3IUG | pdb_00003iug

Crystal structure of the RhoGAP domain of RICS

PDB DOI: https://doi.org/10.2210/pdb3IUG/pdb

Classification: SPLICING
Organism(s): Homo sapiens
Expression System: Escherichia coli
Mutation(s): No

Deposited: 2009-08-31 Released: 2009-09-29
Deposition Author(s): Nedyalkova, L., Tempel, W., Tong, Y., Li, Y., Arrowsmith, C.H., Edwards, A.M., Bountra, C., Weigelt, J., Bochkarev, A., Park, H., Structural Genomics Consortium (SGC)

Experimental Data Snapshot

Method: X-RAY DIFFRACTION
Resolution: 1.77 Å
R-Value Free:
0.245 (Depositor), 0.231 (DCC)
R-Value Work:
0.199 (Depositor)
R-Value Observed:
0.200 (Depositor)

Starting Model: experimental
View more details

wwPDB Validation 3D Report Full Report

This is version 1.3 of the entry. See complete history.

Literature

Crystal structure of the RhoGAP domain of RICS

Nedyalkova, L., Tempel, W., Tong, Y., Li, Y., Arrowsmith, C.H., Edwards, A.M., Bountra, C., Weigelt, J., Bochkarev, A., Park, H.

To be published.

Macromolecule Content

Total Structure Weight: 52.6 kDa
Atom Count: 3,315
Modeled Residue Count: 370
Deposited Residue Count: 458
Unique protein chains: 1

Macromolecules

Find similar proteins by:

| 3D Structure

Entity ID: 1
Molecule	Chains	Sequence Length	Organism	Details	Image
Rho/Cdc42/Rac GTPase-activating protein RICS	A, B	229	Homo sapiens	Mutation(s): 0 Gene Names: GI:134105571, GRIT, KIAA0712, RICS
UniProt & NIH Common Fund Data Resources
Find proteins for A7KAX9 (Homo sapiens) Explore A7KAX9 Go to UniProtKB: A7KAX9
PHAROS: A7KAX9 GTEx: ENSG00000134909
Entity Groups
Sequence Clusters	30% Identity 50% Identity 70% Identity 90% Identity 95% Identity 100% Identity
UniProt Group	A7KAX9
Sequence Annotations Expand
Reference Sequence

Small Molecules

Ligands 1 Unique
ID	Chains	Name / Formula / InChI Key	2D Diagram	3D Interactions
UNX Query on UNX Download:Ideal Coordinates CCD File SDF format, chain M [auth B] SDF format, chain L [auth B] SDF format, chain K [auth B] SDF format, chain J [auth B] SDF format, chain I [auth B] SDF format, chain H [auth B] SDF format, chain G [auth B] SDF format, chain F [auth B] SDF format, chain E [auth B] SDF format, chain D [auth A] SDF format, chain C [auth A] MOL2 format, chain M [auth B] MOL2 format, chain L [auth B] MOL2 format, chain K [auth B] MOL2 format, chain J [auth B] MOL2 format, chain I [auth B] MOL2 format, chain H [auth B] MOL2 format, chain G [auth B] MOL2 format, chain F [auth B] MOL2 format, chain E [auth B] MOL2 format, chain D [auth A] MOL2 format, chain C [auth A] mmCIF format, chain M [auth B] mmCIF format, chain L [auth B] mmCIF format, chain K [auth B] mmCIF format, chain J [auth B] mmCIF format, chain I [auth B] mmCIF format, chain H [auth B] mmCIF format, chain G [auth B] mmCIF format, chain F [auth B] mmCIF format, chain E [auth B] mmCIF format, chain D [auth A] mmCIF format, chain C [auth A]	C [auth A] D [auth A] E [auth B] F [auth B] G [auth B] C [auth A], D [auth A], E [auth B], F [auth B], G [auth B], H [auth B], I [auth B], J [auth B], K [auth B], L [auth B], M [auth B]	UNKNOWN ATOM OR ION X		Interactions Focus chain C [auth A] Focus chain D [auth A] Focus chain E [auth B] Focus chain F [auth B] Focus chain G [auth B] Focus chain H [auth B] Focus chain I [auth B] Focus chain J [auth B] Focus chain K [auth B] Focus chain L [auth B] Focus chain M [auth B] Interactions & Density Focus chain C [auth A] Focus chain D [auth A] Focus chain E [auth B] Focus chain F [auth B] Focus chain G [auth B] Focus chain H [auth B] Focus chain I [auth B] Focus chain J [auth B] Focus chain K [auth B] Focus chain L [auth B] Focus chain M [auth B]

Experimental Data & Validation

Experimental Data

Method: X-RAY DIFFRACTION
Resolution: 1.77 Å
R-Value Free: 0.245 (Depositor), 0.231 (DCC)
R-Value Work: 0.199 (Depositor)
R-Value Observed: 0.200 (Depositor)

Space Group: P 2₁ 2₁ 2

Unit Cell:

Length ( Å )	Angle ( ˚ )
a = 102.264	α = 90
b = 117.369	β = 90
c = 37.717	γ = 90

Software Package:

Software Name	Purpose
DENZO	data reduction
SCALEPACK	data scaling
PHASER	phasing
REFMAC	refinement
PDB_EXTRACT	data extraction
HKL-2000	data reduction
HKL-2000	data scaling

Structure Validation

View Full Validation Report

View more in-depth experimental data

Entry History

Deposition Data

Released Date: 2009-09-29

Deposition Author(s):

Structural Genomics Consortium (SGC)

Revision History (Full details and data files)

Version 1.0: 2009-09-29
Type: Initial release
Version 1.1: 2011-07-13
Changes: Version format compliance
Version 1.2: 2017-11-01
Changes: Refinement description
Version 1.3: 2023-09-06
Changes: Data collection, Database references, Refinement description
