4RFA | pdb_00004rfa

Crystal structure of cyclic nucleotide-binding domain containing protein from Listeria monocytogenes EGD-e

• PDB DOI: https://doi.org/10.2210/pdb4RFA/pdb

• Classification: TRANSCRIPTION REGULATOR
• Organism(s): Listeria monocytogenes EGD-e
• Expression System: Escherichia coli BL21(DE3)
• Mutation(s): No


• Deposited: 2014-09-25 Released: 2014-10-15
• Deposition Author(s): Filippova, E.V., Minasov, G., Kiryukhina, O., Jedrzejczak, R., Joachimiak, A., Anderson, W.F., Midwest Center for Structural Genomics (MCSG)

---

Experimental Data Snapshot

• Method: X-RAY DIFFRACTION
• Resolution: 2.21 Å
• R-Value Free:
  0.243 (Depositor), 0.244 (DCC)
• R-Value Work:
  0.206 (Depositor), 0.213 (DCC)
• R-Value Observed:
  0.208 (Depositor)

Literature

Crystal structure of cyclic nucleotide-binding domain containing protein from Listeria monocytogenes EGD-e

Filippova, E.V., Minasov, G., Kiryukhina, O., Jedrzejczak, R., Joachimiak, A., Anderson, W.F.

To be published.

Biological Assembly 1

Global Symmetry: Cyclic - C2  (Explore in 3D)
Global Stoichiometry: Homo 2-mer - A2

Biological assembly 1 assigned by authors and generated by PISA (software)

Macromolecule Content

• Total Structure Weight: 26.72 kDa
• Atom Count: 1,800
• Modeled Residue Count: 214
• Deposited Residue Count: 226
• Unique protein chains: 1

Macromolecules

Entity ID: 1
Molecule	Chains	Sequence Length	Organism	Details	Image
Lmo0740 protein	A	226	Listeria monocytogenes EGD-e	Mutation(s): 0  Gene Names: lmo0740
UniProt
Find proteins for Q8Y902 (Listeria monocytogenes serovar 1/2a (strain ATCC BAA-679 / EGD-e)) Explore Q8Y902  Go to UniProtKB:  Q8Y902

Small Molecules

Modified Residues  1 Unique
ID	Chains	Type	Formula	2D Diagram	Parent
MSE	A	L-PEPTIDE LINKING	C5 H11 N O2 Se		MET

Experimental Data & Validation

Experimental Data

• Method: X-RAY DIFFRACTION
• Resolution: 2.21 Å
• R-Value Free:  0.243 (Depositor), 0.244 (DCC)
• R-Value Work:  0.206 (Depositor), 0.213 (DCC)
• R-Value Observed: 0.208 (Depositor)

Space Group: P 6₅ 2 2

Unit Cell:

Length ( Å )	Angle ( ˚ )
a = 91.987	α = 90
b = 91.987	β = 90
c = 144.079	γ = 120

Software Package:

Software Name	Purpose
Blu-Ice	data collection
HKL-3000	phasing
REFMAC	refinement
HKL-3000	data reduction
HKL-3000	data scaling

Structure Validation

Entry History

Deposition Data

• Released Date: 2014-10-15
Deposition Author(s): Filippova, E.V., Minasov, G., Kiryukhina, O., Jedrzejczak, R., Joachimiak, A., Anderson, W.F., Midwest Center for Structural Genomics (MCSG)

Revision History

• Version 1.0: 2014-10-15
  Type: Initial release

• Version 1.1: 2017-11-22
  Changes: Refinement description
• Version 1.2: 2024-11-27
  Changes: Data collection, Database references, Derived calculations, Structure summary
