:  Q7KQL9
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupQ7KQL9
Sequence Annotations
Expand
  • Reference Sequence

Find similar proteins by:  Sequence   |   3D Structure

Entity ID: 3
MoleculeChains Sequence LengthOrganismDetailsImage
ALA-ALA-ALA-SER-LEU-TYR-GLU-LYS-LYS-ALA-ALAF [auth G]11Plasmodium falciparum 3D7Mutation(s): 0
UniProt
Find proteins for Q7KQL9 (Plasmodium falciparum (isolate 3D7))
Explore Q7KQL9
Go to UniProtKB:  Q7KQL9
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupQ7KQL9
Sequence Annotations
Expand
  • Reference Sequence

Find similar proteins by:  Sequence   |   3D Structure

Entity ID: 4
MoleculeChains Sequence LengthOrganismDetailsImage
ASP-TRP-ASNG [auth H],
H [auth I],
I [auth J],
J [auth K]
3Plasmodium falciparum 3D7Mutation(s): 0
UniProt
Find proteins for Q76NM2 (Plasmodium falciparum (isolate 3D7))
Explore Q76NM2
Go to UniProtKB:  Q76NM2
Entity Groups
UniProt GroupQ76NM2
Sequence Annotations
Expand
  • Reference Sequence
Experimental Data & Validation

Experimental Data

  • Method: X-RAY DIFFRACTION
  • Resolution: 2.11 Å
  • R-Value Free: 0.262
  • R-Value Work: 0.206
  • R-Value Observed: 0.209
  • Space Group: P 21 21 21
Unit Cell:
Length ( Å )Angle ( ˚ )
a = 69.896α = 90
b = 139.557β = 90
c = 142.099γ = 90
Software Package:
Software NamePurpose
PHENIXrefinement

Structure Validation

View Full Validation Report



Ligand Structure Quality Assessment


Entry History

Deposition Data

Revision History  (Full details and data files)

  • Version 1.0: 2015-08-26
    Type: Initial release
  • Version 1.1: 2015-09-02
    Changes: Database references
  • Version 1.2: 2023-09-27
    Changes: Data collection, Database references, Derived calculations, Refinement description
