3WOZ

Crystal structure of CLASP2 TOG domain (TOG3)


Experimental Data Snapshot

  • Method: X-RAY DIFFRACTION
  • Resolution: 2.20 Å
  • R-Value Free: 0.279
  • R-Value Work: 0.241
  • R-Value Observed: 0.243

wwPDB Validation   3D Report Full Report


This is version 1.1 of the entry. See complete history


Literature

CLASP2 Has Two Distinct TOG Domains That Contribute Differently to Microtubule Dynamics

Maki, T.Grimaldi, A.D.Fuchigami, S.Kaverina, I.Hayashi, I.

(2015) J Mol Biol 427: 2379-2395

  • DOI: 10.1016/j.jmb.2015.05.012
  • Primary Citation of Related Structures:
    3WOY, 3WOZ

  • PubMed Abstract:
  • CLIP-associated proteins CLASPs are mammalian microtubule (MT) plus-end tracking proteins (+TIPs) that promote MT rescue in vivo. Their plus-end localization is dependent on other +TIPs, EB1 and CLIP-170, but in the leading edge of the cell, CLASPs display lattice-binding activity ...

    CLIP-associated proteins CLASPs are mammalian microtubule (MT) plus-end tracking proteins (+TIPs) that promote MT rescue in vivo. Their plus-end localization is dependent on other +TIPs, EB1 and CLIP-170, but in the leading edge of the cell, CLASPs display lattice-binding activity. MT association of CLASPs is suggested to be regulated by multiple TOG (tumor overexpressed gene) domains and by the serine-arginine (SR)-rich region, which contains binding sites for EB1. Here, we report the crystal structures of the two TOG domains of CLASP2. Both domains consist of six HEAT repeats, which are similar to the canonical paddle-like tubulin-binding TOG domains, but have arched conformations. The degrees and directions of curvature are different between the two TOG domains, implying that they have distinct roles in MT binding. Using biochemical, molecular modeling and cell biological analyses, we have investigated the interactions between the TOG domains and αβ-tubulin and found that each domain associates differently with αβ-tubulin. Our findings suggest that, by varying the degrees of domain curvature, the TOG domains may distinguish the structural conformation of the tubulin dimer, discriminate between different states of MT dynamic instability and thereby function differentially as stabilizers of MTs.


    Organizational Affiliation

    Department of Medical Life Science, Yokohama City University, 1-7-29 Suehiro, Tsurumi, Yokohama, Kanagawa 230-0045, Japan. Electronic address: ihay@tsurumi.yokohama-cu.ac.jp.



Macromolecules
Find similar proteins by:  (by identity cutoff)  |  Structure
Entity ID: 1
MoleculeChainsSequence LengthOrganismDetailsImage
CLIP-associating protein 2A, B, C, D232Mus musculusMutation(s): 0
Gene Names: Clasp2Kiaa0627
Find proteins for Q8BRT1 (Mus musculus)
Explore Q8BRT1
Go to UniProtKB:  Q8BRT1
Protein Feature View
Expand
  • Reference Sequence
Small Molecules
Modified Residues  1 Unique
IDChainsTypeFormula2D DiagramParent
MSE
Query on MSE
A, B, C, DL-PEPTIDE LINKINGC5 H11 N O2 SeMET
Experimental Data & Validation

Experimental Data

  • Method: X-RAY DIFFRACTION
  • Resolution: 2.20 Å
  • R-Value Free: 0.279
  • R-Value Work: 0.241
  • R-Value Observed: 0.243
  • Space Group: P 1 21 1
Unit Cell:
Length ( Å )Angle ( ˚ )
a = 50.896α = 90
b = 122.317β = 94.67
c = 86.514γ = 90
Software Package:
Software NamePurpose
HKL-2000data collection
SOLVEphasing
REFMACrefinement
HKL-2000data reduction
HKL-2000data scaling

Structure Validation

View Full Validation Report



Entry History

Deposition Data

  • Deposited Date: 2014-01-06
  • Released Date: 2015-05-27
  • Deposition Author(s): Hayashi, I., Maki, T.

Revision History  (Full details and data files)

  • Version 1.0: 2015-05-27
    Type: Initial release
  • Version 1.1: 2018-10-17
    Changes: Data collection, Database references
