1.65A structure of the T3SS tip protein LcrV (G28-D322, C273S) from Yersinia pestis

Experimental Data Snapshot

  • Resolution: 1.65 Å
  • R-Value Free: 0.220
  • R-Value Work: 0.177
  • R-Value Observed: 0.179

wwPDB Validation   3D Report Full Report

This is version 1.2 of the entry. See complete history


Structure of the Yersinia pestis tip protein LcrV refined to 1.65A resolution

Chaudhury, S.Battaile, K.P.Lovell, S.Plano, G.V.De Guzman, R.N.

(2013) Acta Crystallogr Sect F Struct Biol Cryst Commun 69: 477-481

  • DOI: https://doi.org/10.1107/S1744309113008579
  • Primary Citation of Related Structures:

  • PubMed Abstract:

    The human pathogen Yersinia pestis requires the assembly of the type III secretion system (T3SS) for virulence. The structural component of the T3SS contains an external needle and a tip complex, which is formed by LcrV in Y. pestis. The structure of an LcrV triple mutant (K40A/D41A/K42A) in a C273S background has previously been reported to 2.2 Å resolution. Here, the crystal structure of LcrV without the triple mutation in a C273S background is reported at a higher resolution of 1.65 Å. Overall the two structures are similar, but there are also notable differences, particularly near the site of the triple mutation. The refined structure revealed a slight shift in the backbone positions of residues Gly28-Asn43 and displayed electron density in the loop region consisting of residues Ile46-Val63, which was disordered in the original structure. In addition, the helical turn region spanning residues Tyr77-Gln95 adopts a different orientation.

  • Organizational Affiliation

    Department of Molecular Biosciences, University of Kansas, Lawrence, KS 66045, USA.

Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 1
MoleculeChains Sequence LengthOrganismDetailsImage
Virulence-associated V antigen298Yersinia pestisMutation(s): 1
Find proteins for P0C7U7 (Yersinia pestis)
Explore P0C7U7
Go to UniProtKB:  P0C7U7
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupP0C7U7
Sequence Annotations
  • Reference Sequence
Small Molecules
Ligands 1 Unique
IDChains Name / Formula / InChI Key2D Diagram3D Interactions
Query on PG4

Download Ideal Coordinates CCD File
C8 H18 O5
Experimental Data & Validation

Experimental Data

  • Resolution: 1.65 Å
  • R-Value Free: 0.220
  • R-Value Work: 0.177
  • R-Value Observed: 0.179
  • Space Group: P 1 21 1
Unit Cell:
Length ( Å )Angle ( ˚ )
a = 39.553α = 90
b = 51.442β = 92
c = 65.178γ = 90
Software Package:
Software NamePurpose
SCALAdata scaling
PDB_EXTRACTdata extraction
XSCALEdata scaling

Structure Validation

View Full Validation Report

Entry History

Deposition Data

Revision History  (Full details and data files)

  • Version 1.0: 2013-05-08
    Type: Initial release
  • Version 1.1: 2013-07-10
    Changes: Database references
  • Version 1.2: 2023-09-20
    Changes: Data collection, Database references, Derived calculations, Refinement description
