4NPN

Crystal structure of human tetra-SUMO-2

Experimental Data Snapshot

  • Method: X-RAY DIFFRACTION
  • Resolution: 1.63 Å
  • R-Value Free: 0.218
  • R-Value Work: 0.198
  • R-Value Observed: 0.199

wwPDB Validation   3D Report Full Report


This is version 1.0 of the entry. See complete history.


Literature

Structural analysis of poly-SUMO chain recognition by the RNF4-SIMs domain.

Kung, C.C.-H., Naik, M.T., Wang, S.H., Shih, H.M., Chang, C.C., Lin, L.Y., Chen, C.L., Ma, C., Chang, C.F., Huang, T.H.

(2014) Biochem J 462: 53-65

  • DOI: 10.1042/BJ20140521
  • Primary Citation of Related Structures:
    4NPN

  • PubMed Abstract:

    • The E3 ubiquitin ligase RNF4 (RING finger protein 4) contains four tandem SIM [SUMO (small ubiquitin-like modifier)-interaction motif] repeats for selective interaction with poly-SUMO-modified proteins, which it targets for degradation. We employed a multi-faceted approach to characterize the structure of the RNF4-SIMs domain and the tetra-SUMO2 chain to elucidate the interaction between them ...

    The E3 ubiquitin ligase RNF4 (RING finger protein 4) contains four tandem SIM [SUMO (small ubiquitin-like modifier)-interaction motif] repeats for selective interaction with poly-SUMO-modified proteins, which it targets for degradation. We employed a multi-faceted approach to characterize the structure of the RNF4-SIMs domain and the tetra-SUMO2 chain to elucidate the interaction between them. In solution, the SIM domain was intrinsically disordered and the linkers of the tetra-SUMO2 were highly flexible. Individual SIMs of the RNF4-SIMs domains bind to SUMO2 in the groove between the β2-strand and the α1-helix parallel to the β2-strand. SIM2 and SIM3 bound to SUMO with a high affinity and together constituted the recognition module necessary for SUMO binding. SIM4 alone bound to SUMO with low affinity; however, its contribution to tetra-SUMO2 binding avidity is comparable with that of SIM3 when in the RNF4-SIMs domain. The SAXS data of the tetra-SUMO2-RNF4-SIMs domain complex indicate that it exists as an ordered structure. The HADDOCK model showed that the tandem RNF4-SIMs domain bound antiparallel to the tetra-SUMO2 chain orientation and wrapped around the SUMO protamers in a superhelical turn without imposing steric hindrance on either molecule.

    Organizational Affiliation:

    ¶Genomics Research Center, Academia Sinica, Taipei 11529, Taiwan.



Macromolecules
Find similar proteins by:
(by identity cutoff)  |  3D Structure
Entity ID: 1
MoleculeChainsSequence LengthOrganismDetailsImage
Small ubiquitin-related modifier 2A102Homo sapiensMutation(s): 0
Gene Names: SMT3A, SMT3H2, SUMO2, SUMO2 SMT3A SMT3H2, SMT3B
UniProt & NIH Common Fund Data Resources
Find proteins for P61956 (Homo sapiens)
Explore P61956
Go to UniProtKB:  P61956
PHAROS:  P61956
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupP61956
Protein Feature View
Expand
  • Reference Sequence
Experimental Data & Validation

Experimental Data

  • Method: X-RAY DIFFRACTION
  • Resolution: 1.63 Å
  • R-Value Free: 0.218
  • R-Value Work: 0.198
  • R-Value Observed: 0.199
  • Space Group: H 3
Unit Cell:
Length ( Å )Angle ( ˚ )
a = 75.123α = 90
b = 75.123β = 90
c = 33.116γ = 120
Software Package:
Software NamePurpose
HKL-2000data collection
SOLVEphasing
PHENIXrefinement
HKL-2000data reduction
HKL-2000data scaling

Structure Validation

View Full Validation Report



View more in-depth experimental data

Entry History

Deposition Data

Revision History  (Full details and data files)

  • Version 1.0: 2014-10-15
    Type: Initial release
