4HHX

Structure of cytoplasmic domain of TCPE from Vibrio cholerae


Experimental Data Snapshot

  • Method: X-RAY DIFFRACTION
  • Resolution: 1.88 Å
  • R-Value Free: 0.247
  • R-Value Work: 0.218
  • R-Value Observed: 0.220

wwPDB Validation   3D Report Full Report


This is version 1.0 of the entry. See complete history


Literature

Structure of the cytoplasmic domain of TcpE, the inner membrane core protein required for assembly of the Vibrio cholerae toxin-coregulated pilus.

Kolappan, S.Craig, L.

(2013) Acta Crystallogr D Biol Crystallogr 69: 513-519

  • DOI: 10.1107/S0907444912050330
  • Primary Citation of Related Structures:
    4HHX

  • PubMed Abstract:
  • Type IV pili are long thin surface-displayed polymers of the pilin subunit that are present in a diverse group of bacteria. These multifunctional filaments are critical to virulence for pathogens such as Vibrio cholerae, which use them to form microcolonies and to secrete the colonization factor TcpF ...

    Type IV pili are long thin surface-displayed polymers of the pilin subunit that are present in a diverse group of bacteria. These multifunctional filaments are critical to virulence for pathogens such as Vibrio cholerae, which use them to form microcolonies and to secrete the colonization factor TcpF. The type IV pili are assembled from pilin subunits by a complex inner membrane machinery. The core component of the type IV pilus-assembly platform is an integral inner membrane protein belonging to the GspF superfamily of secretion proteins. These proteins somehow convert chemical energy from ATP hydrolysis by an assembly ATPase on the cytoplasmic side of the inner membrane to mechanical energy for extrusion of the growing pilus filament out of the inner membrane. Most GspF-family inner membrane core proteins are predicted to have N-terminal and central cytoplasmic domains, cyto1 and cyto2, and three transmembrane segments, TM1, TM2 and TM3. Cyto2 and TM3 represent an internal repeat of cyto1 and TM1. Here, the 1.88 Å resolution crystal structure of the cyto1 domain of V. cholerae TcpE, which is required for assembly of the toxin-coregulated pilus, is reported. This domain folds as a monomeric six-helix bundle with a positively charged membrane-interaction face at one end and a hydrophobic groove at the other end that may serve as a binding site for partner proteins in the pilus-assembly complex.


    Organizational Affiliation

    Molecular Biology and Biochemistry Department, Simon Fraser University, Burnaby, BC, Canada.



Macromolecules
Find similar proteins by:  (by identity cutoff)  |  Structure
Entity ID: 1
MoleculeChainsSequence LengthOrganismDetailsImage
Toxin coregulated pilus biosynthesis protein EA120Vibrio cholerae O1 biovar El Tor str. N16961Mutation(s): 0
Gene Names: tcpEVC_0836
Find proteins for P0C6C9 (Vibrio cholerae serotype O1 (strain ATCC 39315 / El Tor Inaba N16961))
Explore P0C6C9
Go to UniProtKB:  P0C6C9
Protein Feature View
Expand
  • Reference Sequence
Small Molecules
Ligands 1 Unique
IDChainsName / Formula / InChI Key2D Diagram3D Interactions
SO4
Query on SO4

Download Ideal Coordinates CCD File
B [auth A]SULFATE ION
O4 S
QAOWNCQODCNURD-UHFFFAOYSA-L
 Ligand Interaction
Modified Residues  1 Unique
IDChainsTypeFormula2D DiagramParent
MSE
Query on MSE
AL-PEPTIDE LINKINGC5 H11 N O2 SeMET
Experimental Data & Validation

Experimental Data

  • Method: X-RAY DIFFRACTION
  • Resolution: 1.88 Å
  • R-Value Free: 0.247
  • R-Value Work: 0.218
  • R-Value Observed: 0.220
  • Space Group: C 2 2 21
Unit Cell:
Length ( Å )Angle ( ˚ )
a = 34.79α = 90
b = 73.61β = 90
c = 95.9γ = 90
Software Package:
Software NamePurpose
Blu-Icedata collection
SQUASHphasing
REFMACrefinement
XDSdata reduction
XSCALEdata scaling

Structure Validation

View Full Validation Report



Entry History

Deposition Data

Revision History  (Full details and data files)

  • Version 1.0: 2013-04-03
    Type: Initial release
