4CJ9

BurrH DNA-binding protein from Burkholderia rhizoxinica in its apo form


Experimental Data Snapshot

  • Method: X-RAY DIFFRACTION
  • Resolution: 2.21 Å
  • R-Value Free: 0.229
  • R-Value Work: 0.180
  • R-Value Observed: 0.181

wwPDB Validation   3D Report Full Report


This is version 1.1 of the entry. See complete history


Literature

Bud, a Helix-Loop-Helix DNA-Binding Domain for Genome Modification

Stella, S.Molina, R.Lopez-Mendez, B.Juillerat, A.Bertonati, C.Daboussi, F.Campos-Olivas, R.Duchateau, P.Montoya, G.

(2014) Acta Crystallogr D Biol Crystallogr 70: 2042

  • DOI: 10.1107/S1399004714011183
  • Primary Citation of Related Structures:
    4CJ9, 4CJA

  • PubMed Abstract:
  • DNA editing offers new possibilities in synthetic biology and biomedicine for modulation or modification of cellular functions to organisms. However, inaccuracy in this process may lead to genome damage. To address this important problem, a strategy allowing specific gene modification has been achieved through the addition, removal or exchange of DNA sequences using customized proteins and the endogenous DNA-repair machinery ...

    DNA editing offers new possibilities in synthetic biology and biomedicine for modulation or modification of cellular functions to organisms. However, inaccuracy in this process may lead to genome damage. To address this important problem, a strategy allowing specific gene modification has been achieved through the addition, removal or exchange of DNA sequences using customized proteins and the endogenous DNA-repair machinery. Therefore, the engineering of specific protein-DNA interactions in protein scaffolds is key to providing `toolkits' for precise genome modification or regulation of gene expression. In a search for putative DNA-binding domains, BurrH, a protein that recognizes a 19 bp DNA target, was identified. Here, its apo and DNA-bound crystal structures are reported, revealing a central region containing 19 repeats of a helix-loop-helix modular domain (BurrH domain; BuD), which identifies the DNA target by a single residue-to-nucleotide code, thus facilitating its redesign for gene targeting. New DNA-binding specificities have been engineered in this template, showing that BuD-derived nucleases (BuDNs) induce high levels of gene targeting in a locus of the human haemoglobin β (HBB) gene close to mutations responsible for sickle-cell anaemia. Hence, the unique combination of high efficiency and specificity of the BuD arrays can push forward diverse genome-modification approaches for cell or organism redesign, opening new avenues for gene editing.


    Organizational Affiliation

    Macromolecular Crystallography Group, Structural Biology and Biocomputing Programme, Spanish National Cancer Research Centre (CNIO), Calle de Melchor Fernández Almagro 3, 28029 Madrid, Spain.



Macromolecules
Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 1
MoleculeChainsSequence LengthOrganismDetailsImage
BURRHA, B794Mycetohabitans rhizoxinicaMutation(s): 0
UniProt
Find proteins for E5AV36 (Mycetohabitans rhizoxinica (strain DSM 19002 / CIP 109453 / HKI 454))
Explore E5AV36
Go to UniProtKB:  E5AV36
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupE5AV36
Protein Feature View
Expand
  • Reference Sequence
Small Molecules
Ligands 1 Unique
IDChainsName / Formula / InChI Key2D Diagram3D Interactions
SE
Query on SE

Download Ideal Coordinates CCD File
C [auth A],
D [auth A]
SELENIUM ATOM
Se
SPVXKVOXSXTJOY-UHFFFAOYSA-N
 Ligand Interaction
Modified Residues  1 Unique
IDChainsTypeFormula2D DiagramParent
MSE
Query on MSE
A, B L-PEPTIDE LINKINGC5 H11 N O2 SeMET
Experimental Data & Validation

Experimental Data

  • Method: X-RAY DIFFRACTION
  • Resolution: 2.21 Å
  • R-Value Free: 0.229
  • R-Value Work: 0.180
  • R-Value Observed: 0.181
  • Space Group: P 31
Unit Cell:
Length ( Å )Angle ( ˚ )
a = 73.314α = 90
b = 73.314β = 90
c = 268.337γ = 120
Software Package:
Software NamePurpose
PHENIXrefinement
XDSdata reduction
SCALAdata scaling
PHASERphasing

Structure Validation

View Full Validation Report



Entry History

Deposition Data

Revision History  (Full details and data files)

  • Version 1.0: 2014-07-09
    Type: Initial release
  • Version 1.1: 2014-07-23
    Changes: Database references
