4MNU | pdb_00004mnu

Crystal Structure of Uncharacterized SlyA-like Transcription Regulator from Listeria monocytogenes

• PDB DOI: https://doi.org/10.2210/pdb4MNU/pdb

• Classification: TRANSCRIPTION REGULATOR
• Organism(s): Listeria monocytogenes EGD-e
• Expression System: Escherichia coli BL21
• Mutation(s): No


• Deposited: 2013-09-11 Released: 2013-09-25
• Deposition Author(s): Kim, Y., Tesar, C., Clancy, S., Joachimiak, A., Midwest Center for Structural Genomics (MCSG)

---

Experimental Data Snapshot

• Method: X-RAY DIFFRACTION
• Resolution: 1.90 Å
• R-Value Free:
  0.222 (Depositor), 0.221 (DCC)
• R-Value Work:
  0.179 (Depositor), 0.180 (DCC)
• R-Value Observed:
  0.181 (Depositor)

Literature

Crystal Structure of Uncharacterized SlyA-like Transcription Regulator from Listeria monocytogenes

Kim, Y., Tesar, C., Clancy, S., Joachimiak, A., Midwest Center for Structural Genomics (MCSG)

To be published.

Biological Assembly 1

Global Symmetry: Cyclic - C2  (Explore in 3D)
Global Stoichiometry: Homo 2-mer - A2

Biological assembly 1 assigned by authors and generated by PISA (software)

Macromolecule Content

• Total Structure Weight: 36.09 kDa
• Atom Count: 2,826
• Modeled Residue Count: 301
• Deposited Residue Count: 306
• Unique protein chains: 1

Macromolecules

Entity ID: 1
Molecule	Chains	Sequence Length	Organism	Details	Image
SlyA-like transcription regulator	A, B	153	Listeria monocytogenes EGD-e	Mutation(s): 0  Gene Names: lmo0815
UniProt
Find proteins for Q8Y8S9 (Listeria monocytogenes serovar 1/2a (strain ATCC BAA-679 / EGD-e)) Explore Q8Y8S9  Go to UniProtKB:  Q8Y8S9

Small Molecules

Ligands 2 Unique
ID	Chains	Name / Formula / InChI Key	2D Diagram
SO4	C [auth A], D [auth A], E [auth A], F [auth B], H [auth B], I [auth B], J [auth B]	SULFATE ION O4 S QAOWNCQODCNURD-UHFFFAOYSA-L
GOL	G [auth B]	GLYCEROL C3 H8 O3 PEDCQBHIVMGVHV-UHFFFAOYSA-N

Modified Residues  1 Unique
ID	Chains	Type	Formula	2D Diagram	Parent
MSE	A, B	L-PEPTIDE LINKING	C5 H11 N O2 Se		MET

Experimental Data & Validation

Experimental Data

• Method: X-RAY DIFFRACTION
• Resolution: 1.90 Å
• R-Value Free:  0.222 (Depositor), 0.221 (DCC)
• R-Value Work:  0.179 (Depositor), 0.180 (DCC)
• R-Value Observed: 0.181 (Depositor)

Space Group: P 2₁ 2₁ 2₁

Unit Cell:

Length ( Å )	Angle ( ˚ )
a = 46.155	α = 90
b = 84.362	β = 90
c = 94.856	γ = 90

Software Package:

Software Name	Purpose
SBC-Collect	data collection
HKL-3000	data collection
HKL-3000	phasing
SHELXS	phasing
MLPHARE	phasing
DM	model building
MOLREP	phasing
PHENIX	refinement
HKL-3000	data reduction
HKL-3000	data scaling
DM	phasing

Structure Validation

Entry History

Deposition Data

• Released Date: 2013-09-25
Deposition Author(s): Kim, Y., Tesar, C., Clancy, S., Joachimiak, A., Midwest Center for Structural Genomics (MCSG)

Revision History

• Version 1.0: 2013-09-25
  Type: Initial release

• Version 1.1: 2024-11-27
  Changes: Data collection, Database references, Derived calculations, Structure summary
