3WKN

Crystal structure of the artificial protein AFFinger p17 (AF.p17) complexed with Fc fragment of human IgG


Experimental Data Snapshot

  • Method: X-RAY DIFFRACTION
  • Resolution: 2.90 Å
  • R-Value Free: 0.242
  • R-Value Work: 0.200
  • R-Value Observed: 0.202

wwPDB Validation   3D Report Full Report


This is version 2.0 of the entry. See complete history


Literature

Adaptive Assembly: Maximizing the Potential of a Given Functional Peptide with a Tailor-Made Protein Scaffold.

Watanabe, H.Honda, S.

(2015) Chem Biol

  • DOI: 10.1016/j.chembiol.2015.07.015
  • Primary Citation of Related Structures:
    3WKN

  • PubMed Abstract:
  • Protein engineering that exploits known functional peptides holds great promise for generating novel functional proteins. Here we propose a combinatorial approach, termed adaptive assembly, which provides a tailor-made protein scaffold for a given functional peptide ...

    Protein engineering that exploits known functional peptides holds great promise for generating novel functional proteins. Here we propose a combinatorial approach, termed adaptive assembly, which provides a tailor-made protein scaffold for a given functional peptide. A combinatorial library was designed to create a tailor-made scaffold, which was generated from β hairpins derived from a 10-residue minimal protein "chignolin" and randomized amino acid sequences. We applied adaptive assembly to a peptide with low affinity for the Fc region of human immunoglobulin G, generating a 54-residue protein AF.p17 with a 40,600-fold enhanced affinity. The crystal structure of AF.p17 complexed with the Fc region revealed that the scaffold fixed the active conformation with a unique structure composed of a short α helix, β hairpins, and a loop-like structure. Adaptive assembly can take full advantage of known peptides as assets for generating novel functional proteins.


    Organizational Affiliation

    Biomedical Research Institute, the National Institute of Advanced Industrial Science and Technology (AIST), 1-1-1, Higashi, Tsukuba, Ibaraki 305-8566, Japan. Electronic address: s.honda@aist.go.jp.



Macromolecules
Find similar proteins by:  (by identity cutoff)  |  Structure
Entity ID: 1
MoleculeChainsSequence LengthOrganismDetailsImage
Ig gamma-1 chain C regionE [auth A], B, A [auth C], F [auth D], I, J, M, N212Homo sapiensMutation(s): 0
Gene Names: IGHG1
UniProt & NIH Common Fund Data Resources
Find proteins for P01857 (Homo sapiens)
Explore P01857
Go to UniProtKB:  P01857
PHAROS:  P01857
Protein Feature View
Expand
  • Reference Sequence
Find similar proteins by:  (by identity cutoff)  |  Structure
Entity ID: 2
MoleculeChainsSequence LengthOrganismDetailsImage
AFFinger p17C [auth E], D [auth F], G, H, K, L, O, P54synthetic constructMutation(s): 0
Protein Feature View
Expand
  • Reference Sequence
Oligosaccharides

Help

Entity ID: 3
MoleculeChainsChain Length2D DiagramGlycosylation3D Interactions
beta-D-galactopyranose-(1-4)-2-acetamido-2-deoxy-beta-D-glucopyranose-(1-2)-alpha-D-mannopyranose-(1-6)-[2-acetamido-2-deoxy-beta-D-glucopyranose-(1-2)-alpha-D-mannopyranose-(1-3)]beta-D-mannopyranose-(1-4)-2-acetamido-2-deoxy-beta-D-glucopyranose-(1-4)-[alpha-L-fucopyranose-(1-6)]2-acetamido-2-deoxy-beta-D-glucopyranoseQ, R, S, T, U, V, W, X9N-Glycosylation Oligosaccharides Interaction
Glycosylation Resources
GlyTouCan:  G27919IH
GlyCosmos:  G27919IH
GlyGen:  G27919IH
Experimental Data & Validation

Experimental Data

  • Method: X-RAY DIFFRACTION
  • Resolution: 2.90 Å
  • R-Value Free: 0.242
  • R-Value Work: 0.200
  • R-Value Observed: 0.202
  • Space Group: P 21 21 21
Unit Cell:
Length ( Å )Angle ( ˚ )
a = 104.027α = 90
b = 153.428β = 90
c = 170.132γ = 90
Software Package:
Software NamePurpose
HKL-2000data collection
MOLREPphasing
REFMACrefinement
HKL-2000data reduction
HKL-2000data scaling

Structure Validation

View Full Validation Report




Entry History

Deposition Data

Revision History  (Full details and data files)

  • Version 1.0: 2014-10-29
    Type: Initial release
  • Version 1.1: 2015-09-09
    Changes: Database references
  • Version 2.0: 2020-07-29
    Type: Remediation
    Reason: Carbohydrate remediation
    Changes: Advisory, Atomic model, Data collection, Derived calculations, Structure summary
