4MKI

Cobalt transporter ATP-binding subunit


Experimental Data Snapshot

  • Method: X-RAY DIFFRACTION
  • Resolution: 2.30 Å
  • R-Value Free: 0.251
  • R-Value Work: 0.200
  • R-Value Observed: 0.202

wwPDB Validation   3D Report Full Report


Ligand Structure Quality Assessment


This is version 1.1 of the entry. See complete history


Literature

Structural basis for a homodimeric ATPase subunit of an ECF transporter

Chai, C.L.Yu, Y.Zhuo, W.Zhao, H.Li, X.Wang, N.Chai, J.Yang, M.

(2013) Protein Cell 4: 793-801

  • DOI: 10.1007/s13238-013-3915-y
  • Primary Citation of Related Structures:
    4MKI

  • PubMed Abstract:
  • The transition metal cobalt, an essential cofactor for many enzymes in prokaryotes, is taken up by several specific transport systems. The CbiMNQO protein complex belongs to type-1 energy-coupling factor (ECF) transporters and is a widespread group of microbial cobalt transporters ...

    The transition metal cobalt, an essential cofactor for many enzymes in prokaryotes, is taken up by several specific transport systems. The CbiMNQO protein complex belongs to type-1 energy-coupling factor (ECF) transporters and is a widespread group of microbial cobalt transporters. CbiO is the ATPase subunit (A-component) of the cobalt transporting system in the gram-negative thermophilic bacterium Thermoanaerobacter tengcongensis. Here we report the crystal structure of a nucleotide-free CbiO at a resolution of 2.3 Å. CbiO contains an N-terminal canonical nucleotide-binding domain (NBD) and C-terminal helical domain. Structural and biochemical data show that CbiO forms a homodimer mediated by the NBD and the C-terminal domain. Interactions mainly via conserved hydrophobic amino acids between the two C-terminal domains result in formation of a four-helix bundle. Structural comparison with other ECF transporters suggests that non-conserved residues outside the T-component binding groove in the A component likely act as a specificity determinant for T components. Together, our data provide information on understanding of the structural organization and interaction of the CbiMNQO system.


    Organizational Affiliation

    College of Biological Sciences, China Agricultural University, Beijing, 100083, China.



Macromolecules
Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 1
MoleculeChainsSequence LengthOrganismDetailsImage
Energy-coupling factor transporter ATP-binding protein EcfA2B [auth A],
A [auth B]
298Caldanaerobacter subterraneus subsp. tengcongensis MB4Mutation(s): 0
Gene Names: ecfA2cbiO2TTE2260
EC: 3.6.3
UniProt
Find proteins for Q8R7Y5 (Caldanaerobacter subterraneus subsp. tengcongensis (strain DSM 15242 / JCM 11007 / NBRC 100824 / MB4))
Explore Q8R7Y5
Go to UniProtKB:  Q8R7Y5
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupQ8R7Y5
Protein Feature View
Expand
  • Reference Sequence
Small Molecules
Ligands 2 Unique
IDChainsName / Formula / InChI Key2D Diagram3D Interactions
LMT
Query on LMT

Download Ideal Coordinates CCD File
D [auth B],
G [auth A]
DODECYL-BETA-D-MALTOSIDE
C24 H46 O11
NLEBIOOXCVAHBD-QKMCSOCLSA-N
 Ligand Interaction
SO4
Query on SO4

Download Ideal Coordinates CCD File
C [auth B],
E [auth A],
F [auth A]
SULFATE ION
O4 S
QAOWNCQODCNURD-UHFFFAOYSA-L
 Ligand Interaction
Experimental Data & Validation

Experimental Data

  • Method: X-RAY DIFFRACTION
  • Resolution: 2.30 Å
  • R-Value Free: 0.251
  • R-Value Work: 0.200
  • R-Value Observed: 0.202
  • Space Group: P 21 21 2
Unit Cell:
Length ( Å )Angle ( ˚ )
a = 110.229α = 90
b = 115.163β = 90
c = 54.416γ = 90
Software Package:
Software NamePurpose
CBASSdata collection
PHASESphasing
REFMACrefinement
HKL-2000data reduction
HKL-2000data scaling

Structure Validation

View Full Validation Report



Ligand Structure Quality Assessment


Entry History

Deposition Data

Revision History  (Full details and data files)

  • Version 1.0: 2013-10-30
    Type: Initial release
  • Version 1.1: 2014-06-11
    Changes: Structure summary
