4DHV

Crystal structure of the Pyrococcus furiosus ferredoxin D14C variant containing the heterometallic [AgFe3S4] cluster


Experimental Data Snapshot

  • Method: X-RAY DIFFRACTION
  • Resolution: 1.95 Å
  • R-Value Free: 0.247
  • R-Value Work: 0.188
  • R-Value Observed: 0.191

wwPDB Validation   3D Report Full Report


This is version 1.3 of the entry. See complete history


Literature

Heterometallic [AgFe(3)S (4)] ferredoxin variants: synthesis, characterization, and the first crystal structure of an engineered heterometallic iron-sulfur protein.

Martic, M.Jakab-Simon, I.N.Haahr, L.T.Hagen, W.R.Christensen, H.E.

(2013) J Biol Inorg Chem 18: 261-276

  • DOI: 10.1007/s00775-012-0971-3
  • Primary Citation of Related Structures:
    4DHV

  • PubMed Abstract:
  • Heterometallic [AgFe(3)S(4)] iron-sulfur clusters assembled in wild-type Pyrococcus furiosus ferredoxin and two variants, D14C and D14H, are characterized. The crystal structure of the [AgFe(3)S(4)] D14C variant shows that the silver(I) ion is indeed part of the cluster and is coordinated to the thiolate group of residue 14 ...

    Heterometallic [AgFe(3)S(4)] iron-sulfur clusters assembled in wild-type Pyrococcus furiosus ferredoxin and two variants, D14C and D14H, are characterized. The crystal structure of the [AgFe(3)S(4)] D14C variant shows that the silver(I) ion is indeed part of the cluster and is coordinated to the thiolate group of residue 14. Cyclic voltammetry shows one redox pair with a reduction potential of +220 mV versus the standard hydrogen electrode which is assigned to the [AgFe(3)S(4)](2+/+) couple. The oxidized form of the [AgFe(3)S(4)] D14C variant is stable in the presence of dioxygen, whereas the oxidized forms of the [AgFe(3)S(4)] wild type and D14H variants convert to the [Fe(3)S(4)] ferredoxin form. The monovalent d (10) silver(I) ion stabilizes the [Fe(3)S(4)](+/0) cluster fragment, as opposed to divalent d (10) metal ions, resulting in more than 0.4 V difference in reduction potentials between the silver(I) and, e.g., zinc(II) heterometallic [MFe(3)S(4)] ferredoxins. The trend in reduction potentials for the variants containing the [AgFe(3)S(4)] cluster is wild type ≤ D14C < D14H and shows the same trend as reported for the variants containing the [Fe(3)S(4)] cluster, but is different from the D14C < D14H < wild type trend reported for the [Fe(4)S(4)] ferredoxin. The similarity in the reduction potential trend for the variants containing the heterometallic [AgFe(3)S(4)] cluster and the [Fe(3)S(4)] cluster can be rationalized in terms of the electrostatic influence of the residue 14 side chains, rather than the dissociation constant of this residue, as is the case for [Fe(4)S(4)] ferredoxins. The trends in reduction potentials are in line with there being no electronic coupling between the silver(I) ion and the Fe(3)S(4) fragment.


    Organizational Affiliation

    Department of Chemistry, Technical University of Denmark, Kemitorvet 207, 2800, Kongens Lyngby, Denmark.



Macromolecules
Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 1
MoleculeChainsSequence LengthOrganismDetailsImage
FerredoxinB [auth A],
A [auth B]
66Pyrococcus furiosus DSM 3638Mutation(s): 1
Gene Names: fdxAFerredoxinPF1909
UniProt
Find proteins for P29603 (Pyrococcus furiosus (strain ATCC 43587 / DSM 3638 / JCM 8422 / Vc1))
Explore P29603
Go to UniProtKB:  P29603
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupP29603
Protein Feature View
Expand
  • Reference Sequence
Small Molecules
Experimental Data & Validation

Experimental Data

  • Method: X-RAY DIFFRACTION
  • Resolution: 1.95 Å
  • R-Value Free: 0.247
  • R-Value Work: 0.188
  • R-Value Observed: 0.191
  • Space Group: P 21 21 21
Unit Cell:
Length ( Å )Angle ( ˚ )
a = 45.11α = 90
b = 49.33β = 90
c = 54.39γ = 90
Software Package:
Software NamePurpose
REFMACrefinement
PDB_EXTRACTdata extraction
XDSdata reduction
XSCALEdata scaling
MOLREPphasing

Structure Validation

View Full Validation Report



Entry History

Deposition Data

Revision History  (Full details and data files)

  • Version 1.0: 2013-01-16
    Type: Initial release
  • Version 1.1: 2013-02-06
    Changes: Database references
  • Version 1.2: 2013-03-06
    Changes: Database references
  • Version 1.3: 2018-03-07
    Changes: Data collection
