4Q6M

Structural analysis of the apo-form of Helicobacter pylori Csd4, a D,L-carboxypeptidase


Experimental Data Snapshot

  • Method: X-RAY DIFFRACTION
  • Resolution: 1.60 Å
  • R-Value Free: 0.220
  • R-Value Work: 0.194
  • R-Value Observed: 0.195

wwPDB Validation 3D Report Full Report


This is version 1.1 of the entry. See complete history


Literature

Structural basis for the recognition of muramyltripeptide by Helicobacter pylori Csd4, a D,L-carboxypeptidase controlling the helical cell shape

Kim, H.S.Kim, J.Im, H.N.An, D.R.Lee, M.Hesek, D.Mobashery, S.Kim, J.Y.Cho, K.Yoon, H.J.Han, B.W.Lee, B.I.Suh, S.W.

(2014) Acta Crystallogr D Biol Crystallogr 70: 2800-2812

  • DOI: 10.1107/S1399004714018732
  • Structures With Same Primary Citation

  • PubMed Abstract:
  • Helicobacter pylori infection causes a variety of gastrointestinal diseases, including peptic ulcers and gastric cancer. Its colonization of the gastric mucosa of the human stomach is a prerequisite for survival in the stomach. Colonization depends o ...

    Helicobacter pylori infection causes a variety of gastrointestinal diseases, including peptic ulcers and gastric cancer. Its colonization of the gastric mucosa of the human stomach is a prerequisite for survival in the stomach. Colonization depends on its motility, which is facilitated by the helical shape of the bacterium. In H. pylori, cross-linking relaxation or trimming of peptidoglycan muropeptides affects the helical cell shape. Csd4 has been identified as one of the cell shape-determining peptidoglycan hydrolases in H. pylori. It is a Zn(2+)-dependent D,L-carboxypeptidase that cleaves the bond between the γ-D-Glu and the mDAP of the non-cross-linked muramyltripeptide (muramyl-L-Ala-γ-D-Glu-mDAP) of the peptidoglycan to produce the muramyldipeptide (muramyl-L-Ala-γ-D-Glu) and mDAP. Here, the crystal structure of H. pylori Csd4 (HP1075 in strain 26695) is reported in three different states: the ligand-unbound form, the substrate-bound form and the product-bound form. H. pylori Csd4 consists of three domains: an N-terminal D,L-carboxypeptidase domain with a typical carboxypeptidase fold, a central β-barrel domain with a novel fold and a C-terminal immunoglobulin-like domain. The D,L-carboxypeptidase domain recognizes the substrate by interacting primarily with the terminal mDAP moiety of the muramyltripeptide. It undergoes a significant structural change upon binding either mDAP or the mDAP-containing muramyltripeptide. It it also shown that Csd5, another cell-shape determinant in H. pylori, is capable of interacting not only with H. pylori Csd4 but also with the dipeptide product of the reaction catalyzed by Csd4.


    Organizational Affiliation

    Department of Chemistry, College of Natural Sciences, Seoul National University, Seoul 151-742, Republic of Korea.



Macromolecules

Find similar proteins by: Sequence  |  Structure

Entity ID: 1
MoleculeChainsSequence LengthOrganismDetails
Conserved hypothetical secreted protein
A
437Helicobacter pylori 26695Mutation(s): 0
Gene Names: HP_1075
Find proteins for O25708 (Helicobacter pylori (strain ATCC 700392 / 26695))
Go to UniProtKB:  O25708
Protein Feature View
  • Reference Sequence
Small Molecules
Ligands 2 Unique
IDChainsName / Formula / InChI Key2D Diagram3D Interactions
GOL
Query on GOL

Download CCD File
A
GLYCEROL
C3 H8 O3
PEDCQBHIVMGVHV-UHFFFAOYSA-N
 Ligand Interaction
CA
Query on CA

Download CCD File
A
CALCIUM ION
Ca
BHPQYMZQTOCNFJ-UHFFFAOYSA-N
 Ligand Interaction
Experimental Data & Validation

Experimental Data

  • Method: X-RAY DIFFRACTION
  • Resolution: 1.60 Å
  • R-Value Free: 0.220
  • R-Value Work: 0.194
  • R-Value Observed: 0.195
  • Space Group: P 21 21 21
Unit Cell:
Length ( Å )Angle ( ˚ )
a = 53.141α = 90
b = 66.549β = 90
c = 144.053γ = 90
Software Package:
Software NamePurpose
ADSCdata collection
AutoSolphasing
REFMACrefinement
HKL-2000data reduction
HKL-2000data scaling

Structure Validation

View Full Validation Report



Entry History

Deposition Data

Revision History

  • Version 1.0: 2014-11-05
    Type: Initial release
  • Version 1.1: 2014-11-19
    Changes: Database references
