4I5L

Structural mechanism of trimeric PP2A holoenzyme involving PR70: insight for Cdc6 dephosphorylation


Experimental Data Snapshot

  • Method: X-RAY DIFFRACTION
  • Resolution: 2.43 Å
  • R-Value Free: 0.228
  • R-Value Work: 0.179

wwPDB Validation 3D Report Full Report


This is version 1.3 of the entry. See complete history

Literature

Structure of the Ca(2+)-dependent PP2A heterotrimer and insights into Cdc6 dephosphorylation.

Wlodarchak, N.Guo, F.Satyshur, K.A.Jiang, L.Jeffrey, P.D.Sun, T.Stanevich, V.Mumby, M.C.Xing, Y.

(2013) Cell Res. 23: 931-946

  • DOI: 10.1038/cr.2013.77
  • Primary Citation of Related Structures:

  • PubMed Abstract:
  • The B″/PR72 family of protein phosphatase 2A (PP2A) is an important PP2A family involved in diverse cellular processes, and uniquely regulated by calcium binding to the regulatory subunit. The PR70 subunit in this family interacts with cell division ...

    The B″/PR72 family of protein phosphatase 2A (PP2A) is an important PP2A family involved in diverse cellular processes, and uniquely regulated by calcium binding to the regulatory subunit. The PR70 subunit in this family interacts with cell division control 6 (Cdc6), a cell cycle regulator important for control of DNA replication. Here, we report crystal structures of the isolated PR72 and the trimeric PR70 holoenzyme at a resolution of 2.1 and 2.4 Å, respectively, and in vitro characterization of Cdc6 dephosphorylation. The holoenzyme structure reveals that one of the PR70 calcium-binding motifs directly contacts the scaffold subunit, resulting in the most compact scaffold subunit conformation among all PP2A holoenzymes. PR70 also binds distinctively to the catalytic subunit near the active site, which is required for PR70 to enhance phosphatase activity toward Cdc6. Our studies provide a structural basis for unique regulation of B″/PR72 holoenzymes by calcium ions, and suggest the mechanisms for precise control of substrate specificity among PP2A holoenzymes.


    Organizational Affiliation

    McArdle Laboratory, Department of Oncology, University of Wisconsin-Madison, School of Medicine and Public Health, Madison, WI, USA.




Macromolecules

Find similar proteins by: Sequence  |  Structure

Entity ID: 1
MoleculeChainsSequence LengthOrganismDetails
Serine/threonine-protein phosphatase 2A 65 kDa regulatory subunit A alpha isoform
A, D
584Homo sapiensMutation(s): 0
Gene Names: PPP2R1A
Find proteins for P30153 (Homo sapiens)
Go to Gene View: PPP2R1A
Go to UniProtKB:  P30153
Entity ID: 2
MoleculeChainsSequence LengthOrganismDetails
Serine/threonine-protein phosphatase 2A regulatory subunit B'' subunit beta - Cell division control protein 6 homolog chimeric construct
B, E
413Homo sapiensMutation(s): 0
Gene Names: CDC6 (CDC18L), PPP2R3B (PPP2R3L)
Find proteins for Q99741 (Homo sapiens)
Go to Gene View: CDC6
Go to UniProtKB:  Q99741
Find proteins for Q9Y5P8 (Homo sapiens)
Go to Gene View: PPP2R3B
Go to UniProtKB:  Q9Y5P8
Entity ID: 3
MoleculeChainsSequence LengthOrganismDetails
Serine/threonine-protein phosphatase 2A catalytic subunit alpha isoform, PP2A-alpha
C, F
311Homo sapiensMutation(s): 0
Gene Names: PPP2CA
EC: 3.1.3.16
Find proteins for P67775 (Homo sapiens)
Go to Gene View: PPP2CA
Go to UniProtKB:  P67775
Entity ID: 4
MoleculeChainsSequence LengthOrganismDetails
Microcystin-LR (MCLR) bound form
G, H
7N/AMutation(s): 0
Protein Feature View is not available: No corresponding UniProt sequence found.
Small Molecules
Ligands 4 Unique
IDChainsName / Formula / InChI Key2D Diagram3D Interactions
MN
Query on MN

Download SDF File
Download CCD File
C, F
MANGANESE (II) ION
Mn
WAEMQWOKJMHJLA-UHFFFAOYSA-N
 Ligand Interaction
MLI
Query on MLI

Download SDF File
Download CCD File
C, E, F
MALONATE ION
C3 H2 O4
OFOBLEOULBTSOW-UHFFFAOYSA-L
 Ligand Interaction
CA
Query on CA

Download SDF File
Download CCD File
B, E
CALCIUM ION
Ca
BHPQYMZQTOCNFJ-UHFFFAOYSA-N
 Ligand Interaction
PEG
Query on PEG

Download SDF File
Download CCD File
A, B, C, D, E
DI(HYDROXYETHYL)ETHER
C4 H10 O3
MTHSVFCYNBDYFN-UHFFFAOYSA-N
 Ligand Interaction
Biologically Interesting Molecules 1 Unique
IDChainsNameType/Class2D Diagram3D Interactions
PRD_001031
Query on PRD_001031
G,HMicrocystin-LR (MCLR) bound formOligopeptide / Toxin

--

Experimental Data & Validation

Experimental Data

  • Method: X-RAY DIFFRACTION
  • Resolution: 2.43 Å
  • R-Value Free: 0.228
  • R-Value Work: 0.179
  • Space Group: P 21 21 21
Unit Cell:
Length (Å)Angle (°)
a = 94.234α = 90.00
b = 101.071β = 90.00
c = 343.396γ = 90.00
Software Package:
Software NamePurpose
REFMACrefinement
HKL-2000data reduction
ADSCdata collection
PHASERphasing
HKL-2000data scaling

Structure Validation

View Full Validation Report or Ramachandran Plots



Entry History

Deposition Data

Revision History

  • Version 1.0: 2013-05-08
    Type: Initial release
  • Version 1.1: 2013-05-15
    Type: Structure summary
  • Version 1.2: 2013-07-24
    Type: Database references
  • Version 1.3: 2017-08-09
    Type: Advisory, Refinement description, Source and taxonomy
