4C50

Crystal Structure of the Catalase-Peroxidase (KatG) D137S mutant from Mycobacterium Tuberculosis

• PDB DOI: https://doi.org/10.2210/pdb4C50/pdb

• Classification: OXIDOREDUCTASE
• Organism(s): Mycobacterium tuberculosis H37Rv
• Expression System: Escherichia coli
• Mutation(s): Yes


• Deposited: 2013-09-10 Released: 2013-11-13
• Deposition Author(s): Hersleth, H.-P., Zhao, X., Magliozzo, R.S., Andersson, K.K.

---

Experimental Data Snapshot

• Method: X-RAY DIFFRACTION
• Resolution: 2.50 Å
• R-Value Free: 0.311
• R-Value Work: 0.264
• R-Value Observed: 0.266

Biological Assembly 1

Global Symmetry: Cyclic - C2  (Explore in 3D)
Global Stoichiometry: Homo 2-mer - A2

Biological assembly 1 assigned by authors and generated by PISA (software)

Macromolecule Content

• Total Structure Weight: 162.79 kDa
• Atom Count: 11,241
• Modelled Residue Count: 1,432
• Deposited Residue Count: 1,480
• Unique protein chains: 1

Macromolecules

Entity ID: 1
Molecule	Chains	Sequence Length	Organism	Details	Image
CATALASE-PEROXIDASE	A, B	740	Mycobacterium tuberculosis H37Rv	Mutation(s): 1  EC: 1.11.1.21
UniProt
Find proteins for P9WIE5 (Mycobacterium tuberculosis (strain ATCC 25618 / H37Rv)) Explore P9WIE5  Go to UniProtKB:  P9WIE5

Small Molecules

Ligands 3 Unique
ID	Chains	Name / Formula / InChI Key	2D Diagram
HEM	D [auth A], F [auth B]	PROTOPORPHYRIN IX CONTAINING FE C34 H32 Fe N4 O4 KABFMIBPWCXCRK-RGGAHWMASA-L
GLC	C [auth A]	alpha-D-glucopyranose C6 H12 O6 WQZGKKKJIJFFOK-DVKNGEFBSA-N
ACT	E [auth A]	ACETATE ION C2 H3 O2 QTBSBXVTEAMEQO-UHFFFAOYSA-M

Experimental Data & Validation

Experimental Data

• Method: X-RAY DIFFRACTION
• Resolution: 2.50 Å
• R-Value Free: 0.311
• R-Value Work: 0.264
• R-Value Observed: 0.266
• Space Group: P 4₂ 2₁ 2

Unit Cell:

Length ( Å )	Angle ( ˚ )
a = 150.59	α = 90
b = 150.59	β = 90
c = 157.35	γ = 90

Software Package:

Software Name	Purpose
REFMAC	refinement
MOSFLM	data reduction
Aimless	data scaling
PHASER	phasing

Structure Validation

Entry History

Deposition Data

• Released Date: 2013-11-13
Deposition Author(s): Hersleth, H.-P., Zhao, X., Magliozzo, R.S., Andersson, K.K.

Revision History

• Version 1.0: 2013-11-13
  Type: Initial release

• Version 1.1: 2013-11-27
  Changes: Database references
• Version 1.2: 2019-10-30
  Changes: Advisory, Data collection, Derived calculations, Other
• Version 1.3: 2020-07-29
  Type: Remediation
  Reason: Carbohydrate remediation
  Changes: Data collection, Derived calculations, Structure summary
• Version 1.4: 2023-12-20
  Changes: Data collection, Database references, Refinement description, Structure summary
