4QOA

Crystal structure of a putative periplasmic protein (BACUNI_04550) from Bacteroides uniformis ATCC 8492 at 2.75 A resolution

PDB DOI: https://doi.org/10.2210/pdb4QOA/pdb

Classification: STRUCTURAL GENOMICS, UNKNOWN FUNCTION
Organism(s): Bacteroides uniformis ATCC 8492
Expression System: Escherichia coli
Mutation(s): No

Deposited: 2014-06-19 Released: 2014-07-16
Deposition Author(s): Joint Center for Structural Genomics (JCSG)

Experimental Data Snapshot

Method: X-RAY DIFFRACTION
Resolution: 2.75 Å
R-Value Free: 0.250
R-Value Work: 0.215
R-Value Observed: 0.217

wwPDB Validation 3D Report Full Report

This is version 1.3 of the entry. See complete history.

Literature

Crystal structure of a putative periplasmic protein (BACUNI_04550) from Bacteroides uniformis ATCC 8492 at 2.75 A resolution

Joint Center for Structural Genomics (JCSG)

To be published.

Macromolecule Content

Total Structure Weight: 14.79 kDa
Atom Count: 1,030
Modelled Residue Count: 126
Deposited Residue Count: 127
Unique protein chains: 1

Macromolecules

Find similar proteins by:

(by identity cutoff) | 3D Structure

Entity ID: 1
Molecule	Chains	Sequence Length	Organism	Details	Image
Putative periplasmic protein	A	127	Bacteroides uniformis ATCC 8492	Mutation(s): 0 Gene Names: BACUNI_04550
UniProt
Find proteins for A7VAB9 (Bacteroides uniformis (strain ATCC 8492 / DSM 6597 / CCUG 4942 / CIP 103695 / JCM 5828 / KCTC 5204 / NCTC 13054 / VPI 0061)) Explore A7VAB9 Go to UniProtKB: A7VAB9
Entity Groups
Sequence Clusters	30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt Group	A7VAB9
Sequence Annotations Expand
Reference Sequence

Small Molecules

Ligands 1 Unique
ID	Chains	Name / Formula / InChI Key	2D Diagram	3D Interactions
EDO Query on EDO Download Ideal Coordinates CCD File SDF format, chain B [auth A] SDF format, chain C [auth A] MOL2 format, chain B [auth A] MOL2 format, chain C [auth A] mmCIF format, chain B [auth A] mmCIF format, chain C [auth A]	B [auth A], C [auth A]	1,2-ETHANEDIOL C₂ H₆ O₂ LYCAIKOWRPUZTN-UHFFFAOYSA-N		Interactions Focus chain B [auth A] Focus chain C [auth A] Interactions & Density Focus chain B [auth A] Focus chain C [auth A]

Modified Residues 1 Unique
ID	Chains	Type	Formula	2D Diagram	Parent
MSE Query on MSE	A	L-PEPTIDE LINKING	C₅ H₁₁ N O₂ Se		MET

Experimental Data & Validation

Experimental Data

Method: X-RAY DIFFRACTION
Resolution: 2.75 Å
R-Value Free: 0.250
R-Value Work: 0.215
R-Value Observed: 0.217
Space Group: P 6₅ 2 2
Diffraction Data: https://doi.org/10.18430/M34QOA

Unit Cell:

Length ( Å )	Angle ( ˚ )
a = 103.311	α = 90
b = 103.311	β = 90
c = 90.83	γ = 120

Software Package:

Software Name	Purpose
MolProbity	model building
PDB_EXTRACT	data extraction
SHELX	phasing
SHARP	phasing
SCALA	data scaling
BUSTER-TNT	refinement
MOSFLM	data reduction
SHELXD	phasing
BUSTER	refinement

Structure Validation

View Full Validation Report

Entry History

Deposition Data

Released Date: 2014-07-16

Deposition Author(s):

Joint Center for Structural Genomics (JCSG)

Revision History (Full details and data files)

Version 1.0: 2014-07-16
Type: Initial release
Version 1.1: 2017-11-22
Changes: Refinement description
Version 1.2: 2023-02-01
Changes: Database references, Derived calculations
Version 1.3: 2024-10-30
Changes: Data collection, Structure summary
