3LVE

LEN Q38E MUTANT: A DOMAIN FLIP FROM A SINGLE AMINO ACID SUBSTITUTION


Experimental Data Snapshot

  • Method: X-RAY DIFFRACTION
  • Resolution: 2.00 Å
  • R-Value Free: 0.248
  • R-Value Work: 0.176
  • R-Value Observed: 0.176

wwPDB Validation   3D Report Full Report


This is version 1.2 of the entry. See complete history


Literature

A domain flip as a result of a single amino-acid substitution.

Pokkuluri, P.R.Huang, D.B.Raffen, R.Cai, X.Johnson, G.Stevens, P.W.Stevens, F.J.Schiffer, M.

(1998) Structure 6: 1067-1073

  • DOI: 10.1016/s0969-2126(98)00107-5
  • Primary Citation of Related Structures:
    3LVE, 4LVE, 2LVE

  • PubMed Abstract:
  • The self-assembly properties of beta domains are important features of diverse classes of proteins that include cell-adhesion molecules, surface receptors and the immunoglobulin superfamily. Immunoglobulin light-chain variable domains are well suited ...

    The self-assembly properties of beta domains are important features of diverse classes of proteins that include cell-adhesion molecules, surface receptors and the immunoglobulin superfamily. Immunoglobulin light-chain variable domains are well suited to the study of structural factors that determine dimerization, including how residues at the interface influence the preferred dimer arrangement.


    Organizational Affiliation

    Center for Mechanistic Biology and Biotechnology, Argonne National Laboratory, IL 60439, USA.



Macromolecules
Find similar proteins by:  (by identity cutoff)  |  Structure
Entity ID: 1
MoleculeChainsSequence LengthOrganismDetailsImage
LENA114Homo sapiensMutation(s): 1
Gene Names: IGKV4-1
Find proteins for P06312 (Homo sapiens)
Explore P06312
Go to UniProtKB:  P06312
NIH Common Fund Data Resources
PHAROS  P06312
Protein Feature View
Expand
  • Reference Sequence
Small Molecules
Ligands 1 Unique
IDChainsName / Formula / InChI Key2D Diagram3D Interactions
ZN
Query on ZN

Download CCD File
A
ZINC ION
Zn
PTFCDOFLOPIGGS-UHFFFAOYSA-N
 Ligand Interaction
Experimental Data & Validation

Experimental Data

  • Method: X-RAY DIFFRACTION
  • Resolution: 2.00 Å
  • R-Value Free: 0.248
  • R-Value Work: 0.176
  • R-Value Observed: 0.176
  • Space Group: P 42 2 2
Unit Cell:
Length ( Å )Angle ( ˚ )
a = 65.3α = 90
b = 65.3β = 90
c = 51.4γ = 90
Software Package:
Software NamePurpose
DENZOdata reduction
SCALEPACKdata scaling
AMoREphasing
X-PLORrefinement

Structure Validation

View Full Validation Report



Entry History

Deposition Data

Revision History

  • Version 1.0: 1999-05-18
    Type: Initial release
  • Version 1.1: 2008-03-25
    Changes: Version format compliance
  • Version 1.2: 2011-07-13
    Changes: Derived calculations, Version format compliance
