3WBX | pdb_00003wbx

Crystal structure of Gox0644 at apoform

• PDB DOI: https://doi.org/10.2210/pdb3WBX/pdb

• Classification: OXIDOREDUCTASE
• Organism(s): Gluconobacter oxydans 621H
• Expression System: Escherichia coli
• Mutation(s): No


• Deposited: 2013-05-22 Released: 2014-05-28
• Deposition Author(s): Yuan, Y.A., Wang, C.

---

Experimental Data Snapshot

• Method: X-RAY DIFFRACTION
• Resolution: 2.40 Å
• R-Value Free:
  0.300 (Depositor), 0.300 (DCC)
• R-Value Work:
  0.224 (Depositor), 0.220 (DCC)
• R-Value Observed:
  0.228 (Depositor)

Literature

Crystal structure of Gox0644 at apoform

Yuan, Y.A., Wang, C.

To be published.

Biological Assembly 1

Global Symmetry: Asymmetric - C1
Global Stoichiometry: Monomer - A1

Biological assembly 1 assigned by authors and generated by PISA (software)

Biological Assembly 2

Global Symmetry: Asymmetric - C1
Global Stoichiometry: Monomer - A1

Biological assembly 2 assigned by authors and generated by PISA (software)

Macromolecule Content

• Total Structure Weight: 64.49 kDa
• Atom Count: 4,600
• Modeled Residue Count: 542
• Deposited Residue Count: 564
• Unique protein chains: 1

Macromolecules

Entity ID: 1
Molecule	Chains	Sequence Length	Organism	Details	Image
Putative 2,5-diketo-D-gluconic acid reductase	A, B	282	Gluconobacter oxydans 621H	Mutation(s): 0  Gene Names: GOX0644 EC: 1.1.1
UniProt
Find proteins for Q5FT75 (Gluconobacter oxydans (strain 621H)) Explore Q5FT75  Go to UniProtKB:  Q5FT75

Small Molecules

Ligands 1 Unique
ID	Chains	Name / Formula / InChI Key	2D Diagram
SO4	C [auth A], D [auth B], E [auth B], F [auth B]	SULFATE ION O4 S QAOWNCQODCNURD-UHFFFAOYSA-L

Experimental Data & Validation

Experimental Data

• Method: X-RAY DIFFRACTION
• Resolution: 2.40 Å
• R-Value Free:  0.300 (Depositor), 0.300 (DCC)
• R-Value Work:  0.224 (Depositor), 0.220 (DCC)
• R-Value Observed: 0.228 (Depositor)

Space Group: P 2₁ 2₁ 2₁

Unit Cell:

Length ( Å )	Angle ( ˚ )
a = 55.879	α = 90
b = 75.78	β = 90
c = 125.585	γ = 90

Software Package:

Software Name	Purpose
HKL-2000	data collection
MOLREP	phasing
REFMAC	refinement
HKL-2000	data reduction
HKL-2000	data scaling

Structure Validation

Entry History

Deposition Data

• Released Date: 2014-05-28
Deposition Author(s): Yuan, Y.A., Wang, C.

Revision History

• Version 1.0: 2014-05-28
  Type: Initial release

• Version 1.1: 2024-03-20
  Changes: Data collection, Database references, Derived calculations, Refinement description
