4N04 | pdb_00004n04

The crystal structure of glyoxalase / bleomycin resistance protein from Catenulispora Acidiphila DSM 44928

• PDB DOI: https://doi.org/10.2210/pdb4N04/pdb

• Classification: OXIDOREDUCTASE
• Organism(s): Catenulispora acidiphila DSM 44928
• Expression System: Escherichia coli BL21(DE3)
• Mutation(s): Yes


• Deposited: 2013-09-30 Released: 2013-12-25
• Deposition Author(s): Wu, R., Jedrzejczak, R., Joachimiak, A., Midwest Center for Structural Genomics (MCSG)

---

Experimental Data Snapshot

• Method: X-RAY DIFFRACTION
• Resolution: 2.49 Å
• R-Value Free:
  0.227 (Depositor), 0.229 (DCC)
• R-Value Work:
  0.176 (Depositor), 0.177 (DCC)
• R-Value Observed:
  0.179 (Depositor)

Literature

The crystal structure of glyoxalase / bleomycin resistance protein from catenulispora acidiphila dsm 44928

Wu, R., Jedrzejczak, R., Joachimiak, A., Midwest Center for Structural Genomics (MCSG)

To be published.

Biological Assembly 1

Global Symmetry: Asymmetric - C1
Global Stoichiometry: Monomer - A1

Biological assembly 1 assigned by authors.

Biological Assembly 2

Global Symmetry: Asymmetric - C1
Global Stoichiometry: Monomer - A1

Biological assembly 2 assigned by authors.

Biological Assembly 3

Global Symmetry: Cyclic - C2  (Explore in 3D)
Global Stoichiometry: Homo 2-mer - A2

Biological assembly 3 generated by PISA (software)

Macromolecule Content

• Total Structure Weight: 26.03 kDa
• Atom Count: 1,775
• Modeled Residue Count: 221
• Deposited Residue Count: 232
• Unique protein chains: 1

Macromolecules

Entity ID: 1
Molecule	Chains	Sequence Length	Organism	Details	Image
Glyoxalase/bleomycin resistance protein/dioxygenase	A, B	116	Catenulispora acidiphila DSM 44928	Mutation(s): 1  Gene Names: Caci_7252
UniProt
Find proteins for C7Q893 (Catenulispora acidiphila (strain DSM 44928 / JCM 14897 / NBRC 102108 / NRRL B-24433 / ID139908)) Explore C7Q893  Go to UniProtKB:  C7Q893

Small Molecules

Ligands 2 Unique
ID	Chains	Name / Formula / InChI Key	2D Diagram
NHE	C [auth A], D [auth B]	2-[N-CYCLOHEXYLAMINO]ETHANE SULFONIC ACID C8 H17 N O3 S MKWKNSIESPFAQN-UHFFFAOYSA-N
GOL	E [auth B], F [auth B]	GLYCEROL C3 H8 O3 PEDCQBHIVMGVHV-UHFFFAOYSA-N

Modified Residues  1 Unique
ID	Chains	Type	Formula	2D Diagram	Parent
MSE	A, B	L-PEPTIDE LINKING	C5 H11 N O2 Se		MET

Experimental Data & Validation

Experimental Data

• Method: X-RAY DIFFRACTION
• Resolution: 2.49 Å
• R-Value Free:  0.227 (Depositor), 0.229 (DCC)
• R-Value Work:  0.176 (Depositor), 0.177 (DCC)
• R-Value Observed: 0.179 (Depositor)

Space Group: I 2₁ 3

Unit Cell:

Length ( Å )	Angle ( ˚ )
a = 123.6	α = 90
b = 123.6	β = 90
c = 123.6	γ = 90

Software Package:

Software Name	Purpose
HKL-3000	data collection
MLPHARE	phasing
PHENIX	refinement
HKL-3000	data reduction
HKL-3000	data scaling

Structure Validation

Entry History

Deposition Data

• Released Date: 2013-12-25
Deposition Author(s): Wu, R., Jedrzejczak, R., Joachimiak, A., Midwest Center for Structural Genomics (MCSG)

Revision History

• Version 1.0: 2013-12-25
  Type: Initial release

• Version 1.1: 2024-10-16
  Changes: Data collection, Database references, Derived calculations, Structure summary
