4CGW

Second TPR of Spaghetti (RPAP3) bound to HSP90 peptide SRMEEVD

Experimental Data Snapshot

  • Method: X-RAY DIFFRACTION
  • Resolution: 3.00 Å
  • R-Value Free: 0.291
  • R-Value Work: 0.241
  • R-Value Observed: 0.244

wwPDB Validation   3D Report Full Report


This is version 1.1 of the entry. See complete history.


Literature

Structural Basis for Phosphorylation-Dependent Recruitment of Tel2 to Hsp90 by Pih1.

Pal, M., Morgan, M., Phelps, S.E., Roe, S.M., Parry-Morris, S., Downs, J.A., Polier, S., Pearl, L.H., Prodromou, C.

(2014) Structure 22: 805

  • DOI: 10.1016/j.str.2014.04.001
  • Primary Citation of Related Structures:
    4CGU, 4CGV, 4CGW, 4CHH, 4CKT, 4CSE, 4CV4

  • PubMed Abstract:

    • Client protein recruitment to the Hsp90 system depends on cochaperones that bind the client and Hsp90 simultaneously and facilitate their interaction. Hsp90 involvement in the assembly of snoRNPs, RNA polymerases, PI3-kinase-like kinases, and chromatin remodeling complexes depends on the TTT (Tel2-Tti1-Tti2), and R2TP complexes-consisting of the AAA-ATPases Rvb1 and Rvb2, Tah1 (Spagh/RPAP3 in metazoa), and Pih1 (Pih1D1 in humans)-that together provide the connection to Hsp90 ...

    Client protein recruitment to the Hsp90 system depends on cochaperones that bind the client and Hsp90 simultaneously and facilitate their interaction. Hsp90 involvement in the assembly of snoRNPs, RNA polymerases, PI3-kinase-like kinases, and chromatin remodeling complexes depends on the TTT (Tel2-Tti1-Tti2), and R2TP complexes-consisting of the AAA-ATPases Rvb1 and Rvb2, Tah1 (Spagh/RPAP3 in metazoa), and Pih1 (Pih1D1 in humans)-that together provide the connection to Hsp90. The biochemistry underlying R2TP function is still poorly understood. Pih1 in particular, at the heart of the complex, has not been described at a structural level, nor have the multiple protein-protein interactions it mediates been characterized. Here we present a structural and biochemical analysis of Hsp90-Tah1-Pih1, Hsp90-Spagh, and Pih1D1-Tel2 complexes that reveal a domain in Pih1D1 specific for binding CK2 phosphorylation sites, and together define the structural basis by which the R2TP complex connects the Hsp90 chaperone system to the TTT complex.

    Organizational Affiliation:

    MRC Genome Damage and Stability Centre, School of Life Sciences, University of Sussex, Falmer, Brighton BN1 9RQ, UK. Electronic address: chris.prodromou@sussex.ac.uk.



Macromolecules
Find similar proteins by:
(by identity cutoff)  |  3D Structure
Entity ID: 1
MoleculeChainsSequence LengthOrganismDetailsImage
RNA POLYMERASE II-ASSOCIATED PROTEIN 3A, B117Homo sapiensMutation(s): 0
Gene Names: RPAP3
UniProt & NIH Common Fund Data Resources
Find proteins for Q9H6T3 (Homo sapiens)
Explore Q9H6T3
Go to UniProtKB:  Q9H6T3
PHAROS:  Q9H6T3
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupQ9H6T3
Protein Feature View
Expand
  • Reference Sequence

Find similar proteins by:  Sequence   |   3D Structure

Entity ID: 2
MoleculeChainsSequence LengthOrganismDetailsImage
HEAT SHOCK PROTEIN HSP 90-ALPHAC, D7Homo sapiensMutation(s): 0
Gene Names: HSP90AA1, HSP90A, HSPC1, HSPCA
UniProt & NIH Common Fund Data Resources
Find proteins for P07900 (Homo sapiens)
Explore P07900
Go to UniProtKB:  P07900
PHAROS:  P07900
Entity Groups
UniProt GroupP07900
Protein Feature View
Expand
  • Reference Sequence
Experimental Data & Validation

Experimental Data

  • Method: X-RAY DIFFRACTION
  • Resolution: 3.00 Å
  • R-Value Free: 0.291
  • R-Value Work: 0.241
  • R-Value Observed: 0.244
  • Space Group: P 21 21 21
Unit Cell:
Length ( Å )Angle ( ˚ )
a = 63.57α = 90
b = 96.51β = 90
c = 52.09γ = 90
Software Package:
Software NamePurpose
PHENIXrefinement
xia2data reduction
xia2data scaling
PHASERphasing

Structure Validation

View Full Validation Report



View more in-depth experimental data

Entry History

Deposition Data

  • Deposited Date: 2013-11-26
  • Released Date: 2014-05-14
    • Deposition Author(s): Roe, S.M., Pal, M.

Revision History  (Full details and data files)

  • Version 1.0: 2014-05-14
    Type: Initial release
  • Version 1.1: 2014-06-25
    Changes: Database references
