Crystal Structure of the CRISPR-Cas RNA Silencing Cmr Complex Bound to a Target Analog


Experimental Data Snapshot

  • Method: X-RAY DIFFRACTION
  • Resolution: 2.10 Å
  • R-Value Free: 0.246
  • R-Value Work: 0.208
  • R-Value Observed: 0.210

wwPDB Validation   3D Report Full Report


This is version 1.2 of the entry. See complete history


Literature

Crystal structure of the CRISPR-Cas RNA silencing Cmr complex bound to a target analog.

Osawa, T.Inanaga, H.Sato, C.Numata, T.

(2015) Mol Cell 58: 418-430

  • DOI: https://doi.org/10.1016/j.molcel.2015.03.018
  • Primary Citation of Related Structures:
    3X1L

  • PubMed Abstract:

    In prokaryotes, Clustered regularly interspaced short palindromic repeat (CRISPR)-derived RNAs (crRNAs), together with CRISPR-associated (Cas) proteins, capture and degrade invading genetic materials. In the type III-B CRISPR-Cas system, six Cas proteins (Cmr1-Cmr6) and a crRNA form an RNA silencing Cmr complex. Here we report the 2.1 Å crystal structure of the Cmr1-deficient, functional Cmr complex bound to single-stranded DNA, a substrate analog complementary to the crRNA guide. Cmr3 recognizes the crRNA 5' tag and defines the start position of the guide-target duplex, using its idiosyncratic loops. The β-hairpins of three Cmr4 subunits intercalate within the duplex, causing nucleotide displacements with 6 nt intervals, and thus periodically placing the scissile bonds near the crucial aspartate of Cmr4. The structure reveals the mechanism for specifying the periodic target cleavage sites from the crRNA 5' tag and provides insights into the assembly of the type III interference machineries and the evolution of the Cmr and Cascade complexes.


  • Organizational Affiliation

    Biomedical Research Institute, National Institute of Advanced Industrial Science and Technology (AIST), 1-1-1 Higashi, Tsukuba-shi, Ibaraki 305-8566, Japan. Electronic address: t-numata@aist.go.jp.


Macromolecules

Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 1
MoleculeChains Sequence LengthOrganismDetailsImage
CRISPR system Cmr subunit Cmr2677Pyrococcus furiosus DSM 3638Mutation(s): 0
Gene Names: cmr2PF1129
UniProt
Find proteins for Q8U1S6 (Pyrococcus furiosus (strain ATCC 43587 / DSM 3638 / JCM 8422 / Vc1))
Explore Q8U1S6
Go to UniProtKB:  Q8U1S6
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupQ8U1S6
Sequence Annotations
Expand
  • Reference Sequence
Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 2
MoleculeChains Sequence LengthOrganismDetailsImage
CRISPR system Cmr subunit Cmr3322Pyrococcus furiosus DSM 3638Mutation(s): 0
Gene Names: cmr3PF1128
UniProt
Find proteins for Q8U1S7 (Pyrococcus furiosus (strain ATCC 43587 / DSM 3638 / JCM 8422 / Vc1))
Explore Q8U1S7
Go to UniProtKB:  Q8U1S7
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupQ8U1S7
Sequence Annotations
Expand
  • Reference Sequence
Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 3
MoleculeChains Sequence LengthOrganismDetailsImage
Cmr4
C, D, E
357Archaeoglobus fulgidus DSM 4304Mutation(s): 0
Gene Names: AF_1863
UniProt
Find proteins for O28416 (Archaeoglobus fulgidus (strain ATCC 49558 / DSM 4304 / JCM 9628 / NBRC 100126 / VC-16))
Explore O28416
Go to UniProtKB:  O28416
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupO28416
Sequence Annotations
Expand
  • Reference Sequence
Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 4
MoleculeChains Sequence LengthOrganismDetailsImage
CRISPR system Cmr subunit Cmr5
F, G
155Archaeoglobus fulgidus DSM 4304Mutation(s): 0
Gene Names: AF_1861
UniProt
Find proteins for O28417 (Archaeoglobus fulgidus (strain ATCC 49558 / DSM 4304 / JCM 9628 / NBRC 100126 / VC-16))
Explore O28417
Go to UniProtKB:  O28417
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupO28417
Sequence Annotations
Expand
  • Reference Sequence
Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 5
MoleculeChains Sequence LengthOrganismDetailsImage
Cmr6349Archaeoglobus fulgidus DSM 4304Mutation(s): 0
Gene Names: AF_1861
UniProt
Find proteins for O28418 (Archaeoglobus fulgidus (strain ATCC 49558 / DSM 4304 / JCM 9628 / NBRC 100126 / VC-16))
Explore O28418
Go to UniProtKB:  O28418
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupO28418
Sequence Annotations
Expand
  • Reference Sequence
Find similar nucleic acids by:  (by identity cutoff)  |  3D Structure
Entity ID: 6
MoleculeChains LengthOrganismImage
RNA (32-MER)39Pyrococcus furiosus COM1
Sequence Annotations
Expand
  • Reference Sequence
Find similar nucleic acids by:  (by identity cutoff)  |  3D Structure
Entity ID: 7
MoleculeChains LengthOrganismImage
DNA (5'-D(*TP*GP*CP*TP*CP*TP*CP*AP*GP*CP*CP*GP*CP*AP*AP*GP*GP*AP*CP*CP*GP*CP*AP*TP*AP*CP*TP*AP*CP*AP*A)-3')31synthetic construct
Sequence Annotations
Expand
  • Reference Sequence
Experimental Data & Validation

Experimental Data

  • Method: X-RAY DIFFRACTION
  • Resolution: 2.10 Å
  • R-Value Free: 0.246
  • R-Value Work: 0.208
  • R-Value Observed: 0.210
  • Space Group: P 1
Unit Cell:
Length ( Å )Angle ( ˚ )
a = 75.489α = 90.32
b = 76.215β = 104.83
c = 139.188γ = 118.58
Software Package:
Software NamePurpose
XDSdata scaling
PHENIXmodel building
PHENIXrefinement
XDSdata reduction
PHENIXphasing

Structure Validation

View Full Validation Report



Entry History

Deposition Data

Revision History  (Full details and data files)

  • Version 1.0: 2015-05-13
    Type: Initial release
  • Version 1.1: 2015-05-20
    Changes: Structure summary
  • Version 1.2: 2022-08-24
    Changes: Database references, Derived calculations
