4HE8

Crystal structure of the membrane domain of respiratory complex I from Thermus thermophilus


Experimental Data Snapshot

  • Method: X-RAY DIFFRACTION
  • Resolution: 3.30 Å
  • R-Value Free: 0.263
  • R-Value Work: 0.209
  • R-Value Observed: 0.210

wwPDB Validation 3D Report Full Report


This is version 1.1 of the entry. See complete history


Literature

Crystal structure of the entire respiratory complex I.

Baradaran, R.Berrisford, J.M.Minhas, G.S.Sazanov, L.A.

(2013) Nature 494: 443-448

  • DOI: 10.1038/nature11871
  • Primary Citation of Related Structures:
    4HEA, 4HE8

  • PubMed Abstract:
  • Complex I is the first and largest enzyme of the respiratory chain and has a central role in cellular energy production through the coupling of NADH:ubiquinone electron transfer to proton translocation. It is also implicated in many common human neur ...

    Complex I is the first and largest enzyme of the respiratory chain and has a central role in cellular energy production through the coupling of NADH:ubiquinone electron transfer to proton translocation. It is also implicated in many common human neurodegenerative diseases. Here, we report the first crystal structure of the entire, intact complex I (from Thermus thermophilus) at 3.3 Å resolution. The structure of the 536-kDa complex comprises 16 different subunits, with a total of 64 transmembrane helices and 9 iron-sulphur clusters. The core fold of subunit Nqo8 (ND1 in humans) is, unexpectedly, similar to a half-channel of the antiporter-like subunits. Small subunits nearby form a linked second half-channel, which completes the fourth proton-translocation pathway (present in addition to the channels in three antiporter-like subunits). The quinone-binding site is unusually long, narrow and enclosed. The quinone headgroup binds at the deep end of this chamber, near iron-sulphur cluster N2. Notably, the chamber is linked to the fourth channel by a 'funnel' of charged residues. The link continues over the entire membrane domain as a flexible central axis of charged and polar residues, and probably has a leading role in the propagation of conformational changes, aided by coupling elements. The structure suggests that a unique, out-of-the-membrane quinone-reaction chamber enables the redox energy to drive concerted long-range conformational changes in the four antiporter-like domains, resulting in translocation of four protons per cycle.


    Organizational Affiliation

    Medical Research Council Mitochondrial Biology Unit, Wellcome Trust/MRC Building, Hills Road, Cambridge CB2 0XY, UK.



