3ND7

Crystal structure of phosphopantetheine adenylyltransferase from Enterococcus faecalis in the ligand-unbound state and in complex with ATP and pantetheine


Experimental Data Snapshot

  • Method: X-RAY DIFFRACTION
  • Resolution: 2.4 Å
  • R-Value Free: 0.262
  • R-Value Work: 0.213

wwPDB Validation 3D Report Full Report


This is version 1.2 of the entry. See complete history

Literature

Crystal structure of phosphopantetheine adenylyltransferase from Enterococcus faecalis in the ligand-unbound state and in complex with ATP and pantetheine

Yoon, H.J.Kang, J.Y.Mikami, B.Lee, H.H.Suh, S.W.

(2011) Mol.Cells 32: 431-435

  • DOI: 10.1007/s10059-011-0102-y
  • Primary Citation of Related Structures:

  • PubMed Abstract:
  • Phosphopantetheine adenylyltransferase (PPAT) catalyzes the reversible transfer of an adenylyl group from ATP to 4'-phosphopantetheine (Ppant) to form dephospho-CoA (dPCoA) and pyrophosphate in the Coenzyme A (CoA) biosynthetic pathway. Importantly, ...

    Phosphopantetheine adenylyltransferase (PPAT) catalyzes the reversible transfer of an adenylyl group from ATP to 4'-phosphopantetheine (Ppant) to form dephospho-CoA (dPCoA) and pyrophosphate in the Coenzyme A (CoA) biosynthetic pathway. Importantly, PPATs are the potential target for developing antibiotics because bacterial and mammalian PPATs share little sequence homology. Previous structural studies revealed the mechanism of the recognizing substrates and products. The binding modes of ATP, ADP, Ppant, and dPCoA are highly similar in all known structures, whereas the binding modes of CoA or 3'-phosphoadenosine 5'-phosphosulfate binding are novel. To provide further structural information on ligand binding by PPATs, the crystal structure of PPAT from Enterococcus faecalis was solved in three forms: (i) apo form, (ii) binary complex with ATP, and (iii) binary complex with pantetheine. The substrate analog, pantetheine, binds to the active site in a similar manner to Ppant. The new structural information reported in this study including pantetheine as a potent inhibitor of PPAT will supplement the existing structural data and should be useful for structure-based antibacterial discovery against PPATs.


    Organizational Affiliation

    Department of Chemistry, College of Natural Sciences, Seoul National University, Seoul 151-742, Korea.




Macromolecules

Find similar proteins by: Sequence  |  Structure

Entity ID: 1
MoleculeChainsSequence LengthOrganismDetails
Phosphopantetheine adenylyltransferase
A, B, C, D, E, F
171Enterococcus faecalis (strain ATCC 700802 / V583)Mutation(s): 0
Gene Names: coaD
EC: 2.7.7.3
Find proteins for Q831P9 (Enterococcus faecalis (strain ATCC 700802 / V583))
Go to UniProtKB:  Q831P9
Small Molecules
Ligands 1 Unique
IDChainsName / Formula / InChI Key2D Diagram3D Interactions
PNY
Query on PNY

Download SDF File
Download CCD File
A, B, C, D, E, F
(2R)-2,4-dihydroxy-3,3-dimethyl-N-{3-oxo-3-[(2-sulfanylethyl)amino]propyl}butanamide
pantetheine, (R)-2,4-Dihydroxy-N-(3-((2-mercaptoethyl)amino)-3-oxopropyl)-3,3-dimethylbutanamide
C11 H22 N2 O4 S
ZNXZGRMVNNHPCA-VIFPVBQESA-N
 Ligand Interaction
Experimental Data & Validation

Experimental Data

  • Method: X-RAY DIFFRACTION
  • Resolution: 2.4 Å
  • R-Value Free: 0.262
  • R-Value Work: 0.213
  • Space Group: P 21 21 21
Unit Cell:
Length (Å)Angle (°)
a = 109.640α = 90.00
b = 125.791β = 90.00
c = 125.804γ = 90.00
Software Package:
Software NamePurpose
HKL-2000data scaling
CNSrefinement
HKL-2000data collection
HKL-2000data reduction
CNSphasing
REFMACrefinement

Structure Validation

View Full Validation Report or Ramachandran Plots



Entry History

Deposition Data

Revision History

  • Version 1.0: 2011-06-22
    Type: Initial release
  • Version 1.1: 2011-07-13
    Type: Version format compliance
  • Version 1.2: 2011-12-14
    Type: Database references
