4HEL

Crystal structure analysis of apo-GroEL structure


Experimental Data Snapshot

  • Method: X-RAY DIFFRACTION
  • Resolution: 3.20 Å
  • R-Value Free: 0.223
  • R-Value Work: 0.198
  • R-Value Observed: 0.199

wwPDB Validation 3D Report Full Report



Literature

Crystal structure of apo-GroEL structure

Meena, S.R.Saxena, A.K.

To be published.

Macromolecules
Find similar proteins by:  (by identity cutoff)  |  Structure
Entity ID: 1
MoleculeChainsSequence LengthOrganismDetailsImage
60 kDa chaperonin 4ABCDEFGHIJKLMN525Escherichia coliMutation(s): 0
Gene Names:
groLgroELgroL_1groL_2mopAA6581_03125A6V01_27720A8C65_01580A9P13_23810A9R57_13545A9X72_22960AC067_05505AC789_1c45570ACN002_4372ACN68_26960ACN81_06325ACU57_19295ACU90_27610AJ318_17205AM270_14500AM446_25370AM464_15770AM465_02150AMK83_27450AML35_20705APT94_02245APZ14_01135ARC77_17990AU473_28145AUQ13_10300AUS26_18735AW059_20455AW106_26290AWB10_23735AWE53_002045AWF59_005875AWG78_009865AWG90_025680B6V57_24240B7C53_14115B9M99_07795B9N33_15905B9T59_10250BANRA_00108BANRA_00147BANRA_02787BANRA_02830BB545_11040BE963_12230BEN53_00765BER14_11410BFD68_08450BHF03_14145BHF46_15625BHS81_24830BHS87_23225BIQ87_23895BIU72_06095BIZ41_02710BJJ90_23450BK248_23630BK292_23445BK296_02280BK334_08295BK373_03440BK375_06855BK383_12940BMA87_21445BMT49_19180BMT91_05495BN17_41231BOH76_02880BON63_07075BON65_22610BON66_25750BON69_04690BON71_15855BON72_19590BON75_25260BON76_04275BON83_17240BON86_07405BON87_11955BON91_12970BON92_18275BON94_08655BON95_05420BON96_03715BTQ04_18135BTQ06_07135BUE81_24315BvCms12BK_04199BvCms2454_04385BvCms28BK_01487BvCms35BK_01935BvCmsC61A_01711BvCmsHHP001_00679BvCmsHHP019_00806BvCmsHHP056_01305BvCmsKKP036_00132BvCmsKKP061_03324BvCmsKSNP073_03447BvCmsKSNP081_01939BvCmsKSNP120_00880BvCmsKSP011_04701BvCmsKSP024_01292BvCmsKSP026_01573BvCmsKSP045_02508BvCmsKSP058_02605BvCmsKSP067_03875BvCmsNSNP036_02363BvCmsNSP006_05622BvCmsNSP007_04896BvCmsNSP047_02052BvCmsNSP072_00461BvCmsOUP014_01585BvCmsSINP011_01477BvCmsSINP022_02410BvCmsSIP019_03074BvCmsSIP044_04391BVL39_04415BW690_22405BWI89_16475BWP17_13605BXT93_23590BZL31_12950BZL69_06910C2M16_07145C2U48_11800C4K41_15740C4M78_05800C5715_24370C5N07_07010C5P01_11485C5P44_18550C6669_06700C6B13_11455C7235_22800C7B02_22870C7B06_19620C7B07_19640C7B08_13320C7B18_22125C9098_11410C9114_00680C9141_20510C9160_20130C9162_14155C9201_17520C9306_22895C9E25_08280C9E67_27735C9Z03_10905C9Z23_18645C9Z28_23700C9Z29_19670C9Z39_10120C9Z43_22545C9Z68_08425C9Z69_17815C9Z70_16200C9Z78_16845C9Z89_21585CA593_05105CCZ14_19960CCZ17_16290CDC27_22515CDL37_19955CF006_04695CG692_00055CI641_014245CI693_12655CI694_17140CIG45_10085CJU63_24545CMR93_14020CO706_20635COD30_28660COD46_17610CQP61_24785CR539_02660CRD98_26740CRE06_15175CRJUMX01_530009CRM83_17505CRT43_24985CRX46_