3TV2 | pdb_00003tv2

Structure of a class II fumarate hydratase from Burkholderia pseudomallei

• PDB DOI: https://doi.org/10.2210/pdb3TV2/pdb

• Classification: LYASE
• Organism(s): Burkholderia pseudomallei 1710b
• Expression System: Escherichia coli
• Mutation(s): No


• Deposited: 2011-09-19 Released: 2011-09-28
• Deposition Author(s): Seattle Structural Genomics Center for Infectious Disease (SSGCID)

---

Experimental Data Snapshot

• Method: X-RAY DIFFRACTION
• Resolution: 2.10 Å
• R-Value Free:
  0.176 (Depositor), 0.180 (DCC)
• R-Value Work:
  0.156 (Depositor), 0.160 (DCC)
• R-Value Observed:
  0.157 (Depositor)

Starting Model: experimental

Literature

Structure of a class II fumarate hydratase from Burkholderia pseudomallei

Clifton, M.C., Abendroth, J., Seattle Structural Genomics Center for Infectious Disease (SSGCID), Sankaran, B.

To be published.

Biological Assembly 1

Global Symmetry: Dihedral - D2  (Explore in 3D)
Global Stoichiometry: Homo 4-mer - A4

Biological assembly 1 assigned by authors and generated by PISA (software)

Macromolecule Content

• Total Structure Weight: 48.79 kDa
• Atom Count: 3,890
• Modeled Residue Count: 457
• Deposited Residue Count: 459
• Unique protein chains: 1

Macromolecules

Entity ID: 1
Molecule	Chains	Sequence Length	Organism	Details	Image
Fumarate hydratase, class II	A	459	Burkholderia pseudomallei 1710b	Mutation(s): 0  Gene Names: fumC, BURPS1710b_2940 EC: 4.2.1.2
UniProt
Find proteins for Q3JQ34 (Burkholderia pseudomallei (strain 1710b)) Explore Q3JQ34  Go to UniProtKB:  Q3JQ34

Small Molecules

Ligands 2 Unique
ID	Chains	Name / Formula / InChI Key	2D Diagram
NA	B [auth A]	SODIUM ION Na FKNQFGJONOIPTF-UHFFFAOYSA-N
UNL	C [auth A]	Unknown ligand FKNQFGJONOIPTF-UHFFFAOYSA-N

Experimental Data & Validation

Experimental Data

• Method: X-RAY DIFFRACTION
• Resolution: 2.10 Å
• R-Value Free:  0.176 (Depositor), 0.180 (DCC)
• R-Value Work:  0.156 (Depositor), 0.160 (DCC)
• R-Value Observed: 0.157 (Depositor)

Diffraction Data: https://doi.org/10.18430/M33TV2

Space Group: P 6₄ 2 2

Unit Cell:

Length ( Å )	Angle ( ˚ )
a = 147.18	α = 90
b = 147.18	β = 90
c = 208.28	γ = 120

Software Package:

Software Name	Purpose
XSCALE	data scaling
PHASER	phasing
REFMAC	refinement
PDB_EXTRACT	data extraction
XDS	data reduction

Structure Validation

Entry History

Deposition Data

• Released Date: 2011-09-28
Deposition Author(s): Seattle Structural Genomics Center for Infectious Disease (SSGCID)

Revision History

• Version 1.0: 2011-09-28
  Type: Initial release

• Version 1.1: 2023-09-13
  Changes: Data collection, Database references, Derived calculations, Refinement description
