3RKO

Crystal structure of the membrane domain of respiratory complex I from E. coli at 3.0 angstrom resolution

Experimental Data Snapshot

  • Method: X-RAY DIFFRACTION
  • Resolution: 3.00 Å
  • R-Value Free: 0.282
  • R-Value Work: 0.232
  • R-Value Observed: 0.233

wwPDB Validation   3D Report Full Report


Ligand Structure Quality Assessment


This is version 1.1 of the entry. See complete history.


Literature

Structure of the membrane domain of respiratory complex I.

Efremov, R.G., Sazanov, L.A.

(2011) Nature 476: 414-420

  • DOI: 10.1038/nature10330
  • Primary Citation of Related Structures:
    3RKO

  • PubMed Abstract:

    • Complex I is the first and largest enzyme of the respiratory chain, coupling electron transfer between NADH and ubiquinone to the translocation of four protons across the membrane. It has a central role in cellular energy production and has been implicated in many human neurodegenerative diseases ...

    Complex I is the first and largest enzyme of the respiratory chain, coupling electron transfer between NADH and ubiquinone to the translocation of four protons across the membrane. It has a central role in cellular energy production and has been implicated in many human neurodegenerative diseases. The L-shaped enzyme consists of hydrophilic and membrane domains. Previously, we determined the structure of the hydrophilic domain. Here we report the crystal structure of the Esherichia coli complex I membrane domain at 3.0 Å resolution. It includes six subunits, NuoL, NuoM, NuoN, NuoA, NuoJ and NuoK, with 55 transmembrane helices. The fold of the homologous antiporter-like subunits L, M and N is novel, with two inverted structural repeats of five transmembrane helices arranged, unusually, face-to-back. Each repeat includes a discontinuous transmembrane helix and forms half of a channel across the membrane. A network of conserved polar residues connects the two half-channels, completing the proton translocation pathway. Unexpectedly, lysines rather than carboxylate residues act as the main elements of the proton pump in these subunits. The fourth probable proton-translocation channel is at the interface of subunits N, K, J and A. The structure indicates that proton translocation in complex I, uniquely, involves coordinated conformational changes in six symmetrical structural elements.

    Organizational Affiliation:

    Medical Research Council Mitochondrial Biology Unit, Wellcome Trust/MRC Building, Hills Road, Cambridge CB2 0XY, UK.



