3R9I

2.6A resolution structure of MinD complexed with MinE (12-31) peptide


Experimental Data Snapshot

  • Method: X-RAY DIFFRACTION
  • Resolution: 2.60 Å
  • R-Value Free: 0.243
  • R-Value Work: 0.201
  • R-Value Observed: 0.203

wwPDB Validation   3D Report Full Report


Ligand Structure Quality Assessment


This is version 1.0 of the entry. See complete history


Literature

The Min Oscillator Uses MinD-Dependent Conformational Changes in MinE to Spatially Regulate Cytokinesis.

Park, K.T.Wu, W.Battaile, K.P.Lovell, S.Holyoak, T.Lutkenhaus, J.

(2011) Cell 146: 396-407

  • DOI: 10.1016/j.cell.2011.06.042
  • Primary Citation of Related Structures:
    3R9J, 3R9I

  • PubMed Abstract:
  • In E. coli, MinD recruits MinE to the membrane, leading to a coupled oscillation required for spatial regulation of the cytokinetic Z ring. How these proteins interact, however, is not clear because the MinD-binding regions of MinE are sequestered within a six-stranded β sheet and masked by N-terminal helices ...

    In E. coli, MinD recruits MinE to the membrane, leading to a coupled oscillation required for spatial regulation of the cytokinetic Z ring. How these proteins interact, however, is not clear because the MinD-binding regions of MinE are sequestered within a six-stranded β sheet and masked by N-terminal helices. minE mutations that restore interaction between some MinD and MinE mutants were isolated. These mutations alter the MinE structure leading to release of the MinD-binding regions and the N-terminal helices that bind the membrane. Crystallization of MinD-MinE complexes revealed a four-stranded β sheet MinE dimer with the released β strands (MinD-binding regions) converted to α helices bound to MinD dimers. These results identify the MinD-dependent conformational changes in MinE that convert it from a latent to an active form and lead to a model of how MinE persists at the MinD-membrane surface.


    Organizational Affiliation

    Department of Microbiology, Molecular Genetics and Immunology, University of Kansas Medical Center, Kansas City, KS 66160, USA.



Macromolecules
Find similar proteins by:  (by identity cutoff)  |  Structure
Entity ID: 1
MoleculeChainsSequence LengthOrganismDetailsImage
Septum site-determining protein minDA, B, C, D260Escherichia coli K-12Mutation(s): 1
Gene Names: b1175JW1164minD
UniProt
Find proteins for P0AEZ3 (Escherichia coli (strain K12))
Explore P0AEZ3
Go to UniProtKB:  P0AEZ3
Protein Feature View
Expand
  • Reference Sequence
  • Find similar proteins by:  Sequence   |   Structure
Entity ID: 2
MoleculeChainsSequence LengthOrganismDetailsImage
Cell division topological specificity factorE, F, G, H20Escherichia coli K-12Mutation(s): 0
Gene Names: minEb1174JW1163
UniProt
Find proteins for P0A734 (Escherichia coli (strain K12))
Explore P0A734
Go to UniProtKB:  P0A734
Protein Feature View
Expand
  • Reference Sequence
Small Molecules
Ligands 1 Unique
IDChainsName / Formula / InChI Key2D Diagram3D Interactions
ADP (Subject of Investigation/LOI)
Query on ADP

Download Ideal Coordinates CCD File
I [auth A], J [auth B], K [auth C], L [auth D]ADENOSINE-5'-DIPHOSPHATE
C10 H15 N5 O10 P2
XTWYTFMLZFPYCI-KQYNXXCUSA-N
 Ligand Interaction
Experimental Data & Validation

Experimental Data

  • Method: X-RAY DIFFRACTION
  • Resolution: 2.60 Å
  • R-Value Free: 0.243
  • R-Value Work: 0.201
  • R-Value Observed: 0.203
  • Space Group: P 1
Unit Cell:
Length ( Å )Angle ( ˚ )
a = 64.293α = 102.64
b = 71.796β = 95.87
c = 76.644γ = 111.72
Software Package:
Software NamePurpose
SCALAdata scaling
MOLREPphasing
PHENIXrefinement
PDB_EXTRACTdata extraction
JDirectordata collection
XSCALEdata scaling

Structure Validation

View Full Validation Report



Ligand Structure Quality Assessment



Entry History

Deposition Data

Revision History  (Full details and data files)

  • Version 1.0: 2011-08-17
    Type: Initial release
