4NHU | pdb_00004nhu

The M33 TCR p3M33l/H-2 Ld Complex

PDB DOI: https://doi.org/10.2210/pdb4NHU/pdb

Classification: IMMUNE SYSTEM
Organism(s): Mus musculus, Homo sapiens
Expression System: Trichoplusia ni, Escherichia coli
Mutation(s): Yes

Deposited: 2013-11-05 Released: 2015-05-06
Deposition Author(s): Birnbaum, M.E., Adams, J.J., Garcia, K.C.

Experimental Data Snapshot

Method: X-RAY DIFFRACTION
Resolution: 2.90 Å
R-Value Free:
0.260 (Depositor), 0.261 (DCC)
R-Value Work:
0.229 (Depositor), 0.230 (DCC)
R-Value Observed:
0.231 (Depositor)

wwPDB Validation 3D Report Full Report

Validation slider image for 4NHU

This is version 1.1 of the entry. See complete history.

Literature

Interrogating TCR Signal Strength and Cross-Reactivity by Yeast Display of pMHC

Birnbaum, M.E., Adams, J.J., Garcia, K.C.

To be published.

Macromolecule Content

Total Structure Weight: 150.89 kDa
Atom Count: 9,829
Modeled Residue Count: 1,243
Deposited Residue Count: 1,354
Unique protein chains: 3

Macromolecules

Find similar proteins by:

Entity ID: 1
Molecule	Chains	Sequence Length	Organism	Details	Image
2C m33 alpha VmCh chimera	A, D [auth C]	219	Mus musculus, Homo sapiens This entity is chimeric	Mutation(s): 0
UniProt & NIH Common Fund Data Resources
Find proteins for P01738 (Mus musculus) Explore P01738 Go to UniProtKB: P01738
Find proteins for P01848 (Homo sapiens) Explore P01848 Go to UniProtKB: P01848
PHAROS: P01848
Entity Groups
Sequence Clusters	30% Identity 50% Identity 70% Identity 90% Identity 95% Identity 100% Identity
UniProt Groups	P01738 P01848
Sequence Annotations Expand
Reference Sequence

Find similar proteins by:

Entity ID: 2
Molecule	Chains	Sequence Length	Organism	Details	Image
2C m33 beta VmCh chimera	B, E [auth D]	254	Mus musculus, Homo sapiens This entity is chimeric	Mutation(s): 0
UniProt & NIH Common Fund Data Resources
Find proteins for A0A5B9 (Homo sapiens) Explore A0A5B9 Go to UniProtKB: A0A5B9
PHAROS: A0A5B9
Find proteins for P04213 (Mus musculus) Explore P04213 Go to UniProtKB: P04213
Entity Groups
Sequence Clusters	30% Identity 50% Identity 70% Identity 90% Identity 95% Identity 100% Identity
UniProt Groups	P04213 A0A5B9
Sequence Annotations Expand
Reference Sequence

Find similar proteins by:

Entity ID: 3
Molecule	Chains	Sequence Length	Organism	Details	Image
H-2 class I histocompatibility antigen, L-D alpha chain	C [auth E], F [auth G]	204	Mus musculus	Mutation(s): 6 Gene Names: H2-L
UniProt
Find proteins for P01897 (Mus musculus) Explore P01897 Go to UniProtKB: P01897
Entity Groups
Sequence Clusters	30% Identity 50% Identity 70% Identity 90% Identity 95% Identity 100% Identity
UniProt Group	P01897
Sequence Annotations Expand
Reference Sequence

Experimental Data & Validation

Experimental Data

Method: X-RAY DIFFRACTION
Resolution: 2.90 Å
R-Value Free: 0.260 (Depositor), 0.261 (DCC)
R-Value Work: 0.229 (Depositor), 0.230 (DCC)
R-Value Observed: 0.231 (Depositor)

Space Group: P 1

Unit Cell:

Length ( Å )	Angle ( ˚ )
a = 49.76	α = 112.29
b = 92.8	β = 103.57
c = 94.95	γ = 102.37

Software Package:

Software Name	Purpose
Blu-Ice	data collection
PHASER	phasing
PHENIX	refinement
MOSFLM	data reduction
SCALA	data scaling

Structure Validation

View Full Validation Report

View more in-depth experimental data

Entry History

Deposition Data

Released Date: 2015-05-06

Deposition Author(s):

Revision History (Full details and data files)

Version 1.0: 2015-05-06
Type: Initial release
Version 1.1: 2024-11-20
Changes: Data collection, Database references, Structure summary
