4F7I

Structure of Isopropylmalate dehydrogenase from Thermus thermophilus in complex with IPM, Mn and NADH


Experimental Data Snapshot

  • Method: X-RAY DIFFRACTION
  • Resolution: 2.00 Å
  • R-Value Free: 0.196
  • R-Value Work: 0.152
  • R-Value Observed: 0.152

wwPDB Validation   3D Report Full Report


This is version 1.4 of the entry. See complete history


Literature

Structural and energetic basis of isopropylmalate dehydrogenase enzyme catalysis.

Pallo, A.Olah, J.Graczer, E.Merli, A.Zavodszky, P.Weiss, M.S.Vas, M.

(2014) FEBS J 281: 5063-5076

  • DOI: 10.1111/febs.13044
  • Primary Citation of Related Structures:
    4F7I

  • PubMed Abstract:
  • The three-dimensional structure of the enzyme 3-isopropylmalate dehydrogenase from the bacterium Thermus thermophilus in complex with Mn(2+) , its substrate isopropylmalate and its co-factor product NADH at 2.0 Å resolution features a fully closed conformation of the enzyme ...

    The three-dimensional structure of the enzyme 3-isopropylmalate dehydrogenase from the bacterium Thermus thermophilus in complex with Mn(2+) , its substrate isopropylmalate and its co-factor product NADH at 2.0 Å resolution features a fully closed conformation of the enzyme. Upon closure of the two domains, the substrate and the co-factor are brought into precise relative orientation and close proximity, with a distance between the C2 atom of the substrate and the C4N atom of the pyridine ring of the co-factor of approximately 3.0 Å. The structure further shows binding of a K(+) ion close to the active site, and provides an explanation for its known activating effect. Hence, this structure is an excellent mimic for the enzymatically competent complex. Using high-level QM/MM calculations, it may be demonstrated that, in the observed arrangement of the reactants, transfer of a hydride from the C2 atom of 3-isopropylmalate to the C4N atom of the pyridine ring of NAD(+) is easily possible, with an activation energy of approximately 15 kcal·mol(-1) . The activation energy increases by approximately 4-6 kcal·mol(-1) when the K(+) ion is omitted from the calculations. In the most plausible scenario, prior to hydride transfer the ε-amino group of Lys185 acts as a general base in the reaction, aiding the deprotonation reaction of 3-isopropylmalate prior to hydride transfer by employing a low-barrier proton shuttle mechanism involving a water molecule.


    Organizational Affiliation

    Institute of Organic Chemistry, Research Centre for Natural Sciences, Hungarian Academy of Sciences, Budapest, Hungary.



Macromolecules
Find similar proteins by:  (by identity cutoff)  |  Structure
Entity ID: 1
MoleculeChainsSequence LengthOrganismDetailsImage
3-isopropylmalate dehydrogenaseA, B, C, D359Thermus thermophilus HB8Mutation(s): 0
Gene Names: leuBTTHA1230
EC: 1.1.1.85
UniProt
Find proteins for Q5SIY4 (Thermus thermophilus (strain ATCC 27634 / DSM 579 / HB8))
Explore Q5SIY4
Go to UniProtKB:  Q5SIY4
Protein Feature View
Expand
  • Reference Sequence
Small Molecules
Ligands 7 Unique
IDChainsName / Formula / InChI Key2D Diagram3D Interactions
NAD
Query on NAD

Download Ideal Coordinates CCD File
F [auth A], IA [auth C], V [auth B], XA [auth D]NICOTINAMIDE-ADENINE-DINUCLEOTIDE
C21 H27 N7 O14 P2
BAWFJGJZGIEFAR-NNYOXOHSSA-N
 Ligand Interaction
MPO
Query on MPO

Download Ideal Coordinates CCD File
G [auth A], JA [auth C], YA [auth D]3[N-MORPHOLINO]PROPANE SULFONIC ACID
C7 H15 N O4 S
DVLFYONBTKHTER-UHFFFAOYSA-N
 Ligand Interaction
IPM
Query on IPM

Download Ideal Coordinates CCD File
E [auth A], HA [auth C], U [auth B], WA [auth D]3-ISOPROPYLMALIC ACID
C7 H12 O5
RNQHMTFBUSSBJQ-CRCLSJGQSA-N
 Ligand Interaction
GOL
Query on GOL

Download Ideal Coordinates CCD File
AA [auth B] , BA [auth B] , BB [auth D] , CA [auth B] , CB [auth D] , DA [auth B] , DB [auth D] , EA [auth B] ,
AA [auth B],  BA [auth B],  BB [auth D],  CA [auth B],  CB [auth D],  DA [auth B],  DB [auth D],  EA [auth B],  EB [auth D],  FB [auth D],  GA [auth B],  GB [auth D],  K [auth A],  L [auth A],  M [auth A],  N [auth A],  NA [auth C],  O [auth A],  OA [auth C],  P [auth A],  PA [auth C],  Q [auth A],  QA [auth C],  R [auth A],  RA [auth C],  S [auth A],  SA [auth C],  TA [auth C],  Z [auth B]
GLYCEROL
C3 H8 O3
PEDCQBHIVMGVHV-UHFFFAOYSA-N
 Ligand Interaction
MN
Query on MN

Download Ideal Coordinates CCD File
H [auth A], KA [auth C], W [auth B], ZA [auth D]MANGANESE (II) ION
Mn
WAEMQWOKJMHJLA-UHFFFAOYSA-N
 Ligand Interaction
EOH
Query on EOH

Download Ideal Coordinates CCD File
FA [auth B], HB [auth D], IB [auth D], T [auth A], UA [auth C], VA [auth C]ETHANOL
C2 H6 O
LFQSCWFLJHTTHZ-UHFFFAOYSA-N
 Ligand Interaction
K
Query on K

Download Ideal Coordinates CCD File
AB [auth D], I [auth A], J [auth A], LA [auth C], MA [auth C], X [auth B], Y [auth B]POTASSIUM ION
K
NPYPAHLBTDXSSS-UHFFFAOYSA-N
 Ligand Interaction
Experimental Data & Validation

Experimental Data

  • Method: X-RAY DIFFRACTION
  • Resolution: 2.00 Å
  • R-Value Free: 0.196
  • R-Value Work: 0.152
  • R-Value Observed: 0.152
  • Space Group: C 1 2 1
Unit Cell:
Length ( Å )Angle ( ˚ )
a = 148.38α = 90
b = 50.72β = 93.09
c = 178.24γ = 90
Software Package:
Software NamePurpose
MAR345dtbdata collection
MOLREPphasing
REFMACrefinement
XDSdata reduction
XSCALEdata scaling

Structure Validation

View Full Validation Report



Entry History

Deposition Data

Revision History  (Full details and data files)

  • Version 1.0: 2012-06-13
    Type: Initial release
  • Version 1.1: 2014-10-22
    Changes: Database references
  • Version 1.2: 2014-11-12
    Changes: Database references
  • Version 1.3: 2014-11-26
    Changes: Database references
  • Version 1.4: 2019-09-04
    Changes: Data collection
