3KWD

Inactive truncation of the beta-carboxysomal gamma-Carbonic Anhydrase, CcmM, form 1


Experimental Data Snapshot

  • Method: X-RAY DIFFRACTION
  • Resolution: 1.1 Å
  • R-Value Free: 0.148
  • R-Value Work: 0.133

wwPDB Validation 3D Report Full Report


This is version 1.1 of the entry. See complete history

Literature

Structural basis of the oxidative activation of the carboxysomal {gamma}-carbonic anhydrase, CcmM.

Pena, K.L.Castel, S.E.de Araujo, C.Espie, G.S.Kimber, M.S.

(2010) Proc.Natl.Acad.Sci.USA 107: 2455-2460

  • DOI: 10.1073/pnas.0910866107
  • Primary Citation of Related Structures:

  • PubMed Abstract:
  • Cyanobacterial RuBisCO is sequestered in large, icosahedral, protein-bounded microcompartments called carboxysomes. Bicarbonate is pumped into the cytosol, diffuses into the carboxysome through small pores in its shell, and is then converted to CO(2) ...

    Cyanobacterial RuBisCO is sequestered in large, icosahedral, protein-bounded microcompartments called carboxysomes. Bicarbonate is pumped into the cytosol, diffuses into the carboxysome through small pores in its shell, and is then converted to CO(2) by carbonic anhydrase (CA) prior to fixation. Paradoxically, many beta-cyanobacteria, including Thermosynechococcus elongatus BP-1, lack the conventional carboxysomal beta-CA, ccaA. The N-terminal domain of the carboxysomal protein CcmM is homologous to gamma-CA from Methanosarcina thermophila (Cam) but recombinant CcmM derived from ccaA-containing cyanobacteria show no CA activity. We demonstrate here that either full length CcmM from T. elongatus, or a construct truncated after 209 residues (CcmM209), is active as a CA-the first catalytically active bacterial gamma-CA reported. The 2.0 A structure of CcmM209 reveals a trimeric, left-handed beta-helix structure that closely resembles Cam, except that residues 198-207 form a third alpha-helix stabilized by an essential Cys194-Cys200 disulfide bond. Deleting residues 194-209 (CcmM193) results in an inactive protein whose 1.1 A structure shows disordering of the N- and C-termini, and reorganization of the trimeric interface and active site. Under reducing conditions, CcmM209 is similarly partially disordered and inactive as a CA. CcmM protein in fresh E. coli cell extracts is inactive, implying that the cellular reducing machinery can reduce and inactivate CcmM, while diamide, a thiol oxidizing agent, activates the enzyme. Thus, like membrane-bound eukaryotic cellular compartments, the beta-carboxysome appears to be able to maintain an oxidizing interior by precluding the entry of thioredoxin and other endogenous reducing agents.


    Organizational Affiliation

    Department of Molecular and Cellular Biology, University of Guelph, Guelph, ON, Canada.




Macromolecules

Find similar proteins by: Sequence  |  Structure

Entity ID: 1
MoleculeChainsSequence LengthOrganismDetails
Carbon dioxide concentrating mechanism protein
A
213Thermosynechococcus elongatus (strain BP-1)Mutation(s): 0
Gene Names: ccmM
Find proteins for Q8DKB5 (Thermosynechococcus elongatus (strain BP-1))
Go to UniProtKB:  Q8DKB5
Small Molecules
Ligands 2 Unique
IDChainsName / Formula / InChI Key2D Diagram3D Interactions
ZN
Query on ZN

Download SDF File
Download CCD File
A
ZINC ION
Zn
PTFCDOFLOPIGGS-UHFFFAOYSA-N
 Ligand Interaction
CL
Query on CL

Download SDF File
Download CCD File
A
CHLORIDE ION
Cl
VEXZGXHMUGYJMC-UHFFFAOYSA-M
 Ligand Interaction
Experimental Data & Validation

Experimental Data

  • Method: X-RAY DIFFRACTION
  • Resolution: 1.1 Å
  • R-Value Free: 0.148
  • R-Value Work: 0.133
  • Space Group: H 3
Unit Cell:
Length (Å)Angle (°)
a = 103.006α = 90.00
b = 103.006β = 90.00
c = 44.953γ = 120.00
Software Package:
Software NamePurpose
REFMACrefinement
MOLREPphasing
HKL-3000data scaling
ADSCdata collection
HKL-3000data reduction

Structure Validation

View Full Validation Report or Ramachandran Plots



Entry History

Deposition Data

Revision History

  • Version 1.0: 2010-02-23
    Type: Initial release
  • Version 1.1: 2011-07-13
    Type: Advisory, Version format compliance