11625CSB64_20580CT146_11195CUB99_10685CV83915_01888CVH05_06685CWM24_06435CWS33_03390D0X26_12780D2184_07875D2185_07635D2188_20735D3822_10750D3C88_27260D3M98_16560D3O91_01400D3P01_12765D3P02_10285D3Y67_00555D4011_02335D4011_28795D4023_24445D4074_12335D4074_28065D4628_24265D4636_24995D4638_20515D4660_14220D4660_28105D4718_12750D4L91_10435D4L91_28785D4M06_10270D4M06_29410D4U49_20275D4U49_28470D4U85_11010D4U85_28965D4V08_09395D5H35_23635D5I97_10335D5I97_29045D6004_23030D6C36_13230D6C36_28445D6D43_13715D6D43_29350D6T60_08370D6W00_21570D6X36_01360D6X63_17145D6X76_09075D6X76_29465D7K33_08230D7K33_28455D7K63_02295D7K66_01645D7W70_13165D7Y10_20710D7Z75_21475D8Y65_09645D8Y65_29360D9610_22370D9C99_20305D9D20_08430D9D31_08050D9D33_02520D9D43_14725D9D44_05930D9D94_05390D9E13_11800D9E19_18585D9E34_15015D9E35_09915D9E49_11975D9E73_04555D9F17_02185D9F32_10570D9F87_11960D9G11_21625D9G42_15395D9G48_11760D9G69_11420D9G95_09380D9H10_23635D9H36_10345D9H53_05445D9H68_15855D9H70_08850D9H94_06455D9I18_04540D9I87_11050D9I88_12295D9I97_14780D9J03_08605D9J44_18175D9J46_16915D9J52_05945D9J58_20605D9J60_12275D9J63_12815D9J78_19045D9K02_08765D9K48_05190D9K54_26350D9L89_02290D9L89_29680D9L99_20610D9S45_09405D9X77_11690D9X77_27245D9X97_13605D9X97_28710D9Z28_19325DAH18_16415DAH26_05045DAH30_16205DAH34_17585DAH37_06370DAH43_08635DB359_12000DBQ99_23660DD762_21030DEN86_00710DEN89_17490DEN97_13360DEO04_24535DEO19_26325DEO20_25075DJ487_18360DJ492_21620DJ503_21955DK132_21945DL251_20250DL251_25995DL257_06855DL257_26035DL292_23900DL326_21490DL455_10645DL479_22395DL530_24735DL545_22730DL800_29220DL979_24565DL979_26215DLT82_13510DLT82_28090DLU50_04890DLU67_18735DLU82_20050DLW60_25690DLW88_24690DLW88_28620DLX38_16350DLX38_27700DLX40_20245DLY41_20340DLY44_11720DM102_08870DM129_07825DM155_25270DM267_18730DM272_20435DM272_27585DM280_12770DM280_26265DM296_20595DM382_23740DM820_21810DM962_19000DM973_23780DMI04_11460DMI04_28175DMI53_04370DMI53_30055DMO02_14455DMO02_29440DMZ50_22485DMZ50_28115DN627_22730DN660_22545DN700_24935DN703_08355DN703_30665DN808_14005DNB37_06985DNB37_28240DNC98_05725DND16_08930DND16_27675DND79_22010DNI21_07355DNJ62_11730DNJ62_29205DNK12_12585DNK12_28175DNQ45_22695DNR35_20070DNR41_18215DNW42_03440DNX19_14450DNX30_08345DNX30_30410DOE35_12275DOE35_31185DOM23_19100DOM23_26315DOS18_11520DOS18_28020DOT81_12600DOT81_29465DOU81_10025DOU81_28535DOY22_05440DOY56_08400DOY56_28305DOY61_23910DOY67_14955DP258_24460DP265_18880DP277_20350DQE91_24695DQF36_20915DQF57_23270DQF71_26180DQF72_19220DQG35_13885DQG35_28640DQO13_25440DQP61_22195DRP48_12950DRP48_28250DRW19_22655DS143_26430DS721_10755DS721_28365DS732_02495DS966_08020DT034_23795DTL43_02185DTL90_17410DTM10_04525DTM45_21115DTZ20_23990DTZ20_30255DU309_08105DU321_10255DU333_08465DVB38_23740DW236_18440DWB25_22555DXT69_20