3UV1

Crystal structure a major allergen from dust mite

Experimental Data Snapshot

  • Method: X-RAY DIFFRACTION
  • Resolution: 2.00 Å
  • R-Value Free: 0.280
  • R-Value Work: 0.224
  • R-Value Observed: 0.228

wwPDB Validation   3D Report Full Report


This is version 1.0 of the entry. See complete history.


Literature

Crystal Structure of Der f 7, a Dust Mite Allergen from Dermatophagoides farinae.

Tan, K.W., Jobichen, C., Ong, T.C., Gao, Y.F., Tiong, Y.S., Wong, K.N., Chew, F.T., Sivaraman, J., Mok, Y.K.

(2012) PLoS One 7: e44850-e44850

  • DOI: https://doi.org/10.1371/journal.pone.0044850
  • Primary Citation of Related Structures:
    3UV1

  • PubMed Abstract:

    • Der f 7 is the group 7 allergen from the dust mite Dermatophagoides farinae, homologous to the major allergen Der p 7 from D. pteronyssinus. Monoclonal antibody that bind to residues Leu48 and Phe50 was found to inhibit IgE binding to residue Asp159, which is important for the cross-reactivity between Der f 7 and Der p 7 ...

    Der f 7 is the group 7 allergen from the dust mite Dermatophagoides farinae, homologous to the major allergen Der p 7 from D. pteronyssinus. Monoclonal antibody that bind to residues Leu48 and Phe50 was found to inhibit IgE binding to residue Asp159, which is important for the cross-reactivity between Der f 7 and Der p 7.

    Organizational Affiliation:

    Department of Biological Sciences, National University of Singapore, Singapore, Singapore.



Macromolecules
Find similar proteins by:
(by identity cutoff)  |  3D Structure
Entity ID: 1
MoleculeChainsSequence LengthOrganismDetailsImage
Der f 7 allergen
A, B
196Dermatophagoides farinaeMutation(s): 0
Gene Names: DERF7
UniProt
Find proteins for Q26456 (Dermatophagoides farinae)
Explore Q26456
Go to UniProtKB:  Q26456
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupQ26456
Protein Feature View
Expand
  • Reference Sequence
Small Molecules
Modified Residues  1 Unique
IDChainsTypeFormula2D DiagramParent
MSE
Query on MSE
A, B
L-PEPTIDE LINKINGC5 H11 N O2 SeMET
Experimental Data & Validation

Experimental Data

  • Method: X-RAY DIFFRACTION
  • Resolution: 2.00 Å
  • R-Value Free: 0.280
  • R-Value Work: 0.224
  • R-Value Observed: 0.228
  • Space Group: P 21 21 21
Unit Cell:
Length ( Å )Angle ( ˚ )
a = 51.092α = 90
b = 58.234β = 90
c = 128.978γ = 90
Software Package:
Software NamePurpose
ADSCdata collection
PHASERphasing
PHENIXrefinement
HKL-2000data reduction
SCALEPACKdata scaling

Structure Validation

View Full Validation Report



View more in-depth experimental data
Entry History

Deposition Data

Revision History  (Full details and data files)

  • Version 1.0: 2012-10-17
    Type: Initial release
