4OAW

Fab structure of anti-HIV gp120 V2 mAb 2158


Experimental Data Snapshot

  • Method: X-RAY DIFFRACTION
  • Resolution: 2.8 Å
  • R-Value Free: 0.254
  • R-Value Work: 0.182

wwPDB Validation 3D Report Full Report


This is version 1.2 of the entry. See complete history

Literature

Functional Implications of the Binding Mode of a Human Conformation-Dependent V2 Monoclonal Antibody against HIV.

Spurrier, B.Sampson, J.Gorny, M.K.Zolla-Pazner, S.Kong, X.P.

(2014) J.Virol. 88: 4100-4112

  • DOI: 10.1128/JVI.03153-13

  • PubMed Abstract:
  • Data from the RV144 HIV vaccine trial indicated that gp120 V2 antibodies were associated with a lower risk of infection; thus, the mapping of V2 epitopes can contribute to the design of an effective HIV vaccine. We solved the crystal structure of hum ...

    Data from the RV144 HIV vaccine trial indicated that gp120 V2 antibodies were associated with a lower risk of infection; thus, the mapping of V2 epitopes can contribute to the design of an effective HIV vaccine. We solved the crystal structure of human monoclonal antibody (MAb) 2158, which targets a conformational V2 epitope overlapping the α4β7 integrin binding site, and constructed a full-length model of V1V2. Comparison of computational energy stability to experimental enzyme-linked immunosorbent assay (ELISA) results identified a hydrophobic core that stabilizes the V2 region for optimal 2158 binding, as well as residues that directly mediate side chain interactions with MAb 2158. These data define the binding surface recognized by MAb 2158 and offer a structural explanation for why a mismatched mutation at position 181 (I181X) in the V2 loop was associated with a higher vaccine efficiency in the RV144 clinical vaccine trial.


    Organizational Affiliation

    Department of Biochemistry and Molecular Pharmacology, NYU School of Medicine, New York, New York, USA.




Macromolecules

Find similar proteins by: Sequence  |  Structure

Entity ID: 1
MoleculeChainsSequence LengthOrganismDetails
Light chain of Fab fragment of anti-HIV1 gp120 V2 mAb 2158
A, C
214N/AMutation(s): 0
Protein Feature View is not available: No corresponding UniProt sequence found.
Entity ID: 2
MoleculeChainsSequence LengthOrganismDetails
Heavy chain of Fab fragment of anti-HIV1 gp120 V2 mAb 2158
B, D
236N/AMutation(s): 0
Protein Feature View is not available: No corresponding UniProt sequence found.
Small Molecules
Ligands 2 Unique
IDChainsName / Formula / InChI Key2D Diagram3D Interactions
SO4
Query on SO4

Download SDF File
Download CCD File
A, B, C, D
SULFATE ION
O4 S
QAOWNCQODCNURD-UHFFFAOYSA-L
 Ligand Interaction
GOL
Query on GOL

Download SDF File
Download CCD File
B, D
GLYCEROL
GLYCERIN; PROPANE-1,2,3-TRIOL
C3 H8 O3
PEDCQBHIVMGVHV-UHFFFAOYSA-N
 Ligand Interaction
Experimental Data & Validation

Experimental Data

  • Method: X-RAY DIFFRACTION
  • Resolution: 2.8 Å
  • R-Value Free: 0.254
  • R-Value Work: 0.182
  • Space Group: P 32
Unit Cell:
Length (Å)Angle (°)
a = 73.710α = 90.00
b = 73.710β = 90.00
c = 215.950γ = 120.00
Software Package:
Software NamePurpose
Blu-Icedata collection
SCALAdata scaling
PHASERphasing
MOSFLMdata reduction
PHENIXrefinement

Structure Validation

View Full Validation Report or Ramachandran Plots



Entry History

Deposition Data

Revision History

  • Version 1.0: 2014-03-19
    Type: Initial release
  • Version 1.1: 2014-04-16
    Type: Database references
  • Version 1.2: 2017-11-22
    Type: Refinement description