Macromolecules
Find similar proteins by:  (by identity cutoff)  |  Structure
Entity ID: 2
MoleculeChainsSequence LengthOrganismDetailsImage
NADH-quinone oxidoreductase subunit 10DJ176Thermus thermophilus HB8Mutation(s): 0
Gene Names: nqo10TTHA0093
EC: 1.6.5.3 (PDB Primary Data), 7.1.1 (UniProt)
Membrane protein
Mpstruc
Group:
TRANSMEMBRANE PROTEINS: ALPHA-HELICAL
Sub Group:
Electron Transport Chain Complexes: Complex I
Protein:
Complex I complete
Find proteins for Q56225 (Thermus thermophilus (strain HB8 / ATCC 27634 / DSM 579))
Explore Q56225
Go to UniProtKB:  Q56225
Protein Feature View
Expand
 ( Mouse scroll to zoom / Hold left click to move )
  • Reference Sequence
Find similar proteins by:  (by identity cutoff)  |  Structure
Entity ID: 3
MoleculeChainsSequence LengthOrganismDetailsImage
NADH-quinone oxidoreductase subunit 11EK95Thermus thermophilus HB8Mutation(s): 0
Gene Names: nqo11TTHA0094
EC: 1.6.5.3 (PDB Primary Data), 7.1.1 (UniProt)
Membrane protein
Mpstruc
Group:
TRANSMEMBRANE PROTEINS: ALPHA-HELICAL
Sub Group:
Electron Transport Chain Complexes: Complex I
Protein:
Complex I complete
Find proteins for Q56226 (Thermus thermophilus (strain HB8 / ATCC 27634 / DSM 579))
Explore Q56226
Go to UniProtKB:  Q56226
Protein Feature View
Expand
 ( Mouse scroll to zoom / Hold left click to move )
  • Reference Sequence
Find similar proteins by:  (by identity cutoff)  |  Structure
Entity ID: 5
MoleculeChainsSequence LengthOrganismDetailsImage
NADH-quinone oxidoreductase subunit 13GM469Thermus thermophilus HB8Mutation(s): 0
Gene Names: nqo13TTHA0096
EC: 1.6.5.3 (PDB Primary Data), 7.1.1 (UniProt)
Membrane protein
Mpstruc
Group:
TRANSMEMBRANE PROTEINS: ALPHA-HELICAL
Sub Group:
Electron Transport Chain Complexes: Complex I
Protein:
Complex I complete
Find proteins for Q56228 (Thermus thermophilus (strain HB8 / ATCC 27634 / DSM 579))
Explore Q56228
Go to UniProtKB:  Q56228
Protein Feature View
Expand
 ( Mouse scroll to zoom / Hold left click to move )
  • Reference Sequence
Find similar proteins by:  (by identity cutoff)  |  Structure
Entity ID: 6
MoleculeChainsSequence LengthOrganismDetailsImage
NADH-quinone oxidoreductase subunit 14IN427Thermus thermophilus HB8Mutation(s): 0
Gene Names: nqo14TTHA0097
EC: 1.6.5.3 (PDB Primary Data), 7.1.1 (UniProt)
Membrane protein
Mpstruc
Group:
TRANSMEMBRANE PROTEINS: ALPHA-HELICAL
Sub Group:
Electron Transport Chain Complexes: Complex I
Protein:
Complex I complete
Find proteins for Q56229 (Thermus thermophilus (strain HB8 / ATCC 27634 / DSM 579))
Explore Q56229
Go to UniProtKB:  Q56229
Protein Feature View
Expand
 ( Mouse scroll to zoom / Hold left click to move )
  • Reference Sequence
Find similar proteins by:  (by identity cutoff)  |  Structure
Entity ID: 7
MoleculeChainsSequence LengthOrganismDetailsImage
NADH-quinone oxidoreductase subunit 8CH365Thermus thermophilus HB8Mutation(s): 0
Gene Names: nqo8TTHA0091
EC: 1.6.5.3 (PDB Primary Data), 7.1.1 (UniProt)
Membrane protein
Mpstruc
Group:
TRANSMEMBRANE PROTEINS: ALPHA-HELICAL
Sub Group:
Electron Transport Chain Complexes: Complex I
Protein:
Complex I complete
Find proteins for Q60019 (Thermus thermophilus (strain HB8 / ATCC 27634 / DSM 579))
Explore Q60019
Go to UniProtKB:  Q60019
Protein Feature View
Expand
 ( Mouse scroll to zoom / Hold left click to move )
  • Reference Sequence
Find similar proteins by:  (by identity cutoff)  |  Structure
Entity ID: 1
MoleculeChainsSequence LengthOrganismDetailsImage
NADH-quinone oxidoreductase subunit 7AB119Thermus thermophilus HB8Mutation(s): 0
Gene Names: nqo7TTHA0084
EC: 1.6.5.3 (PDB Primary Data), 7.1.1 (UniProt)
Membrane protein
Mpstruc
Group:
TRANSMEMBRANE PROTEINS: ALPHA-HELICAL
Sub Group:
Electron Transport Chain Complexes: Complex I
Protein:
Complex I complete
Find proteins for Q56217 (Thermus thermophilus (strain HB8 / ATCC 27634 / DSM 579))
Explore Q56217
Go to UniProtKB:  Q56217
Protein Feature View
Expand
 ( Mouse scroll to zoom / Hold left click to move )
  • Reference Sequence
Find similar proteins by:  (by identity cutoff)  |  Structure
Entity ID: 4
MoleculeChainsSequence LengthOrganismDetailsImage
NADH-quinone oxidoreductase subunit 12FL606Thermus thermophilus HB8Mutation(s): 0
Gene Names: nqo12TTHA0095
EC: 1.6.5.3 (PDB Primary Data), 7.1.1 (UniProt)
Membrane protein
Mpstruc
Group:
TRANSMEMBRANE PROTEINS: ALPHA-HELICAL
Sub Group:
Electron Transport Chain Complexes: Complex I
Protein:
Complex I complete
Find proteins for Q56227 (Thermus thermophilus (strain HB8 / ATCC 27634 / DSM 579))
Explore Q56227
Go to UniProtKB:  Q56227
Protein Feature View
Expand
 ( Mouse scroll to zoom / Hold left click to move )
  • Reference Sequence
Small Molecules
Ligands 1 Unique
IDChainsName / Formula / InChI Key2D Diagram3D Interactions
UMQ
Query on UMQ

Download CCD File
D, F, J, L
UNDECYL-MALTOSIDE
C23 H44 O11
UYEMNFYVTFDKRG-ZNGNCRBCSA-N
 Ligand Interaction
Experimental Data & Validation

Experimental Data

  • Method: X-RAY DIFFRACTION
  • Resolution: 3.30 Å
  • R-Value Free: 0.263
  • R-Value Work: 0.209
  • R-Value Observed: 0.210
  • Space Group: P 1
Unit Cell:
Length ( Å )Angle ( ˚ )
a = 85.26α = 91.91
b = 120.54β = 95.73
c = 176.66γ = 101.41
Software Package:
Software NamePurpose
MOSFLMdata reduction
PHASERphasing
PHENIXrefinement
SCALAdata scaling

Structure Validation

View Full Validation Report



Entry History

Deposition Data

Revision History

  • Version 1.0: 2013-02-13
    Type: Initial release
  • Version 1.1: 2013-03-13
    Changes: Database references
