4KI7

Design and structural analysis of aromatic inhibitors of type II dehydroquinase from Mycobacterium tuberculosis - compound 41c [3-hydroxy-5-(3-nitrophenoxy)benzoic acid]


Experimental Data Snapshot

  • Method: X-RAY DIFFRACTION
  • Resolution: 2.80 Å
  • R-Value Free: 0.278
  • R-Value Work: 0.188
  • R-Value Observed: 0.193

wwPDB Validation   3D Report Full Report


Ligand Structure Quality Assessment


This is version 1.1 of the entry. See complete history


Literature

Design and Structural Analysis of Aromatic Inhibitors of Type II Dehydroquinase from Mycobacterium tuberculosis.

Howard, N.I.Dias, M.V.Peyrot, F.Chen, L.Schmidt, M.F.Blundell, T.L.Abell, C.

(2015) ChemMedChem 10: 116-133

  • DOI: 10.1002/cmdc.201402298
  • Primary Citation of Related Structures:
    4KI7, 4KIJ, 4KIU, 4KIW

  • PubMed Abstract:
  • 3-Dehydroquinase, the third enzyme in the shikimate pathway, is a potential target for drugs against tuberculosis. Whilst a number of potent inhibitors of the Mycobacterium tuberculosis enzyme based on a 3-dehydroquinate core have been identified, they generally show little or no in vivo activity, and were synthetically complex to prepare ...

    3-Dehydroquinase, the third enzyme in the shikimate pathway, is a potential target for drugs against tuberculosis. Whilst a number of potent inhibitors of the Mycobacterium tuberculosis enzyme based on a 3-dehydroquinate core have been identified, they generally show little or no in vivo activity, and were synthetically complex to prepare. This report describes studies to develop tractable and drug-like aromatic analogues of the most potent inhibitors. A range of carbon-carbon linked biaryl analogues were prepared to investigate the effect of hydrogen bond acceptor and donor patterns on inhibition. These exhibited inhibitory activity in the high-micromolar range. The addition of flexible linkers in the compounds led to the identification of more potent 3-nitrobenzylgallate- and 5-aminoisophthalate-based analogues.


    Organizational Affiliation

    Department of Chemistry, University of Cambridge, Lensfield Road, Cambridge CB2 1EW (UK).



Macromolecules
Find similar proteins by:  (by identity cutoff)  |  Structure
Entity ID: 1
MoleculeChainsSequence LengthOrganismDetailsImage
3-dehydroquinate dehydratase
A, B, C, D, E, F, G, H
A, B, C, D, E, F, G, H, I, J, K, L, M, N, O, P, Q, R, S, T, U, V, W, X
153Mycobacterium tuberculosisMutation(s): 0
Gene Names: aroDaroKaroQMT2612MTCY159.19Rv2537c
EC: 4.2.1.10
UniProt
Find proteins for P9WPX7 (Mycobacterium tuberculosis (strain ATCC 25618 / H37Rv))
Explore P9WPX7
Go to UniProtKB:  P9WPX7
Protein Feature View
Expand
  • Reference Sequence
Small Molecules
Ligands 1 Unique
IDChainsName / Formula / InChI Key2D Diagram3D Interactions
1R2 (Subject of Investigation/LOI)
Query on 1R2

Download Ideal Coordinates CCD File
AA [auth C] , BA [auth D] , CA [auth E] , DA [auth F] , EA [auth G] , FA [auth H] , GA [auth I] , HA [auth J] ,
AA [auth C], BA [auth D], CA [auth E], DA [auth F], EA [auth G], FA [auth H], GA [auth I], HA [auth J], IA [auth K], JA [auth L], KA [auth N], LA [auth O], MA [auth P], NA [auth R], OA [auth S], PA [auth T], QA [auth U], RA [auth V], SA [auth W], TA [auth X], Y [auth A], Z [auth B]
3-hydroxy-5-(3-nitrophenoxy)benzoic acid
C13 H9 N O6
KGFXJYALKCBPSP-UHFFFAOYSA-N
 Ligand Interaction
Experimental Data & Validation

Experimental Data

  • Method: X-RAY DIFFRACTION
  • Resolution: 2.80 Å
  • R-Value Free: 0.278
  • R-Value Work: 0.188
  • R-Value Observed: 0.193
  • Space Group: P 1 21 1
Unit Cell:
Length ( Å )Angle ( ˚ )
a = 96.74α = 90
b = 139.69β = 96.43
c = 143.81γ = 90
Software Package:
Software NamePurpose
REFMACrefinement
PDB_EXTRACTdata extraction
MAR345dtbdata collection
MOSFLMdata reduction
SCALAdata scaling
AMoREphasing

Structure Validation

View Full Validation Report



Ligand Structure Quality Assessment



Entry History

Deposition Data

Revision History  (Full details and data files)

  • Version 1.0: 2014-05-14
    Type: Initial release
  • Version 1.1: 2015-01-07
    Changes: Database references
