4O36

Semisynthetic RNase S1-15-H7/11-Q10

• PDB DOI: https://doi.org/10.2210/pdb4O36/pdb

• Classification: HYDROLASE
• Organism(s): Bos taurus
• Mutation(s): Yes


• Deposited: 2013-12-18 Released: 2014-05-07
• Deposition Author(s): Genz, M., Strater, N.

---

Experimental Data Snapshot

• Method: X-RAY DIFFRACTION
• Resolution: 1.22 Å
• R-Value Free: 0.226
• R-Value Work: 0.184
• R-Value Observed: 0.185

Literature

An Artificial Imine Reductase based on the Ribonuclease S scaffold

Genz, M., Koehler, V., Krauss, M., Singer, D., Hoffmann, R., Ward, T.R., Strater, N.

(2014) ChemCatChem

• DOI: https://doi.org/10.1002/cctc.201300995

Biological Assembly 1

Global Symmetry: Asymmetric - C1
Global Stoichiometry: Hetero 2-mer - A1B1

Biological assembly 1 assigned by authors and generated by PISA (software)

Macromolecule Content

• Total Structure Weight: 13.57 kDa
• Atom Count: 1,100
• Modelled Residue Count: 115
• Deposited Residue Count: 119
• Unique protein chains: 2

Macromolecules

Entity ID: 1
Molecule	Chains	Sequence Length	Organism	Details	Image
Ribonuclease pancreatic, S-peptide	A	15	Bos taurus	Mutation(s): 3  EC: 3.1.27.5
UniProt
Find proteins for P61823 (Bos taurus) Explore P61823  Go to UniProtKB:  P61823

Entity ID: 2
Molecule	Chains	Sequence Length	Organism	Details	Image
Ribonuclease pancreatic, S-protein	B	104	Bos taurus	Mutation(s): 0  EC: 3.1.27.5
UniProt
Find proteins for P61823 (Bos taurus) Explore P61823  Go to UniProtKB:  P61823

Small Molecules

Ligands 2 Unique
ID	Chains	Name / Formula / InChI Key	2D Diagram
SO4	C [auth B]	SULFATE ION O4 S QAOWNCQODCNURD-UHFFFAOYSA-L
CL	D [auth B], E [auth B], F [auth B], G [auth B], H [auth B]	CHLORIDE ION Cl VEXZGXHMUGYJMC-UHFFFAOYSA-M

Experimental Data & Validation

Experimental Data

• Method: X-RAY DIFFRACTION
• Resolution: 1.22 Å
• R-Value Free: 0.226
• R-Value Work: 0.184
• R-Value Observed: 0.185
• Space Group: P 3₁ 2 1

Unit Cell:

Length ( Å )	Angle ( ˚ )
a = 43.91	α = 90
b = 43.91	β = 90
c = 96.4	γ = 120

Software Package:

Software Name	Purpose
REFMAC	refinement
XDS	data reduction
XSCALE	data scaling

Structure Validation

Entry History

Deposition Data

• Released Date: 2014-05-07
Deposition Author(s): Genz, M., Strater, N.

Revision History

• Version 1.0: 2014-05-07
  Type: Initial release

• Version 1.1: 2017-11-22
  Changes: Refinement description
• Version 1.2: 2023-09-20
  Changes: Data collection, Database references, Derived calculations, Refinement description
