4NUN

Crystal structure of copper-bound Na-ASP-2


Experimental Data Snapshot

  • Method: X-RAY DIFFRACTION
  • Resolution: 2.20 Å
  • R-Value Free: 0.231
  • R-Value Work: 0.175
  • R-Value Observed: 0.178

wwPDB Validation 3D Report Full Report



Literature

Probing the equatorial groove of the hookworm protein and vaccine candidate antigen, Na-ASP-2.

Mason, L.Tribolet, L.Simon, A.von Gnielinski, N.Nienaber, L.Taylor, P.Willis, C.Jones, M.K.Sternberg, P.W.Gasser, R.B.Loukas, A.Hofmann, A.

(2014) Int J Biochem Cell Biol 50: 146-155

  • DOI: 10.1016/j.biocel.2014.03.003
  • Primary Citation of Related Structures:
    4NUK, 4NUN, 4NUO, 4NUI

  • PubMed Abstract:
  • Hookworm activation-associated secreted proteins can be structurally classified into at least three different groups. The hallmark feature of Group 1 activation-associated secreted proteins is a prominent equatorial groove, which is inferred to form ...

    Hookworm activation-associated secreted proteins can be structurally classified into at least three different groups. The hallmark feature of Group 1 activation-associated secreted proteins is a prominent equatorial groove, which is inferred to form a ligand binding site. Furthermore, a conserved tandem histidine motif is located in the centre of the groove and believed to provide or support a yet to be determined catalytic activity. Here, we report three-dimensional crystal structures of Na-ASP-2, an L3-secreted activation-associated secreted protein from the human hookworm Necator americanus, which demonstrate transition metal binding ability of the conserved tandem histidine motif. We further identified moderate phosphohydrolase activity of recombinant Na-ASP-2, which relates to the tandem histidine motif. By panning a random 12-mer peptide phage library, we identified a peptide with high similarity to the human calcium-activated potassium channel SK3, and confirm binding of the synthetic peptide to recombinant Na-ASP-2 by differential scanning fluorimetry. Potential binding modes of the peptide to Na-ASP-2 were studied by molecular dynamics simulations which clearly identify a preferred topology of the Na-ASP-2:SK3 peptide complex.


    Organizational Affiliation

    Structural Chemistry Program, Eskitis Institute, Griffith University, Brisbane, Queensland, Australia; Faculty of Veterinary Science, The University of Melbourne, Parkville, Victoria, Australia. Electronic address: a.hofmann@griffith.edu.au.



Macromolecules
Find similar proteins by:  (by identity cutoff)  |  Structure
Entity ID: 1
MoleculeChainsSequence LengthOrganismDetailsImage
Ancylostoma secreted protein 2A210Necator americanusMutation(s): 0
Gene Names: ASP2
Find proteins for J9ULM6 (Necator americanus)
Explore J9ULM6
Go to UniProtKB:  J9ULM6
Protein Feature View
Expand
 ( Mouse scroll to zoom / Hold left click to move )
  • Reference Sequence
Small Molecules
Ligands 1 Unique
IDChainsName / Formula / InChI Key2D Diagram3D Interactions
CU
Query on CU

Download CCD File
A
COPPER (II) ION
Cu
JPVYNHNXODAKFH-UHFFFAOYSA-N
 Ligand Interaction
Experimental Data & Validation

Experimental Data

  • Method: X-RAY DIFFRACTION
  • Resolution: 2.20 Å
  • R-Value Free: 0.231
  • R-Value Work: 0.175
  • R-Value Observed: 0.178
  • Space Group: P 1 21 1
Unit Cell:
Length ( Å )Angle ( ˚ )
a = 36.953α = 90
b = 51.267β = 93.96
c = 43.288γ = 90
Software Package:
Software NamePurpose
ADSCdata collection
PHENIXmodel building
PHASERphasing
PHENIXrefinement
XDSdata reduction
SCALAdata scaling
PHENIXphasing

Structure Validation

View Full Validation Report



Entry History

Deposition Data

  • Deposited Date: 2013-12-03
  • Released Date: 2014-05-14
  • Deposition Author(s): Hofmann, A.

Revision History

  • Version 1.0: 2014-05-14
    Type: Initial release
