Crystal structure of the nucleotide-binding domain of a dipeptide ABC transporter

Experimental Data Snapshot

  • Resolution: 2.89 Å
  • R-Value Free: 0.268
  • R-Value Work: 0.212
  • R-Value Observed: 0.215

wwPDB Validation   3D Report Full Report

Ligand Structure Quality Assessment

This is version 1.2 of the entry. See complete history


Structure of the nucleotide-binding domain of a dipeptide ABC transporter reveals a novel iron-sulfur cluster-binding domain

Li, X.Zhuo, W.Yu, J.Ge, J.Gu, J.Feng, Y.Yang, M.Wang, L.Wang, N.

(2013) Acta Crystallogr D Biol Crystallogr 69: 256-265

  • DOI: https://doi.org/10.1107/S0907444912045180
  • Primary Citation of Related Structures:

  • PubMed Abstract:

    Dipeptide permease (Dpp), which belongs to an ABC transport system, imports peptides consisting of two or three L-amino acids from the matrix to the cytoplasm in microbes. Previous studies have indicated that haem competes with dipeptides to bind DppA in vitro and in vivo and that the Dpp system can also translocate haem. Here, the crystal structure of DppD, the nucleotide-binding domain (NBD) of the ABC-type dipeptide/oligopeptide/nickel-transport system from Thermoanaerobacter tengcongensis, bound with ATP, Mg(2+) and a [4Fe-4S] iron-sulfur cluster is reported. The N-terminal domain of DppD shares a similar structural fold with the NBDs of other ABC transporters. Interestingly, the C-terminal domain of DppD contains a [4Fe-4S] cluster. The UV-visible absorbance spectrum of DppD was consistent with the presence of a [4Fe-4S] cluster. A search with DALI revealed that the [4Fe-4S] cluster-binding domain is a novel structural fold. Structural analysis and comparisons with other ABC transporters revealed that this iron-sulfur cluster may act as a mediator in substrate (dipeptide or haem) binding by electron transfer and may regulate the transport process in Dpp ABC transport systems. The crystal structure provides a basis for understanding the properties of ABC transporters and will be helpful in investigating the functions of NBDs in the regulation of ABC transporter activity.

  • Organizational Affiliation

    State Key Laboratory of Medical Molecular Biology, Department of Biochemistry and Molecular Biology, Institute of Basic Medical Sciences, Chinese Academy of Medical Sciences, Peking Union Medical College, Tsinghua University, Beijing 100005, People's Republic of China.

Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 1
MoleculeChains Sequence LengthOrganismDetailsImage
ABC-type dipeptide/oligopeptide/nickel transport system, ATPase componentA [auth B]334Caldanaerobacter subterraneus subsp. tengcongensis MB4Mutation(s): 0
Gene Names: DppD
Find proteins for Q8RDH4 (Caldanaerobacter subterraneus subsp. tengcongensis (strain DSM 15242 / JCM 11007 / NBRC 100824 / MB4))
Explore Q8RDH4
Go to UniProtKB:  Q8RDH4
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupQ8RDH4
Sequence Annotations
  • Reference Sequence
Small Molecules
Experimental Data & Validation

Experimental Data

  • Resolution: 2.89 Å
  • R-Value Free: 0.268
  • R-Value Work: 0.212
  • R-Value Observed: 0.215
  • Space Group: P 43 2 2
Unit Cell:
Length ( Å )Angle ( ˚ )
a = 64.247α = 90
b = 64.247β = 90
c = 320.608γ = 90
Software Package:
Software NamePurpose
HKL-2000data collection
HKL-2000data reduction
HKL-2000data scaling

Structure Validation

View Full Validation Report

Ligand Structure Quality Assessment

Entry History

Deposition Data

Revision History  (Full details and data files)

  • Version 1.0: 2013-01-30
    Type: Initial release
  • Version 1.1: 2013-08-07
    Changes: Database references
  • Version 1.2: 2024-03-20
    Changes: Data collection, Database references, Derived calculations
