4I78

Crystal structure of a subtype H17 hemagglutinin homologue from A/little yellow-shouldered bat/Guatemala/060/2010 (H17N10)


Experimental Data Snapshot

  • Method: X-RAY DIFFRACTION
  • Resolution: 3.18 Å
  • R-Value Free: 0.258
  • R-Value Work: 0.203
  • R-Value Observed: 0.205

wwPDB Validation   3D Report Full Report



Literature

Hemagglutinin homologue from H17N10 bat influenza virus exhibits divergent receptor-binding and pH-dependent fusion activities.

Zhu, X.Yu, W.McBride, R.Li, Y.Chen, L.M.Donis, R.O.Tong, S.Paulson, J.C.Wilson, I.A.

(2013) Proc Natl Acad Sci U S A 110: 1458-1463

  • DOI: 10.1073/pnas.1218509110
  • Primary Citation of Related Structures:
    4I78

  • PubMed Abstract:
  • Bat influenza virus H17N10 represents a distinct lineage of influenza A viruses with gene segments coding for proteins that are homologs of the surface antigens, hemagglutinin (HA) and neuraminidase (NA). Our recent study of the N10 NA homolog reveal ...

    Bat influenza virus H17N10 represents a distinct lineage of influenza A viruses with gene segments coding for proteins that are homologs of the surface antigens, hemagglutinin (HA) and neuraminidase (NA). Our recent study of the N10 NA homolog revealed an NA-like structure, but with a highly divergent putative active site exhibiting little or no NA activity, and provided strong motivation for performing equivalent structural and functional analyses of the H17 HA protein. The overall structure of the H17 HA homolog from A/little yellow-shouldered bat/Guatemala/060/2010 at 3.18 Å resolution is very similar to other influenza HAs, with a putative receptor-binding site containing some conserved aromatic residues that form the base of the sialic acid binding site. However, the rest of the H17 receptor-binding site differs substantially from the other HA subtypes, including substitution of other conserved residues associated with receptor binding. Significantly, electrostatic potential analyses reveal that this putative receptor-binding site is highly acidic, making it unfavorable to bind any negatively charged sialylated receptors, consistent with the recombinant H17 protein exhibiting no detectable binding to sialylated glycans. Furthermore, the fusion mechanism is also distinct; trypsin digestion with recombinant H17 protein, when exposed to pH 4.0, did not degrade the HA1 and HA2, in contrast to other HAs. These distinct structural features and functional differences suggest that the H17 HA behaves very differently compared with other influenza HAs.


    Organizational Affiliation

    Department of Molecular Biology, Skaggs Institute for Chemical Biology, The Scripps Research Institute, La Jolla, CA 92037, USA.



Macromolecules
Find similar proteins by:  (by identity cutoff)  |  Structure
Entity ID: 1
MoleculeChainsSequence LengthOrganismDetailsImage
Hemagglutinin HA1AB328Influenza A virus (A/little yellow-shouldered bat/Guatemala/060/2010(H17N10))Mutation(s): 0
Gene Names: HA
Find proteins for H6QM93 (Influenza A virus)
Explore H6QM93
Go to UniProtKB:  H6QM93
Protein Feature View
Expand
  • Reference Sequence
Find similar proteins by:  (by identity cutoff)  |  Structure
Entity ID: 2
MoleculeChainsSequence LengthOrganismDetailsImage
Hemagglutinin HA2CD181Influenza A virus (A/little yellow-shouldered bat/Guatemala/060/2010(H17N10))Mutation(s): 1
Gene Names: HA
Find proteins for H6QM93 (Influenza A virus)
Explore H6QM93
Go to UniProtKB:  H6QM93
Protein Feature View
Expand
  • Reference Sequence
Oligosaccharides

Help

Entity ID: 3
MoleculeChainsChain Length2D Diagram Glycosylation3D Interactions
alpha-L-fucopyranose-(1-6)-2-acetamido-2-deoxy-beta-D-glucopyranose
E
2 N-Glycosylation Oligosaccharides Interaction
Small Molecules
Ligands 1 Unique
IDChainsName / Formula / InChI Key2D Diagram3D Interactions
NAG
Query on NAG

Download CCD File
B
2-acetamido-2-deoxy-beta-D-glucopyranose
C8 H15 N O6
OVRNDRQMDRJTHS-FMDGEEDCSA-N
 Ligand Interaction
Experimental Data & Validation

Experimental Data

  • Method: X-RAY DIFFRACTION
  • Resolution: 3.18 Å
  • R-Value Free: 0.258
  • R-Value Work: 0.203
  • R-Value Observed: 0.205
  • Space Group: H 3 2
Unit Cell:
Length ( Å )Angle ( ˚ )
a = 100.825α = 90
b = 100.825β = 90
c = 760.536γ = 120
Software Package:
Software NamePurpose
HKL-2000data collection
PHASERphasing
REFMACrefinement
HKL-2000data reduction
HKL-2000data scaling

Structure Validation

View Full Validation Report



Entry History

Deposition Data

  • Deposited Date: 2012-11-30
  • Released Date: 2013-01-16
  • Deposition Author(s): Zhu, X., Wilson, I.A.

Revision History

  • Version 1.0: 2013-01-16
    Type: Initial release
  • Version 1.1: 2013-05-22
    Changes: Database references
  • Version 2.0: 2020-07-29
    Type: Remediation
    Reason: Carbohydrate remediation
    Changes: Atomic model, Data collection, Database references, Derived calculations, Structure summary
