4EN6

Crystal structure of HA70 (HA3) subcomponent of Clostridium botulinum type C progenitor toxin in complex with alpha 2-3-sialyllactose


Experimental Data Snapshot

  • Method: X-RAY DIFFRACTION
  • Resolution: 2.56 Å
  • R-Value Free: 0.219
  • R-Value Work: 0.188
  • R-Value Observed: 0.191

Starting Model: experimental
View more details

wwPDB Validation   3D Report Full Report


This is version 2.1 of the entry. See complete history


Literature

Carbohydrate recognition mechanism of HA70 from Clostridium botulinum deduced from X-ray structures in complexes with sialylated oligosaccharides

Yamashita, S.Yoshida, H.Uchiyama, N.Nakakita, Y.Nakakita, S.Tonozuka, T.Oguma, K.Nishikawa, A.Kamitori, S.

(2012) FEBS Lett 586: 2404-2410

  • DOI: https://doi.org/10.1016/j.febslet.2012.05.055
  • Primary Citation of Related Structures:
    4EN6, 4EN7, 4EN8, 4EN9

  • PubMed Abstract:

    Clostridium botulinum produces the botulinum neurotoxin, forming a large complex as progenitor toxins in association with non-toxic non-hemagglutinin and/or several different hemagglutinin (HA) subcomponents, HA33, HA17 and HA70, which bind to carbohydrate of glycoproteins from epithelial cells in the infection process. To elucidate the carbohydrate recognition mechanism of HA70, X-ray structures of HA70 from type C toxin (HA70/C) in complexes with sialylated oligosaccharides were determined, and a binding assay by the glycoconjugate microarray was performed. These results suggested that HA70/C can recognize both α2-3- and α2-6-sialylated oligosaccharides, and that it has a higher affinity for α2-3-sialylated oligosaccharides.


  • Organizational Affiliation

    Life Science Research Center and Faculty of Medicine, Kagawa University, 1750-1 Ikenobe, Kita-gun, Kagawa 761-0793, Japan.


Macromolecules
Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 1
MoleculeChains Sequence LengthOrganismDetailsImage
Hemagglutinin components HA-22/23/53224Clostridium botulinumMutation(s): 0
Gene Names: HA-70
UniProt
Find proteins for P46085 (Clostridium botulinum C phage)
Explore P46085
Go to UniProtKB:  P46085
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupP46085
Sequence Annotations
Expand
  • Reference Sequence
Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 2
MoleculeChains Sequence LengthOrganismDetailsImage
Hemagglutinin components HA-22/23/53420Clostridium botulinumMutation(s): 0
Gene Names: HA-70
UniProt
Find proteins for P46085 (Clostridium botulinum C phage)
Explore P46085
Go to UniProtKB:  P46085
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupP46085
Sequence Annotations
Expand
  • Reference Sequence
Oligosaccharides

Help

Entity ID: 3
MoleculeChains Length2D Diagram Glycosylation3D Interactions
N-acetyl-alpha-neuraminic acid-(2-3)-beta-D-galactopyranose-(1-4)-beta-D-glucopyranose
C
3N/A
Glycosylation Resources
GlyTouCan:  G91237TK
GlyCosmos:  G91237TK
GlyGen:  G91237TK
Experimental Data & Validation

Experimental Data

  • Method: X-RAY DIFFRACTION
  • Resolution: 2.56 Å
  • R-Value Free: 0.219
  • R-Value Work: 0.188
  • R-Value Observed: 0.191
  • Space Group: P 63
Unit Cell:
Length ( Å )Angle ( ˚ )
a = 175.596α = 90
b = 175.596β = 90
c = 80.779γ = 120
Software Package:
Software NamePurpose
HKL-2000data collection
MOLREPphasing
CNSrefinement
HKL-2000data reduction
HKL-2000data scaling

Structure Validation

View Full Validation Report



Entry History

Deposition Data

Revision History  (Full details and data files)

  • Version 1.0: 2012-06-06
    Type: Initial release
  • Version 1.1: 2013-07-03
    Changes: Database references
  • Version 2.0: 2020-07-29
    Type: Remediation
    Reason: Carbohydrate remediation
    Changes: Atomic model, Data collection, Database references, Derived calculations, Structure summary
  • Version 2.1: 2023-11-08
    Changes: Data collection, Database references, Refinement description, Structure summary
