Crystal structure of human FPPS in complex with CL01131

Experimental Data Snapshot

  • Resolution: 2.35 Å
  • R-Value Free: 0.230
  • R-Value Work: 0.182
  • R-Value Observed: 0.184

wwPDB Validation   3D Report Full Report

Ligand Structure Quality Assessment

This is version 1.2 of the entry. See complete history


Multistage screening reveals chameleon ligands of the human farnesyl pyrophosphate synthase: implications to drug discovery for neurodegenerative diseases.

De Schutter, J.W.Park, J.Leung, C.Y.Gormley, P.Lin, Y.S.Hu, Z.Berghuis, A.M.Poirier, J.Tsantrizos, Y.S.

(2014) J Med Chem 57: 5764-5776

  • DOI: https://doi.org/10.1021/jm500629e
  • Primary Citation of Related Structures:
    4LPG, 4LPH

  • PubMed Abstract:

    Human farnesyl pyrophosphate synthase (hFPPS) is the gate-keeper of mammalian isoprenoids and the key target of bisphosphonate drugs. Bisphosphonates suffer from poor "drug-like" properties and are mainly effective in treating skeletal diseases. Recent investigations have implicated hFPPS in various nonskeletal diseases, including Alzheimer's disease (AD). Analysis of single nucleotide polymorphisms in the hFPPS gene and mRNA levels in autopsy-confirmed AD subjects was undertaken, and a genetic link between hFPPS and phosphorylated tau (P-Tau) levels in the human brain was identified. Elevated P-Tau levels are strongly implicated in AD progression. The development of nonbisphosphonate inhibitors can provide molecular tools for validating hFPPS as a therapeutic target for tauopathy-associated neurodegeneration. A multistage screening protocol led to the identification of a new monophosphonate chemotype that bind in an allosteric pocket of hFPPS. Optimization of these compounds could lead to human therapeutics that block tau metabolism and arrest the progression of neurodegeneration.

  • Organizational Affiliation

    Department of Chemistry, McGill University , 801 Sherbrooke Street West, Montreal, Quebec H3A 0B8, Canada.

Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 1
MoleculeChains Sequence LengthOrganismDetailsImage
Farnesyl pyrophosphate synthaseA [auth F]375Homo sapiensMutation(s): 0
Gene Names: FDPSFPSKIAA1293
EC: (PDB Primary Data), (PDB Primary Data)
UniProt & NIH Common Fund Data Resources
Find proteins for P14324 (Homo sapiens)
Explore P14324
Go to UniProtKB:  P14324
PHAROS:  P14324
GTEx:  ENSG00000160752
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupP14324
Sequence Annotations
  • Reference Sequence
Small Molecules
Ligands 2 Unique
IDChains Name / Formula / InChI Key2D Diagram3D Interactions
Query on 1MV

Download Ideal Coordinates CCD File
C [auth F]({[6-(4-methylphenyl)thieno[2,3-d]pyrimidin-4-yl]amino}methanediyl)bis(phosphonic acid)
C14 H15 N3 O6 P2 S
Query on PO4

Download Ideal Coordinates CCD File
O4 P
Binding Affinity Annotations
IDSourceBinding Affinity
1MV BindingDB:  4LPG Kd: 3200 (nM) from 1 assay(s)
IC50: min: 22, max: 390 (nM) from 3 assay(s)
Binding MOAD:  4LPG Kd: 5.56e+4 (nM) from 1 assay(s)
Experimental Data & Validation

Experimental Data

  • Resolution: 2.35 Å
  • R-Value Free: 0.230
  • R-Value Work: 0.182
  • R-Value Observed: 0.184
  • Space Group: P 41 21 2
Unit Cell:
Length ( Å )Angle ( ˚ )
a = 110.87α = 90
b = 110.87β = 90
c = 77.03γ = 90
Software Package:
Software NamePurpose
MxDCdata collection
XDSdata reduction
XSCALEdata scaling

Structure Validation

View Full Validation Report

Ligand Structure Quality Assessment

Entry History

Deposition Data

Revision History  (Full details and data files)

  • Version 1.0: 2014-06-25
    Type: Initial release
  • Version 1.1: 2014-07-23
    Changes: Database references
  • Version 1.2: 2023-09-20
    Changes: Data collection, Database references, Derived calculations, Refinement description