Macromolecules
Find similar proteins by:
(by identity cutoff)  |  3D Structure
Entity ID: 1
MoleculeChainsSequence LengthOrganismDetailsImage
NADH-QUINONE OXIDOREDUCTASE SUBUNIT LG [auth B],
A [auth L]		613Escherichia coli BL21(DE3)Mutation(s): 0
Gene Names: nuoL, ECBD_1383, HO396_11190
EC: 1.6.5.3
Membrane Entity: Yes
UniProt
Find proteins for A0A140N7P6 (Escherichia coli (strain B / BL21-DE3))
Explore A0A140N7P6
Go to UniProtKB:  A0A140N7P6
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupA0A140N7P6
Protein Feature View
Expand
  • Reference Sequence
Find similar proteins by:
(by identity cutoff)  |  3D Structure
Entity ID: 2
MoleculeChainsSequence LengthOrganismDetailsImage
NADH-QUINONE OXIDOREDUCTASE SUBUNIT MH [auth C],
B [auth M]		509Escherichia coli BL21(DE3)Mutation(s): 0
Gene Names: nuoM, ECBD_1384, HO396_11185
EC: 1.6.5.3
Membrane Entity: Yes
UniProt
Find proteins for A0A140N571 (Escherichia coli (strain B / BL21-DE3))
Explore A0A140N571
Go to UniProtKB:  A0A140N571
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupA0A140N571
Protein Feature View
Expand
  • Reference Sequence
Find similar proteins by:
(by identity cutoff)  |  3D Structure
Entity ID: 3
MoleculeChainsSequence LengthOrganismDetailsImage
NADH-QUINONE OXIDOREDUCTASE SUBUNIT NI [auth D],
C [auth N]		485Escherichia coli BL21(DE3)Mutation(s): 0
Gene Names: nuoN, ECBD_1385, HO396_11180
EC: 1.6.5.3 (PDB Primary Data), 7.1.1 (UniProt)
Membrane Entity: Yes
UniProt
Find proteins for A0A140N755 (Escherichia coli (strain B / BL21-DE3))
Explore A0A140N755
Go to UniProtKB:  A0A140N755
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupA0A140N755
Protein Feature View
Expand
  • Reference Sequence
Find similar proteins by:
(by identity cutoff)  |  3D Structure
Entity ID: 4
MoleculeChainsSequence LengthOrganismDetailsImage
NADH-QUINONE OXIDOREDUCTASE SUBUNIT KJ [auth G],
D [auth K]		100Escherichia coli BL21(DE3)Mutation(s): 0
Gene Names: nuoK, B21_02164, ECBD_1382, ECD_02204
EC: 1.6.5.3 (PDB Primary Data), 7.1.1 (UniProt)
Membrane Entity: Yes
UniProt
Find proteins for C5W716 (Escherichia coli (strain B / BL21-DE3))
Explore C5W716
Go to UniProtKB:  C5W716
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupC5W716
Protein Feature View
Expand
  • Reference Sequence
Find similar proteins by:
(by identity cutoff)  |  3D Structure
Entity ID: 5
MoleculeChainsSequence LengthOrganismDetailsImage
NADH-QUINONE OXIDOREDUCTASE SUBUNIT AE [auth A],
K [auth E]		147Escherichia coli BL21(DE3)Mutation(s): 0
Gene Names: nuoA, ECBD_1373, HO396_11240
EC: 1.6.5.3 (PDB Primary Data), 7.1.1 (UniProt)
Membrane Entity: Yes
UniProt
Find proteins for A0A140N7N4 (Escherichia coli (strain B / BL21-DE3))
Explore A0A140N7N4
Go to UniProtKB:  A0A140N7N4
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupA0A140N7N4
Protein Feature View
Expand
  • Reference Sequence
Find similar proteins by:
(by identity cutoff)  |  3D Structure
Entity ID: 6
MoleculeChainsSequence LengthOrganismDetailsImage
NADH-QUINONE OXIDOREDUCTASE SUBUNIT JL [auth F],
F [auth J]		184Escherichia coli BL21(DE3)Mutation(s): 0
Gene Names: nuoJ, ECBD_1381, HO396_11200
EC: 1.6.5.3 (PDB Primary Data), 7.1.1 (UniProt)
Membrane Entity: Yes
UniProt
Find proteins for A0A140N7W8 (Escherichia coli (strain B / BL21-DE3))
Explore A0A140N7W8
Go to UniProtKB:  A0A140N7W8
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupA0A140N7W8
Protein Feature View
Expand
  • Reference Sequence
Small Molecules
Ligands 2 Unique
IDChainsName / Formula / InChI Key2D Diagram3D Interactions
CA7
Query on CA7
Download Ideal Coordinates CCD File
P [auth M],
Z [auth C]		7-cyclohexylheptyl 4-O-alpha-D-glucopyranosyl-beta-D-glucopyranoside
C25 H46 O11
BEKAVONQUWHNMM-IYBATYGCSA-N		 Ligand Interaction
LFA
Query on LFA
Download Ideal Coordinates CCD File
AA [auth C],
BA [auth C],
CA [auth C],
DA [auth D],
EA [auth D],
AA [auth C],
BA [auth C],
CA [auth C],
DA [auth D],
EA [auth D],
FA [auth D],
M [auth L],
N [auth L],
O [auth L],
Q [auth M],
R [auth M],
S [auth N],
T [auth N],
U [auth N],
V [auth N],
W [auth B],
X [auth B],
Y [auth B]
EICOSANE
C20 H42
CBFCDTFDPHXCNY-UHFFFAOYSA-N		 Ligand Interaction
Experimental Data & Validation

Experimental Data

  • Method: X-RAY DIFFRACTION
  • Resolution: 3.00 Å
  • R-Value Free: 0.282
  • R-Value Work: 0.232
  • R-Value Observed: 0.233
  • Space Group: P 1
Unit Cell:
Length ( Å )Angle ( ˚ )
a = 94.98α = 98.51
b = 116.57β = 104.08
c = 191.37γ = 108.51
Software Package:
Software NamePurpose
MOSFLMdata reduction
SCALAdata scaling
PHENIXrefinement
PDB_EXTRACTdata extraction
ADSCdata collection
SHARPphasing

Structure Validation

View Full Validation Report



Ligand Structure Quality Assessment


View more in-depth experimental data

Entry History

Deposition Data

Revision History  (Full details and data files)

  • Version 1.0: 2011-08-03
    Type: Initial release
  • Version 1.1: 2011-11-02
    Changes: Database references
