4A61

ParM from plasmid R1 in complex with AMPPNP


Experimental Data Snapshot

  • Method: X-RAY DIFFRACTION
  • Resolution: 2 Å
  • R-Value Free: 0.253
  • R-Value Work: 0.209

wwPDB Validation 3D Report Full Report


This is version 1.1 of the entry. See complete history

Literature

A Bipolar Spindle of Antiparallel Parm Filaments Drives Bacterial Plasmid Segregation.

Gayathri, P.Fujii, T.Moller-Jensen, J.Van Den Ent, F.Namba, K.Lowe, J.

(2012) Science 338: 1334

  • DOI: 10.1126/science.1229091
  • Primary Citation of Related Structures:

  • PubMed Abstract:
  • To ensure their stable inheritance by daughter cells during cell division, bacterial low-copy-number plasmids make simple DNA segregating machines that use an elongating protein filament between sister plasmids. In the ParMRC system of the Escherichi ...

    To ensure their stable inheritance by daughter cells during cell division, bacterial low-copy-number plasmids make simple DNA segregating machines that use an elongating protein filament between sister plasmids. In the ParMRC system of the Escherichia coli R1 plasmid, ParM, an actinlike protein, forms the spindle between ParRC complexes on sister plasmids. By using a combination of structural work and total internal reflection fluorescence microscopy, we show that ParRC bound and could accelerate growth at only one end of polar ParM filaments, mechanistically resembling eukaryotic formins. The architecture of ParM filaments enabled two ParRC-bound filaments to associate in an antiparallel orientation, forming a bipolar spindle. The spindle elongated as a bundle of at least two antiparallel filaments, thereby pushing two plasmid clusters toward the poles.


    Organizational Affiliation

    Medical Research Council Laboratory of Molecular Biology, Hills Road, Cambridge CB2 0QH, UK.




Macromolecules

Find similar proteins by: Sequence  |  Structure

Entity ID: 1
MoleculeChainsSequence LengthOrganismDetails
PLASMID SEGREGATION PROTEIN PARM
A
326Escherichia coliMutation(s): 1
Gene Names: parM (stbA)
Find proteins for P11904 (Escherichia coli)
Go to UniProtKB:  P11904
Small Molecules
Ligands 2 Unique
IDChainsName / Formula / InChI Key2D Diagram3D Interactions
ANP
Query on ANP

Download SDF File
Download CCD File
A
PHOSPHOAMINOPHOSPHONIC ACID-ADENYLATE ESTER
C10 H17 N6 O12 P3
PVKSNHVPLWYQGJ-KQYNXXCUSA-N
 Ligand Interaction
MG
Query on MG

Download SDF File
Download CCD File
A
MAGNESIUM ION
Mg
JLVVSXFLKOJNIY-UHFFFAOYSA-N
 Ligand Interaction
Experimental Data & Validation

Experimental Data

  • Method: X-RAY DIFFRACTION
  • Resolution: 2 Å
  • R-Value Free: 0.253
  • R-Value Work: 0.209
  • Space Group: P 43 2 2
Unit Cell:
Length (Å)Angle (°)
a = 63.541α = 90.00
b = 63.541β = 90.00
c = 164.093γ = 90.00
Software Package:
Software NamePurpose
MOSFLMdata reduction
SCALAdata scaling
PHENIXrefinement
CNSphasing

Structure Validation

View Full Validation Report or Ramachandran Plots



Entry History

Deposition Data

Revision History

  • Version 1.0: 2012-11-07
    Type: Initial release
  • Version 1.1: 2012-12-19
    Type: Database references
