4GOQ

Crystal structure of a DUF1491 family protein (CC_1065) from Caulobacter crescentus CB15 at 1.87 A resolution

PDB DOI: https://doi.org/10.2210/pdb4GOQ/pdb

Classification: STRUCTURAL GENOMICS, UNKNOWN FUNCTION
Organism(s): Caulobacter vibrioides CB15
Expression System: Escherichia coli
Mutation(s): No

Deposited: 2012-08-20 Released: 2012-09-19
Deposition Author(s): Joint Center for Structural Genomics (JCSG)

Experimental Data Snapshot

Method: X-RAY DIFFRACTION
Resolution: 1.87 Å
R-Value Free: 0.211
R-Value Work: 0.180
R-Value Observed: 0.182

wwPDB Validation 3D Report Full Report

This is version 1.5 of the entry. See complete history.

Literature

Crystal structure of a hypothetical protein (CC_1065) from Caulobacter crescentus CB15 at 1.87 A resolution

Joint Center for Structural Genomics (JCSG)

To be published.

Macromolecule Content

Total Structure Weight: 62.8 kDa
Atom Count: 4,905
Modelled Residue Count: 531
Deposited Residue Count: 550
Unique protein chains: 1

Macromolecules

Find similar proteins by:

(by identity cutoff) | 3D Structure

Entity ID: 1
Molecule	Chains	Sequence Length	Organism	Details	Image
hypothetical protein	A, B, C, D, E	110	Caulobacter vibrioides CB15	Mutation(s): 0 Gene Names: 13422365, CC_1065
UniProt
Find proteins for Q9A9C4 (Caulobacter vibrioides (strain ATCC 19089 / CIP 103742 / CB 15)) Explore Q9A9C4 Go to UniProtKB: Q9A9C4
Entity Groups
Sequence Clusters	30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt Group	Q9A9C4
Sequence Annotations Expand
Reference Sequence

Small Molecules

Ligands 1 Unique
ID	Chains	Name / Formula / InChI Key	2D Diagram	3D Interactions
GOL Query on GOL Download Ideal Coordinates CCD File SDF format, chain I [auth B] SDF format, chain L [auth C] SDF format, chain N [auth D] SDF format, chain P [auth E] SDF format, chain F [auth A] SDF format, chain G [auth A] SDF format, chain H [auth A] SDF format, chain J [auth B] SDF format, chain K [auth B] SDF format, chain M [auth C] SDF format, chain O [auth D] MOL2 format, chain I [auth B] MOL2 format, chain L [auth C] MOL2 format, chain N [auth D] MOL2 format, chain P [auth E] MOL2 format, chain F [auth A] MOL2 format, chain G [auth A] MOL2 format, chain H [auth A] MOL2 format, chain J [auth B] MOL2 format, chain K [auth B] MOL2 format, chain M [auth C] MOL2 format, chain O [auth D] mmCIF format, chain I [auth B] mmCIF format, chain L [auth C] mmCIF format, chain N [auth D] mmCIF format, chain P [auth E] mmCIF format, chain F [auth A] mmCIF format, chain G [auth A] mmCIF format, chain H [auth A] mmCIF format, chain J [auth B] mmCIF format, chain K [auth B] mmCIF format, chain M [auth C] mmCIF format, chain O [auth D]	F [auth A] G [auth A] H [auth A] I [auth B] J [auth B] F [auth A], G [auth A], H [auth A], I [auth B], J [auth B], K [auth B], L [auth C], M [auth C], N [auth D], O [auth D], P [auth E]	GLYCEROL C₃ H₈ O₃ PEDCQBHIVMGVHV-UHFFFAOYSA-N		Interactions Focus chain F [auth A] Focus chain G [auth A] Focus chain H [auth A] Focus chain I [auth B] Focus chain J [auth B] Focus chain K [auth B] Focus chain L [auth C] Focus chain M [auth C] Focus chain N [auth D] Focus chain O [auth D] Focus chain P [auth E] Interactions & Density Focus chain F [auth A] Focus chain G [auth A] Focus chain H [auth A] Focus chain I [auth B] Focus chain J [auth B] Focus chain K [auth B] Focus chain L [auth C] Focus chain M [auth C] Focus chain N [auth D] Focus chain O [auth D] Focus chain P [auth E]

Modified Residues 1 Unique
ID	Chains	Type	Formula	2D Diagram	Parent
MSE Query on MSE	A, B, C, D, E	L-PEPTIDE LINKING	C₅ H₁₁ N O₂ Se		MET

Experimental Data & Validation

Experimental Data

Method: X-RAY DIFFRACTION
Resolution: 1.87 Å
R-Value Free: 0.211
R-Value Work: 0.180
R-Value Observed: 0.182
Space Group: P 3₁ 2 1
Diffraction Data: https://doi.org/10.18430/M34GOQ

Unit Cell:

Length ( Å )	Angle ( ˚ )
a = 59.73	α = 90
b = 59.73	β = 90
c = 323.01	γ = 120

Software Package:

Software Name	Purpose
MolProbity	model building
PDB_EXTRACT	data extraction
SHELX	phasing
SHARP	phasing
XSCALE	data scaling
BUSTER-TNT	refinement
XDS	data reduction
SHELXD	phasing
BUSTER	refinement
