3U6G | pdb_00003u6g

Crystal structure of a domain of unknown function, DUF4425 (BVU_3708) from Bacteroides vulgatus ATCC 8482 at 1.35 A resolution

PDB DOI: https://doi.org/10.2210/pdb3U6G/pdb

Classification: Structural Genomics, Unknown Function
Organism(s): Phocaeicola vulgatus ATCC 8482
Expression System: Escherichia coli
Mutation(s): No

Deposited: 2011-10-12 Released: 2011-11-02
Deposition Author(s): Joint Center for Structural Genomics (JCSG)

Experimental Data Snapshot

Method: X-RAY DIFFRACTION
Resolution: 1.35 Å
R-Value Free:
0.207 (Depositor), 0.210 (DCC)
R-Value Work:
0.157 (Depositor), 0.160 (DCC)
R-Value Observed:
0.159 (Depositor)

wwPDB Validation 3D Report Full Report

This is version 1.4 of the entry. See complete history.

Literature

Crystal structure of a domain of unknown function, DUF4425 (BVU_3708) from Bacteroides vulgatus ATCC 8482 at 1.35 A resolution

Joint Center for Structural Genomics (JCSG)

To be published.

Macromolecule Content

Total Structure Weight: 27.16 kDa
Atom Count: 2,256
Modeled Residue Count: 248
Deposited Residue Count: 252
Unique protein chains: 1

Macromolecules

Find similar proteins by:

(by identity cutoff) | 3D Structure

Entity ID: 1
Molecule	Chains	Sequence Length	Organism	Details	Image
uncharacterized protein DUF4425	A, B	126	Phocaeicola vulgatus ATCC 8482	Mutation(s): 0 Gene Names: BVU_3708
UniProt
Find proteins for A6L6K5 (Phocaeicola vulgatus (strain ATCC 8482 / DSM 1447 / JCM 5826 / CCUG 4940 / NBRC 14291 / NCTC 11154)) Explore A6L6K5 Go to UniProtKB: A6L6K5
Entity Groups
Sequence Clusters	30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt Group	A6L6K5
Sequence Annotations Expand
Reference Sequence

Small Molecules

Modified Residues 1 Unique
ID	Chains	Type	Formula	2D Diagram	Parent
MSE Query on MSE	A, B	L-PEPTIDE LINKING	C₅ H₁₁ N O₂ Se		MET

Experimental Data & Validation

Experimental Data

Method: X-RAY DIFFRACTION
Resolution: 1.35 Å
R-Value Free: 0.207 (Depositor), 0.210 (DCC)
R-Value Work: 0.157 (Depositor), 0.160 (DCC)
R-Value Observed: 0.159 (Depositor)

Diffraction Data: https://doi.org/10.18430/M33U6G

Space Group: P 2₁ 2₁ 2

Unit Cell:

Length ( Å )	Angle ( ˚ )
a = 52.237	α = 90
b = 99.302	β = 90
c = 41.085	γ = 90

Software Package:

Software Name	Purpose
MolProbity	model building
PDB_EXTRACT	data extraction
SHELX	phasing
SHARP	phasing
XSCALE	data scaling
REFMAC	refinement
XDS	data reduction
SHELXD	phasing
autoSHARP	phasing

Structure Validation

View Full Validation Report

Entry History

Deposition Data

Released Date: 2011-11-02

Deposition Author(s):

Joint Center for Structural Genomics (JCSG)

Revision History (Full details and data files)

Version 1.0: 2011-11-02
Type: Initial release
Version 1.1: 2017-10-25
Changes: Author supporting evidence, Refinement description
Version 1.2: 2018-01-24
Changes: Database references
Version 1.3: 2023-02-01
Changes: Database references, Derived calculations
Version 1.4: 2024-11-27
Changes: Data collection, Structure summary
