Biological Assembly 1

 3D View: Structure | Electron Density | Validation Report | Ligand Interaction

Global Symmetry: Cyclic - C2  (3D View)
Global Stoichiometry: Homo 2-mer - A2

Biological assembly 1 assigned by authors and generated by PISA (software)

Macromolecule Content

• Total Structure Weight: 43.48 kDa
• Atom Count: 2961
• Modelled Residue Count: 354
• Deposited Residue Count: 382
• Unique protein chains: 1

3ZPG

Acinetobacter baumannii RibD, form 2

• DOI: 10.2210/pdb3ZPG/pdb

• Classification: HYDROLASE
• Organism(s): Acinetobacter baumannii
• Expression System: Escherichia coli BL21(DE3)
• Mutation(s): No


• Deposited: 2013-02-27 Released: 2013-03-27
• Deposition Author(s): Dawson, A., Trumper, P., Chrysostomou, G., Hunter, W.N.

---

Experimental Data Snapshot

• Method: X-RAY DIFFRACTION
• Resolution: 1.99 Å
• R-Value Free: 0.237
• R-Value Work: 0.214
• R-Value Observed: 0.215

Literature

Structure of Diaminohydroxyphosphoribosylaminopyrimidine Deaminase/5-Amino-6-(5-Phosphoribosylamino)Uracil Reductase from Acinetobacter Baumannii.

Dawson, A., Trumper, P., Chrysostomou, G., Hunter, W.N.

(2013) Acta Crystallogr Sect F Struct Biol Cryst Commun 69: 611

• PubMed: 23722836
• DOI: 10.1107/S174430911301292X
• Primary Citation of Related Structures:
  3ZPC, 3ZPG


• PubMed Abstract:


The bifunctional diaminohydroxyphosphoribosylaminopyrimidine deaminase/5-amino-6-(5-phosphoribosylamino)uracil reductase (RibD) represents a potential antibacterial drug target. The structure of recombinant Acinetobacter baumannii RibD is reported in orthorhombic and tetragonal crystal forms at 2.2 and 2.0 Å resolution, respectively. Comparisons with orthologous structures in the Protein Data Bank indicated close similarities. The tetragonal crystal form was obtained in the presence of guanosine monophosphate, which surprisingly was observed to occupy the adenine-binding site of the reductase domain.

---

Organizational Affiliation:

Division of Biological Chemistry and Drug Discovery, College of Life Sciences, University of Dundee, Dundee DD1 5EH, Scotland.

Macromolecules

Entity ID: 1
Molecule	Chains	Sequence Length	Organism	Details	Image
RIBD	A	382	Acinetobacter baumannii	Mutation(s): 0  EC: 3.5.4.26 (PDB Primary Data), 1.1.1.193 (PDB Primary Data)
UniProt
Find proteins for D0CB74 (Acinetobacter baumannii (strain ATCC 19606 / DSM 30007 / JCM 6841 / CCUG 19606 / CIP 70.34 / NBRC 109757 / NCIMB 12457 / NCTC 12156 / 81)) Explore D0CB74  Go to UniProtKB:  D0CB74

Small Molecules

Ligands 7 Unique
ID	Chains	Name / Formula / InChI Key	2D Diagram
5GP (Subject of Investigation/LOI)	E [auth A], K [auth A]	GUANOSINE-5'-MONOPHOSPHATE C10 H14 N5 O8 P RQFCJASXJCIDSX-UUOKFMHZSA-N
CAC	H [auth A]	CACODYLATE ION C2 H6 As O2 OGGXGZAMXPVRFZ-UHFFFAOYSA-M
SO4	C [auth A], D [auth A]	SULFATE ION O4 S QAOWNCQODCNURD-UHFFFAOYSA-L
OXL	F [auth A], G [auth A]	OXALATE ION C2 O4 MUBZPKHOEPUJKR-UHFFFAOYSA-L
ZN	B [auth A]	ZINC ION Zn PTFCDOFLOPIGGS-UHFFFAOYSA-N
ACT	J [auth A]	ACETATE ION C2 H3 O2 QTBSBXVTEAMEQO-UHFFFAOYSA-M
CL	I [auth A]	CHLORIDE ION Cl VEXZGXHMUGYJMC-UHFFFAOYSA-M

Experimental Data & Validation

Experimental Data

• Method: X-RAY DIFFRACTION
• Resolution: 1.99 Å
• R-Value Free: 0.237
• R-Value Work: 0.214
• R-Value Observed: 0.215
• Space Group: P 4₃ 2₁ 2

Unit Cell:

Length ( Å )	Angle ( ˚ )
a = 72.998	α = 90
b = 72.998	β = 90
c = 201.456	γ = 90

Software Package:

Software Name	Purpose
REFMAC	refinement
XDS	data reduction
SCALA	data scaling
PHASER	phasing

Structure Validation

Ligand Structure Quality Assessment

Entry History

Deposition Data

• Deposited Date: 2013-02-27
• Released Date: 2013-03-27
Deposition Author(s): Dawson, A., Trumper, P., Chrysostomou, G., Hunter, W.N.

Revision History

• Version 1.0: 2013-03-27
  Type: Initial release

• Version 1.1: 2013-06-12
  Changes: Database references
• Version 1.2: 2017-06-28
  Changes: Data collection
