Biological Assembly 1

 3D View: Structure | Electron Density | Ligand Interaction

Global Symmetry: Asymmetric - C1
Global Stoichiometry: Monomer - A1

Biological assembly 1 assigned by authors and generated by PISA (software)

Biological Assembly 2

 3D View: Structure | Electron Density | Ligand Interaction

Biological assembly 2 generated by PISA (software)

Macromolecule Content

• Total Structure Weight: 35.06 kDa
• Atom Count: 1943
• Residue Count: 195
• Unique protein chains: 1
• Unique nucleic acid chains: 1

3UGO

Crystal structure of RNA-polymerase sigma subunit domain 2 complexed with -10 promoter element ssDNA oligo (TACAAT)

• DOI: 10.2210/pdb3UGO/pdb
• NDB: NA1373

• Classification: TRANSCRIPTION/DNA
• Organism(s): Thermus aquaticus
• Expression System: Escherichia coli
• Mutation(s): No


• Deposited: 2011-11-02 Released: 2011-12-07
• Deposition Author(s): Feklistov, A., Darst, S.A.

---

Experimental Data Snapshot

• Method: X-RAY DIFFRACTION
• Resolution: 2.10 Å
• R-Value Free: 0.237
• R-Value Work: 0.196
• R-Value Observed: 0.198

Literature

Structural basis for promoter-10 element recognition by the bacterial RNA polymerase sigma subunit.

Feklistov, A., Darst, S.A.

(2011) Cell 147: 1257-1269

• PubMed: 22136875
• DOI: 10.1016/j.cell.2011.10.041
• Primary Citation of Related Structures:
  3UGO, 3UGP


• PubMed Abstract:


The key step in bacterial promoter opening is recognition of the -10 promoter element (T(-12)A(-11)T(-10)A(-9)A(-8)T(-7) consensus sequence) by the RNA polymerase σ subunit. We determined crystal structures of σ domain 2 bound to single-stranded DNA bearing-10 element sequences. Extensive interactions occur between the protein and the DNA backbone of every -10 element nucleotide. Base-specific interactions occur primarily with A(-11) and T(-7), which are flipped out of the single-stranded DNA base stack and buried deep in protein pockets. The structures, along with biochemical data, support a model where the recognition of the -10 element sequence drives initial promoter opening as the bases of the nontemplate strand are extruded from the DNA double-helix and captured by σ. These results provide a detailed structural basis for the critical roles of A(-11) and T(-7) in promoter melting and reveal important insights into the initiation of transcription bubble formation.

---

Organizational Affiliation:

The Rockefeller University, 1230 York Avenue, New York, NY 10065, USA. [e-mail]

Macromolecules

Entity ID: 1
Molecule	Chains	Sequence Length	Organism	Details	Image
RNA polymerase sigma factor	A	245	Thermus aquaticus	Mutation(s): 0  Gene Names: sigA
Find proteins for Q9EZJ8 (Thermus aquaticus) Explore Q9EZJ8  Go to UniProtKB:  Q9EZJ8

Entity ID: 2
Molecule	Chains	Length	Organism	Image
5'-D(*TP*GP*TP*AP*CP*AP*AP*TP*GP*GP*G)-3'	B, C	11	N/A

Small Molecules

Ligands 1 Unique
ID	Chains	Name / Formula / InChI Key	2D Diagram
K	B, C	POTASSIUM ION K NPYPAHLBTDXSSS-UHFFFAOYSA-N

Experimental Data & Validation

Experimental Data

• Method: X-RAY DIFFRACTION
• Resolution: 2.10 Å
• R-Value Free: 0.237
• R-Value Work: 0.196
• R-Value Observed: 0.198
• Space Group: P 4 2 2

Unit Cell:

Length ( Å )	Angle ( ˚ )
a = 86.134	α = 90
b = 86.134	β = 90
c = 111.728	γ = 90

Software Package:

Software Name	Purpose
CBASS	data collection
PHASER	phasing
PHENIX	refinement
HKL-2000	data reduction
HKL-2000	data scaling

Structure Validation

Entry History

Deposition Data

• Deposited Date: 2011-11-02
• Released Date: 2011-12-07
Deposition Author(s): Feklistov, A., Darst, S.A.

Revision History

• Version 1.0: 2011-12-07
  Type: Initial release

• Version 1.1: 2012-03-07
  Changes: Database references
