3X15

Dimeric Aquifex aeolicus cytochrome c555


Experimental Data Snapshot

  • Method: X-RAY DIFFRACTION
  • Resolution: 1.60 Å
  • R-Value Free: 0.214
  • R-Value Work: 0.150
  • R-Value Observed: 0.154

wwPDB Validation   3D Report Full Report


Ligand Structure Quality Assessment


This is version 1.2 of the entry. See complete history


Literature

Change in structure and ligand binding properties of hyperstable cytochrome c555 from Aquifex aeolicus by domain swapping

Yamanaka, M.Nagao, S.Komori, H.Higuchi, Y.Hirota, S.

(2015) Protein Sci 24: 366-375

  • DOI: https://doi.org/10.1002/pro.2627
  • Primary Citation of Related Structures:
    3X15

  • PubMed Abstract:

    Cytochrome c555 from hyperthermophilic bacteria Aquifex aeolicus (AA cyt c555 ) is a hyperstable protein belonging to the cyt c protein family, which possesses a unique long 310 -α-310 helix containing the heme-ligating Met61. Herein, we show that AA cyt c555 forms dimers by swapping the region containing the extra 310 -α-310 helix and C-terminal α-helix. The asymmetric unit of the crystal of dimeric AA cyt c555 contained two dimer structures, where the structure of the hinge region (Val53-Lys57) was different among all four protomers. Dimeric AA cyt c555 dissociated to monomers at 92 ± 1°C according to DSC measurements, showing that the dimer was thermostable. According to CD measurements, the secondary structures of dimeric AA cyt c555 were maintained at pH 2.2-11.0. CN(-) and CO bound to dimeric AA cyt c555 in the ferric and ferrous states, respectively, owing to the flexibility of the hinge region close to Met61 in the dimer, whereas these ligands did not bind to the monomer under the same conditions. In addition, CN(-) and CO bound to the oxidized and reduced dimer at neutral pH and a wide range of pH (pH 2.2-11.0), respectively, in a wide range of temperature (25-85°C), owing to the thermostability and pH tolerance of the dimer. These results show that the ligand binding character of hyperstable AA cyt c555 changes upon dimerization by domain swapping.


  • Organizational Affiliation

    Graduate School of Materials Science, Nara Institute of Science and Technology, Ikoma, Nara, 630-0192, Japan.


Macromolecules
Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 1
MoleculeChains Sequence LengthOrganismDetailsImage
Cytochrome c552A,
B [auth D],
C [auth G],
D [auth J]
87Aquifex aeolicus VF5Mutation(s): 0
Gene Names: cycB2aq_1550
UniProt
Find proteins for O67504 (Aquifex aeolicus (strain VF5))
Explore O67504
Go to UniProtKB:  O67504
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupO67504
Sequence Annotations
Expand
  • Reference Sequence
Experimental Data & Validation

Experimental Data

  • Method: X-RAY DIFFRACTION
  • Resolution: 1.60 Å
  • R-Value Free: 0.214
  • R-Value Work: 0.150
  • R-Value Observed: 0.154
  • Space Group: P 1 21 1
Unit Cell:
Length ( Å )Angle ( ˚ )
a = 57.591α = 90
b = 54.464β = 114.47
c = 65.403γ = 90
Software Package:
Software NamePurpose
HKL-2000data collection
MOLREPphasing
REFMACrefinement
HKL-2000data reduction
HKL-2000data scaling

Structure Validation

View Full Validation Report



Ligand Structure Quality Assessment


Entry History

Deposition Data

Revision History  (Full details and data files)

  • Version 1.0: 2015-01-28
    Type: Initial release
  • Version 1.1: 2015-03-04
    Changes: Database references
  • Version 1.2: 2023-11-08
    Changes: Data collection, Database references, Derived calculations, Refinement description