075DXT71_04100DXT73_07230DXX80_015065E0I42_01220E0K84_20485E0L04_22495E0L12_16055E2112_14800E2114_01880E2115_03725E2127_07020E2128_02070E2129_04150E2134_13845E2148_16540E2855_05287E2863_05073E4K55_08760E4K60_10770E4K61_05830E5P22_06470E5P28_03065E5P37_09765E5S42_15075E5S46_10410E5S47_14980E5S58_09490E5S61_14350EA159_10565EA167_13005EA189_17960EA191_15010EA200_16350EA203_12885EA213_12185EA214_14310EA218_07230EA222_18065EA223_01205EA225_21165EA231_14300EA232_12495EA233_14040EA242_18995EA250_13490EA410_11360EA429_17040EA434_08355EA435_16360EA834_13510EAI42_02210EAI46_05875EAI52_08825EAM59_26250EAN70_26425EAN77_04200EAN77_30790EAX79_03060EB476_06015EB509_04245EB510_02850EB515_02245EB515_27855EBA46_03220EBA84_09370EBA84_28120EBJ06_01305EBJ06_28485EBM08_22005EC1094V2_4111EC3234A_108c00480EC3426_00475EC382_20320EC95NR1_03760ECONIH1_24685ECs5124ECTO124_04553ECTO6_04343ED225_08645ED225_27880ED307_02560ED600_22995ED607_16100ED611_08915ED903_07130ED944_02245ED944_28230EEA45_03810EEA45_28005EEP23_07625EF082_10500EF082_28260EF173_02240EG075_08115EG599_24615EG796_20885EG808_19065EGC26_01700EGC26_27120EGT48_17625EGU87_11215EH186_16900EH412_25905EHD45_05145EHD63_02245EHD63_27685EHD79_25330EHH55_19100EHJ36_27130EHJ66_01305EHJ66_27440EHV81_05685EHV81_28700EHV90_05845EHV90_28280EHW09_10550EHW09_28755EHX09_11460EHX09_28360EI021_09520EI028_05320EI032_02755EI041_04840EIA08_20145EIA21_18795EJ366_20730EJC75_20460EKI52_12830EL75_4022EL79_4200EL80_4116ELT17_14070ELT20_09305ELT22_11950ELT33_14955ELT48_15395ELT58_06705ELU82_07640ELU85_14365ELU96_21405ELV05_12715ELV08_11530ELV13_23125ELV15_01140ELV22_09270ELV24_17430ELV28_07840ELX56_19165ELX70_15520ELX76_24925ELX79_22305ELX83_07205ELY05_00695ELY23_03820ELY24_10375ELY41_00375ELY48_02650ELY50_08540EO241_15015EPS76_03470EPS91_16025EPS94_17720EPU41_23390EQ823_13510EQ830_14810ERS085365_01231ERS085366_02367ERS085374_01721ERS085379_04164ERS085383_01552ERS085386_01025ERS085404_01348ERS085416_03698ERS139211_04024ERS150873_01289ERS150876_03930EST51_23025EVY14_04860EWK56_08835EXM29_20525ExPECSC019_02707ExPECSC038_04651ExPECSC065_03193EXX06_20585EXX13_20070EXX23_19135EXX24_09465EXX53_17255EXX55_21120EXX71_14845EXX78_13730EXX87_19165EYD11_20730EYX82_10180EYX99_04255EYY27_19875EYY34_13765EYY78_14820F1E13_09345F1E19_03375F7F00_14880F7F11_04220F7F18_10000F7F23_25375F7F26_26295F7F29_01940F7G01_00535F7G03_07175F9059_10080F9Z74_02985FAF34_003085FE846_00125FKO60_18130FNJ67_24100FNJ69_19940FNJ83_25610FORC82_4346FQ022_13705FQ915_09820FQR64_21020FQU83_24305FQZ46_22770FTV92_15760FV293_00695FV295_12225FV438_02410FVB16_06060FY127_22265FZ043_01940GFU40_14935GFU45_12425GFU47_18795GII67_18045GII91_15055GIY19_14585GJ11_26030GJ638_00565GJD97_25060GKE15_09275GKE22_10295GKE24_11420GKE26_10775GKE29_08310GKE31_09560GKE39_09155GKE46_08955GKE58_08785GKE60_08855GKE64_08830GKE77_10075GKE87_04060GKE92_06735GKE93_00650GKF03_06795GKF28_04865GKF34_05660GKF47_05655GKF74_12750GKF86_05330GKF89_03295GKG08_03500GKG09_04295GKG11_04295GKG22_04295GKG29_04295GN312_11965GNZ00_20445GNZ02_08740GNZ03_05040GP654_20575GP661_16060GP664_24795GP666_16195GP689_08440GP700_05565GP712_07845GP720_11720GP727_03900GP912_07820GP935_18020GP946_12790GQE22_08265GQE30_14340GQE34_01865GQE42_10270GQE47_08935GQE51_14690GQE58_15895GQE64_09275GQE68_13620GQE88_08730GQE93_06555GQL64_02350GQM09_07865GQM13_10590GQM17_01930GQN16_09890GQN33_18275GQS26_16025GRW42_14445GRW80_01165HmCms169_03328HmCms184_03267HmCmsJML074_01333HmCmsJML079_00812HmCmsJML146_00635HmCmsJML204_04031HmCmsJML236_04199HMPREF3040_03032MJ49_08265MS6198_48630MS8345_04771NCTC10082_01857NCTC10089_04560NCTC10090_02607NCTC10418_06721NCTC10764_04513NCTC10767_00467NCTC10865_05650NCTC10963_04614NCTC10974_05136NCTC11022_04473NCTC11112_02719NCTC11181_01789NCTC11341_03019NCTC12650_04817NCTC12950_04949NCTC13127_05944NCTC13216_02274NCTC13846_04307NCTC7927_05027NCTC8450_00576NCTC8500_05095NCTC8621_04680NCTC8622_02021NCTC8959_04316NCTC8960_02051NCTC9007_00921NCTC9036_04433NCTC9044_02622NCTC9045_05354NCTC9050_02551NCTC9055_01424NCTC9058_02377NCTC9062_03620NCTC9073_03984NCTC9077_05690NCTC9081_01494NCTC9111_04720NCTC9117_05641NCTC9119_04735NCTC9434_02173NCTC9701_04822NCTC9702_05313NCTC9703_03911NCTC9706_01822NCTC9777_00950NCTC9969_04590PGD_03325PU06_23700RG28_06025RK56_012245RX35_04405SAMEA3472043_02122SAMEA3472044_01554SAMEA3472047_01720SAMEA3472055_04142SAMEA3472056_01662SAMEA3472070_02799SAMEA3472080_00128SAMEA3472090_01020SAMEA3472110_00754SAMEA3472112_01087SAMEA3472114_01908SAMEA3484427_02051SAMEA3484429_03091SAMEA3484434_04204SAMEA3485101_04769SAMEA3752372_01184SAMEA3752553_04400SAMEA3752559_00182SAMEA3752620_03454SAMEA3753064_01580SAMEA3753097_01210SAMEA3753164_04038SAMEA3753290_02069SAMEA3753300_00682SK85_04506SY51_23895U12A_04548U14A_04542UC41_03555UN91_24955WQ89_21775WR15_07175YDC107_2866

Find proteins for Q548M1 (Escherichia coli)
Explore Q548M1
Go to UniProtKB:  Q548M1
Protein Feature View
Expand
 ( Mouse scroll to zoom / Hold left click to move )
  • Reference Sequence
Experimental Data & Validation

Experimental Data

  • Method: X-RAY DIFFRACTION
  • Resolution: 3.20 Å
  • R-Value Free: 0.223
  • R-Value Work: 0.198
  • R-Value Observed: 0.199
  • Space Group: P 21 21 21
Unit Cell:
Length ( Å )Angle ( ˚ )
a = 136.24α = 90
b = 261.83β = 90
c = 282.28γ = 90
Software Package:
Software NamePurpose
HKL-2000data collection
PHASERphasing
REFMACrefinement
MOSFLMdata reduction
SCALAdata scaling

Structure Validation

View Full Validation Report



Entry History

Deposition Data

Revision History

  • Version 1.0: 2013-09-25
    Type: Initial release
