3MAL

Crystal structure of the SDF2-like protein from Arabidopsis thaliana


Experimental Data Snapshot

  • Method: X-RAY DIFFRACTION
  • Resolution: 1.95 Å
  • R-Value Free: 0.213
  • R-Value Work: 0.167
  • R-Value Observed: 0.169

wwPDB Validation 3D Report Full Report


This is version 1.1 of the entry. See complete history


Literature

Arabidopsis stromal-derived Factor2 (SDF2) is a crucial target of the unfolded protein response in the endoplasmic reticulum.

Schott, A.Ravaud, S.Keller, S.Radzimanowski, J.Viotti, C.Hillmer, S.Sinning, I.Strahl, S.

(2010) J Biol Chem 285: 18113-18121

  • DOI: 10.1074/jbc.M110.117176
  • Structures With Same Primary Citation

  • PubMed Abstract:
  • Stresses increasing the load of unfolded proteins that enter the endoplasmic reticulum (ER) trigger a protective response termed the unfolded protein response (UPR). Stromal cell-derived factor2 (SDF2)-type proteins are highly conserved throughout th ...

    Stresses increasing the load of unfolded proteins that enter the endoplasmic reticulum (ER) trigger a protective response termed the unfolded protein response (UPR). Stromal cell-derived factor2 (SDF2)-type proteins are highly conserved throughout the plant and animal kingdoms. In this study we have characterized AtSDF2 as crucial component of the UPR in Arabidopsis thaliana. Using a combination of biochemical and cell biological methods, we demonstrate that SDF2 is induced in response to ER stress conditions causing the accumulation of unfolded proteins. Transgenic reporter plants confirmed induction of SDF2 during ER stress. Under normal growth conditions SDF2 is highly expressed in fast growing, differentiating cells and meristematic tissues. The increased production of SDF2 due to ER stress and in tissues that require enhanced protein biosynthesis and secretion, and its association with the ER membrane qualifies SDF2 as a downstream target of the UPR. Determination of the SDF2 three-dimensional crystal structure at 1.95 A resolution revealed the typical beta-trefoil fold with potential carbohydrate binding sites. Hence, SDF2 might be involved in the quality control of glycoproteins. Arabidopsis sdf2 mutants display strong defects and morphological phenotypes during seedling development specifically under ER stress conditions, thus establishing that SDF2-type proteins play a key role in the UPR.


    Organizational Affiliation

    Department of Cell Chemistry, Institute for Plant Sciences, Im Neuenheimer Feld 360, University of Heidelberg, D-69120 Heidelberg, Germany.



Macromolecules

Find similar proteins by: Sequence  |  Structure

Entity ID: 1
MoleculeChainsSequence LengthOrganismDetails
Stromal cell-derived factor 2-like proteinA, B199Arabidopsis thalianaMutation(s): 0
Gene Names: At2g25110F13D4.70U14608SDF2
Find proteins for Q93ZE8 (Arabidopsis thaliana)
Explore Q93ZE8
Go to UniProtKB:  Q93ZE8
Protein Feature View
 ( Mouse scroll to zoom / Hold left click to move )
  • Reference Sequence
Small Molecules
Ligands 2 Unique
IDChainsName / Formula / InChI Key2D Diagram3D Interactions
SO4
Query on SO4

Download CCD File
A
SULFATE ION
O4 S
QAOWNCQODCNURD-UHFFFAOYSA-L
 Ligand Interaction
EDO
Query on EDO

Download CCD File
A, B
1,2-ETHANEDIOL
C2 H6 O2
LYCAIKOWRPUZTN-UHFFFAOYSA-N
 Ligand Interaction
Experimental Data & Validation

Experimental Data

  • Method: X-RAY DIFFRACTION
  • Resolution: 1.95 Å
  • R-Value Free: 0.213
  • R-Value Work: 0.167
  • R-Value Observed: 0.169
  • Space Group: P 61
Unit Cell:
Length ( Å )Angle ( ˚ )
a = 96.13α = 90
b = 96.13β = 90
c = 69.343γ = 120
Software Package:
Software NamePurpose
ADSCdata collection
MOLREPphasing
REFMACrefinement
MOSFLMdata reduction
SCALAdata scaling

Structure Validation

View Full Validation Report



Entry History

Deposition Data

Revision History

  • Version 1.0: 2010-04-07
    Type: Initial release
  • Version 1.1: 2011-07-13
    Changes: Version format compliance
