4ELZ

CCDBVFI:GYRA14VFI


Experimental Data Snapshot

  • Method: X-RAY DIFFRACTION
  • Resolution: 2.20 Å
  • R-Value Free: 0.247
  • R-Value Work: 0.195
  • R-Value Observed: 0.197

Starting Model: experimental
View more details

wwPDB Validation   3D Report Full Report


This is version 1.1 of the entry. See complete history


Literature

Alternative interactions define gyrase specificity in the CcdB family.

De Jonge, N.Simic, M.Buts, L.Haesaerts, S.Roelants, K.Garcia-Pino, A.Sterckx, Y.De Greve, H.Lah, J.Loris, R.

(2012) Mol Microbiol 84: 965-978

  • DOI: https://doi.org/10.1111/j.1365-2958.2012.08069.x
  • Primary Citation of Related Structures:
    4ELY, 4ELZ

  • PubMed Abstract:

    Toxin-antitoxin (TA) modules are small operons associated with stress response of bacteria. F-plasmid CcdB(F) was the first TA toxin for which its target, gyrase, was identified. Plasmidic and chromosomal CcdBs belong to distinct families. Conserved residues crucial for gyrase poisoning activity of plasmidic CcdBs are not conserved among these families. Here we show that the chromosomal CcdB(Vfi) from Vibrio fischeri is an active gyrase poison that interacts with its target via an alternative energetic mechanism. Changes in the GyrA14-binding surface of the Vibrio and F-plasmid CcdB family members illustrate neutral drift where alternative interactions can be used to achieve the same functionality. Differences in affinity between V. fischeri and F-plasmid CcdB for gyrase and their corresponding CcdA antitoxin possibly reflect distinct roles for TA modules located on plasmids and chromosomes.


  • Organizational Affiliation

    Structural Biology Brussels, Department of Biotechnology, Vrije Universiteit Brussel, Pleinlaan 2, B-1050 Brussels, Belgium.


Macromolecules
Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 1
MoleculeChains Sequence LengthOrganismDetailsImage
DNA gyrase subunit A
A, B
153Aliivibrio fischeri ES114Mutation(s): 0
Gene Names: gyrAVF_1204
EC: 5.99.1.3 (PDB Primary Data), 5.6.2.2 (UniProt)
UniProt
Find proteins for Q5E5J7 (Aliivibrio fischeri (strain ATCC 700601 / ES114))
Explore Q5E5J7
Go to UniProtKB:  Q5E5J7
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupQ5E5J7
Sequence Annotations
Expand
  • Reference Sequence
Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 2
MoleculeChains Sequence LengthOrganismDetailsImage
CcdB
C, D
105Aliivibrio fischeri MJ11Mutation(s): 0
Gene Names: CcdBVFMJ11_A0651
UniProt
Find proteins for B5EU32 (Aliivibrio fischeri (strain MJ11))
Explore B5EU32
Go to UniProtKB:  B5EU32
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupB5EU32
Sequence Annotations
Expand
  • Reference Sequence
Small Molecules
Ligands 1 Unique
IDChains Name / Formula / InChI Key2D Diagram3D Interactions
GOL
Query on GOL

Download Ideal Coordinates CCD File
E [auth A]GLYCEROL
C3 H8 O3
PEDCQBHIVMGVHV-UHFFFAOYSA-N
Experimental Data & Validation

Experimental Data

  • Method: X-RAY DIFFRACTION
  • Resolution: 2.20 Å
  • R-Value Free: 0.247
  • R-Value Work: 0.195
  • R-Value Observed: 0.197
  • Space Group: P 21 21 21
Unit Cell:
Length ( Å )Angle ( ˚ )
a = 53.505α = 90
b = 94.59β = 90
c = 120.502γ = 90
Software Package:
Software NamePurpose
MAR345dtbdata collection
PHASERphasing
PHENIXrefinement
DENZOdata reduction
SCALEPACKdata scaling

Structure Validation

View Full Validation Report



Entry History

Deposition Data

Revision History  (Full details and data files)

  • Version 1.0: 2012-05-30
    Type: Initial release
  • Version 1.1: 2023-09-13
    Changes: Data collection, Database references, Derived calculations, Refinement description
