3Q0B

Crystal structure of SUVH5 SRA- fully methylated CG DNA complex in space group P42212


Experimental Data Snapshot

  • Method: X-RAY DIFFRACTION
  • Resolution: 2.20 Å
  • R-Value Free: 0.252
  • R-Value Work: 0.217
  • R-Value Observed: 0.218

wwPDB Validation   3D Report Full Report


This is version 1.1 of the entry. See complete history


Literature

A dual flip-out mechanism for 5mC recognition by the Arabidopsis SUVH5 SRA domain and its impact on DNA methylation and H3K9 dimethylation in vivo.

Rajakumara, E.Law, J.A.Simanshu, D.K.Voigt, P.Johnson, L.M.Reinberg, D.Patel, D.J.Jacobsen, S.E.

(2011) Genes Dev 25: 137-152

  • DOI: 10.1101/gad.1980311
  • Primary Citation of Related Structures:
    3Q0B, 3Q0C, 3Q0D, 3Q0F

  • PubMed Abstract:
  • Cytosine DNA methylation is evolutionarily ancient, and in eukaryotes this epigenetic modification is associated with gene silencing. Proteins with SRA (SET- or RING-associated) methyl-binding domains are required for the establishment and/or maintenance of DNA methylation in both plants and mammals ...

    Cytosine DNA methylation is evolutionarily ancient, and in eukaryotes this epigenetic modification is associated with gene silencing. Proteins with SRA (SET- or RING-associated) methyl-binding domains are required for the establishment and/or maintenance of DNA methylation in both plants and mammals. The 5-methyl-cytosine (5mC)-binding specificity of several SRA domains have been characterized, and each one has a preference for DNA methylation in different sequence contexts. Here we demonstrate through mobility shift assays and calorimetric measurements that the SU(VAR)3-9 HOMOLOG 5 (SUVH5) SRA domain differs from other SRA domains in that it can bind methylated DNA in all contexts to similar extents. Crystal structures of the SUVH5 SRA domain bound to 5mC-containing DNA in either the fully or hemimethylated CG context or the methylated CHH context revealed a dual flip-out mechanism where both the 5mC and a base (5mC, C, or G, respectively) from the partner strand are simultaneously extruded from the DNA duplex and positioned within binding pockets of individual SRA domains. Our structure-based in vivo studies suggest that a functional SUVH5 SRA domain is required for both DNA methylation and accumulation of the H3K9 dimethyl modification in vivo, suggesting a role for the SRA domain in recruitment of SUVH5 to genomic loci.


    Organizational Affiliation

    Structural Biology Program, Memorial Sloan-Kettering Cancer Center, New York, New York 10065, USA.



Macromolecules

Find similar proteins by:  (by identity cutoff)  |  Structure
Entity ID: 1
MoleculeChainsSequence LengthOrganismDetailsImage
Histone-lysine N-methyltransferase, H3 lysine-9 specific SUVH5 X167Arabidopsis thalianaMutation(s): 0
Gene Names: At2g35160SDG9SET9SUVH5T4C15.17
EC: 2.1.1.43 (PDB Primary Data), 2.1.1 (UniProt)
Find proteins for O82175 (Arabidopsis thaliana)
Explore O82175
Go to UniProtKB:  O82175
Protein Feature View
Expand
  • Reference Sequence
  • Find similar nucleic acids by:  Sequence   |   Structure
  • Entity ID: 2
    MoleculeChainsLengthOrganismImage
    DNA (5'-D(*AP*CP*TP*AP*(5CM)P*GP*TP*AP*GP*T)-3')A10N/A
    Small Molecules
    Modified Residues  1 Unique
    IDChainsTypeFormula2D DiagramParent
    MSE
    Query on MSE
    XL-PEPTIDE LINKINGC5 H11 N O2 SeMET
    Experimental Data & Validation

    Experimental Data

    • Method: X-RAY DIFFRACTION
    • Resolution: 2.20 Å
    • R-Value Free: 0.252
    • R-Value Work: 0.217
    • R-Value Observed: 0.218
    • Space Group: P 42 21 2
    Unit Cell:
    Length ( Å )Angle ( ˚ )
    a = 76.566α = 90
    b = 76.566β = 90
    c = 73.904γ = 90
    Software Package:
    Software NamePurpose
    ADSCdata collection
    SHARPphasing
    PHENIXrefinement
    HKL-2000data reduction
    HKL-2000data scaling

    Structure Validation

    View Full Validation Report



    Entry History

    Deposition Data

    Revision History  (Full details and data files)

    • Version 1.0: 2011-02-02
      Type: Initial release
    • Version 1.1: 2011-07-13
      Changes: Version format compliance
