4M14

Crystal structure of ITK in complex with compound 9 [4-(carbamoylamino)-1-[7-(propan-2-yloxy)naphthalen-1-yl]-1H-pyrazole-3-carboxamide]


Experimental Data Snapshot

  • Method: X-RAY DIFFRACTION
  • Resolution: 1.55 Å
  • R-Value Free: 0.189
  • R-Value Work: 0.165
  • R-Value Observed: 0.166

wwPDB Validation   3D Report Full Report


Ligand Structure Quality Assessment


This is version 1.1 of the entry. See complete history


Literature

Selectively targeting an inactive conformation of interleukin-2-inducible T-cell kinase by allosteric inhibitors.

Han, S.Czerwinski, R.M.Caspers, N.L.Limburg, D.C.Ding, W.Wang, H.Ohren, J.F.Rajamohan, F.McLellan, T.J.Unwalla, R.Choi, C.Parikh, M.D.Seth, N.Edmonds, J.Phillips, C.Shakya, S.Li, X.Spaulding, V.Hughes, S.Cook, A.Robinson, C.Mathias, J.P.Navratilova, I.Medley, Q.G.Anderson, D.R.Kurumbail, R.G.Aulabaugh, A.

(2014) Biochem J 460: 211-222

  • DOI: 10.1042/BJ20131139
  • Primary Citation of Related Structures:
    4M0Y, 4M0Z, 4M12, 4M13, 4M14, 4M15

  • PubMed Abstract:
  • ITK (interleukin-2-inducible T-cell kinase) is a critical component of signal transduction in T-cells and has a well-validated role in their proliferation, cytokine release and chemotaxis. ITK is an attractive target for the treatment of T-cell-mediated inflammatory diseases ...

    ITK (interleukin-2-inducible T-cell kinase) is a critical component of signal transduction in T-cells and has a well-validated role in their proliferation, cytokine release and chemotaxis. ITK is an attractive target for the treatment of T-cell-mediated inflammatory diseases. In the present study we describe the discovery of kinase inhibitors that preferentially bind to an allosteric pocket of ITK. The novel ITK allosteric site was characterized by NMR, surface plasmon resonance, isothermal titration calorimetry, enzymology and X-ray crystallography. Initial screening hits bound to both the allosteric pocket and the ATP site. Successful lead optimization was achieved by improving the contribution of the allosteric component to the overall inhibition. NMR competition experiments demonstrated that the dual-site binders showed higher affinity for the allosteric site compared with the ATP site. Moreover, an optimized inhibitor displayed non-competitive inhibition with respect to ATP as shown by steady-state enzyme kinetics. The activity of the isolated kinase domain and auto-activation of the full-length enzyme were inhibited with similar potency. However, inhibition of the activated full-length enzyme was weaker, presumably because the allosteric site is altered when ITK becomes activated. An optimized lead showed exquisite kinome selectivity and is efficacious in human whole blood and proximal cell-based assays.


    Organizational Affiliation

    *Pfizer Worldwide Research, Eastern Point Road, Groton, CT 06340, U.S.A.



Macromolecules
Find similar proteins by:  (by identity cutoff)  |  Structure
Entity ID: 1
MoleculeChainsSequence LengthOrganismDetailsImage
Tyrosine-protein kinase ITK/TSKA269Homo sapiensMutation(s): 0
Gene Names: ITKEMTLYK
EC: 2.7.10.2
UniProt & NIH Common Fund Data Resources
Find proteins for Q08881 (Homo sapiens)
Explore Q08881
Go to UniProtKB:  Q08881
PHAROS:  Q08881
Protein Feature View
Expand
  • Reference Sequence
Small Molecules
Ligands 1 Unique
IDChainsName / Formula / InChI Key2D Diagram3D Interactions
QWS (Subject of Investigation/LOI)
Query on QWS

Download Ideal Coordinates CCD File
B [auth A], C [auth A]4-(carbamoylamino)-1-[7-(propan-2-yloxy)naphthalen-1-yl]-1H-pyrazole-3-carboxamide
C18 H19 N5 O3
GYKHVLWAQGEZTM-UHFFFAOYSA-N
 Ligand Interaction
Experimental Data & Validation

Experimental Data

  • Method: X-RAY DIFFRACTION
  • Resolution: 1.55 Å
  • R-Value Free: 0.189
  • R-Value Work: 0.165
  • R-Value Observed: 0.166
  • Space Group: P 1 21 1
Unit Cell:
Length ( Å )Angle ( ˚ )
a = 40.41α = 90
b = 68.94β = 106.75
c = 49.51γ = 90
Software Package:
Software NamePurpose
AutoPROCdata collection
BUSTERrefinement
AutoPROCdata scaling
BUSTERphasing

Structure Validation

View Full Validation Report



Ligand Structure Quality Assessment



Entry History

Deposition Data

  • Deposited Date: 2013-08-02
  • Released Date: 2014-04-02
  • Deposition Author(s): Han, S., Caspers, N.L.

Revision History  (Full details and data files)

  • Version 1.0: 2014-04-02
    Type: Initial release
  • Version 1.1: 2014-06-04
    Changes: Database references
