3M36

Factor XA in complex with the inhibitor 1-[3-(aminomethyl)phenyl]-N-[3-fluoro-2'-(methylsulfonyl)biphenyl-4-yl]-3-(trifluoromethyl)-1H-pyrazole-5-carboxamide (DPC423)


Experimental Data Snapshot

  • Method: X-RAY DIFFRACTION
  • Resolution: 2.15 Å
  • R-Value Free: 0.264
  • R-Value Work: 0.223
  • R-Value Observed: 0.226

wwPDB Validation 3D Report Full Report


This is version 1.1 of the entry. See complete history


Literature

Discovery of 1-(2-Aminomethylphenyl)-3-trifluoromethyl-N-[3-fluoro-2'-(aminosulfonyl)[1,1'-biphenyl)]-1H-pyrazole-5-carboxyamide (DPC602), a Potent, Selective, and Orally Bioavailable Factor Xa Inhibitor

Pruitt, J.R.Pinto, D.J.P.Galemmo, R.A.Jr.Alexander, R.S.Rossi, K.A.Wells, B.L.Drummond, S.Bostrom, L.L.Burdick, D.Bruckner, R.Chen, H.Smallwood, A.Wong, P.C.Wright, M.R.Bai, S.Luettgen, J.M.Knabb, R.M.Lam, P.Y.S.Wexler, R.R.

(2003) J Med Chem 46: 5298-5315

  • DOI: 10.1021/jm030212h
  • Structures With Same Primary Citation

  • PubMed Abstract:
  • Factor Xa, a serine protease, is at the critical juncture between the intrinsic and extrinsic pathways of the coagulation cascade. Inhibition of factor Xa has the potential to provide effective treatment for both venous and arterial thrombosis. We re ...

    Factor Xa, a serine protease, is at the critical juncture between the intrinsic and extrinsic pathways of the coagulation cascade. Inhibition of factor Xa has the potential to provide effective treatment for both venous and arterial thrombosis. We recently described a series of meta-substituted phenylpyrazoles that are highly potent, selective, and orally bioavailable factor Xa inhibitors. In this paper we report our efforts to further optimize the selectivity profile of our factor Xa inhibitors with a series of ortho- and/or para-substituted phenylpyrazole derivatives. The most potent compounds display sub-nanomolar inhibition constants for factor Xa and show greater than 1000-fold selectivity against other serine proteases. These compounds are also effective in a rabbit model of arteriovenous shunt thrombosis. Optimization of this series led to the preclinical development of DPC602, a 2-(aminomethyl)phenylpyrazole analogue, as a highly potent, selective, and orally bioavailable factor Xa inhibitor.


    Organizational Affiliation

    Bristol-Myers Squibb Company, Pharmaceutical Research Institute, 31 Pennington-Rocky Hill Road, Pennington, New Jersey 08534, USA.



Macromolecules

Find similar proteins by: Sequence  |  Structure

Entity ID: 1
MoleculeChainsSequence LengthOrganismDetails
Coagulation factor XA234Homo sapiensMutation(s): 0
Gene Names: F10
EC: 3.4.21.6
Find proteins for P00742 (Homo sapiens)
Explore P00742
Go to UniProtKB:  P00742
NIH Common Fund Data Resources
PHAROS  P00742
Protein Feature View
 ( Mouse scroll to zoom / Hold left click to move )
  • Reference Sequence

Find similar proteins by: Sequence  |  Structure

Entity ID: 2
MoleculeChainsSequence LengthOrganismDetails
Coagulation factor XL52Homo sapiensMutation(s): 0
Gene Names: F10
EC: 3.4.21.6
Find proteins for P00742 (Homo sapiens)
Explore P00742
Go to UniProtKB:  P00742
NIH Common Fund Data Resources
PHAROS  P00742
Protein Feature View
 ( Mouse scroll to zoom / Hold left click to move )
  • Reference Sequence
Small Molecules
Ligands 2 Unique
IDChainsName / Formula / InChI Key2D Diagram3D Interactions
M35
Query on M35

Download CCD File
A
1-[3-(aminomethyl)phenyl]-N-[3-fluoro-2'-(methylsulfonyl)biphenyl-4-yl]-3-(trifluoromethyl)-1H-pyrazole-5-carboxamide
C25 H20 F4 N4 O3 S
ZLUOAFAJSUPHOG-UHFFFAOYSA-N
 Ligand Interaction
CA
Query on CA

Download CCD File
A
CALCIUM ION
Ca
BHPQYMZQTOCNFJ-UHFFFAOYSA-N
 Ligand Interaction
External Ligand Annotations
IDBinding Affinity (Sequence Identity %)
M35Ki :  0.15000000596046448   nM  PDBBind
M35IC50:  2.4000000953674316   nM  BindingDB
M35Ki:  0.15000000596046448   nM  BindingDB
M35Ki:  0.30000001192092896   nM  BindingDB
M35Ki:  150   nM  BindingDB
Experimental Data & Validation

Experimental Data

  • Method: X-RAY DIFFRACTION
  • Resolution: 2.15 Å
  • R-Value Free: 0.264
  • R-Value Work: 0.223
  • R-Value Observed: 0.226
  • Space Group: P 21 21 21
Unit Cell:
Length ( Å )Angle ( ˚ )
a = 56.8α = 90
b = 72.3β = 90
c = 77.7γ = 90
Software Package:
Software NamePurpose
CNSrefinement
PDB_EXTRACTdata extraction
HKL-2000data reduction
HKL-2000data scaling
EPMRphasing
CNXrefinement

Structure Validation

View Full Validation Report



Entry History

Deposition Data

  • Deposited Date: 2010-03-08
  • Released Date: 2010-04-21
  • Deposition Author(s): Alexander, R.S.

Revision History

  • Version 1.0: 2010-04-21
    Type: Initial release
  • Version 1.1: 2011-07-13
    Changes: Version format compliance
